Diagnostic Trouble Code (DTC) Chart
| DTC | Description | Source | Action |
|---|---|---|---|
| B1105 | Rear Open/Close Switch Active During Self-Test | Power Liftgate Module | REFER to BODY CLOSURES . |
| B1200 | Climate Control Push Button Circuit Failure | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1201 | Fuel Sender Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER . |
| B1202 | Fuel Sender Circuit Open | SJB | REFER to INSTRUMENT CLUSTER . |
| B1202 | Fuel Sender Circuit Open | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1204 | Fuel Sender Circuit Short to Ground | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1205 | EIC Switch 1 Assembly Circuit Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1217 | Horn Relay Coil Circuit Failure | SJB | REFER to HORN . |
| B1231 | Longitudinal Acceleration Threshold Exceeded | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1242 | Air Flow Recirculation Door Driver Circuit Failure | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1251 | Air Temperature Internal Sensor Circuit Open | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1253 | Air Temperature Internal Sensor Circuit Short to Ground | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1254 | Air Temperature External Sensor Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1255 | Air Temperature External Sensor Circuit Open | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1263 | Servo Motor Vent Circuit Failure | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1299 | Power Supply Sensor Circuit Short to Ground | Parking Aid Module | REFER to PARKING AID . |
| B1306 | Oil Level Switch Circuit Open | SJB | REFER to INSTRUMENT CLUSTER . |
| B1309 | Power Door Lock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1317 | Battery Voltage High | Power Liftgate Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | ABS Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Power Liftgate Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Speed Control Actuator | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | ABS Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1319 | Drivers Door Ajar Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1327 | Passengers Door Ajar Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1335 | Door Ajar RR Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1341 | Power Door Unlock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1342 | ECU is Defective | Power Liftgate Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new power liftgate module. REFER to BODY CLOSURES . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Speed Control Actuator | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new speed control actuator. REFER to SPEED CONTROL . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Right Power Sliding Door Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new right power sliding door module. REFER to BODY CLOSURES . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Left Power Sliding Door Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new left power sliding door module. REFER to BODY CLOSURES . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | DATC Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DATC module. REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Climate Control Seat Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new climate control seat module. REFER to SEATING . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | ABS Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS module. REFER to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Instrument Cluster | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Parking Aid Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new parking aid module. REFER to PARKING AID . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | RCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | DSM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DSM. REFER to DRIVER SEAT MODULE (DSM) . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B1345 | Heated Backlite Input Circuit Short to Ground | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1349 | Heated Backlite Relay Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1352 | Ignition Key-In Circuit Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1356 | Ignition Run Circuit Open | SJB | REFER to STEERING SYSTEM-GENERAL INFORMATION . |
| B1358 | Ignition Run Circuit Short to Ground | Climate Control Seat Module | REFER to SEATING . |
| B1360 | Ignition Run/ACC Circuit Open | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1361 | Ignition Run/Acc Circuit Short to Battery | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1365 | Ignition Start Circuit Short to Battery | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1365 | Ignition Start Circuit Short to Battery | Power Liftgate Module | REFER to STEERING COLUMN SWITCHES . |
| B1470 | Lamp Headlamp Input Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1475 | Accessory Delay Relay 1 Short to Battery | SJB | REFER to INTERIOR LIGHTING . |
| B1482 | Wiper/Washer Fluid Level Sensor Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER . |
| B1485 | Brake Pedal Input Circuit Short to Battery | SJB | REFER to ANTI-LOCK CONTROL . |
| B1499 | Lamp Turn Signal Left Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1501 | Lamp Turn Signal Left Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B1503 | Lamp Turn Signal Right Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1505 | Lamp Turn Signal Right Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B1519 | Hood Switch Circuit Failure | SJB | REFER to ANTI-THEFT . |
| B1530 | Memory Set Switch Circuit Short to Ground | DSM | REFER to SEATING . |
| B1533 | Memory 1 Switch Circuit Short to Battery | SJB | REFER to SEATING . |
| B1534 | Memory 1 Switch Circuit Short to Ground | DSM | REFER to SEATING . |
| B1534 | Memory 1 Switch Circuit Short to Ground | SJB | REFER to SEATING . |
| B1537 | Memory 2 Switch Circuit Short to Battery | SJB | REFER to SEATING . |
| B1538 | Memory 2 Switch Circuit Short to Ground | DSM | REFER to SEATING . |
| B1538 | Memory 2 Switch Circuit Short to Ground | SJB | REFER to SEATING . |
| B1571 | Door Ajar LR Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1626 | Lamp Keypad Output Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1629 | PRNDL Reverse Input Short to Ground | Parking Aid Module | REFER to PARKING AID . |
| B1663 | Seat Driver Front Up/Down Motor Stalled | DSM | REFER to SEATING . |
| B1664 | Seat Driver Rear Up/Down Motor Stalled | DSM | REFER to SEATING . |
| B1665 | Seat Driver Forward/Backward Motor Stalled | DSM | REFER to SEATING . |
| B1666 | Seat Recline Forward/Reward Motor Stalled | DSM | REFER to SEATING . |
| B1667 | Mirror Driver Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1668 | Mirror Driver Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1669 | Mirror Passenger Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1670 | Mirror Passenger Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1676 | Battery Pack Voltage Out of Range | DATC Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1676 | Battery Voltage Out of Range | Instrument Cluster | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1676 | Battery Voltage Out of Range | DSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1676 | Battery Pack Voltage Out of Range | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1703 | Driver Seat Recline Forward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1707 | Driver Seat Recline Rearward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1711 | Seat Driver Front Up Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1715 | Seat Driver Front Down Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1719 | Seat Driver Forward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1723 | Seat Driver Rearward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1727 | Seat Driver Rear Up Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1731 | Seat Driver Rear Down Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1735 | Mirror Driver Vertical Switch Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B1739 | Mirror Driver Horizontal Switch Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B1743 | Mirror Passenger Vertical Switch Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B1747 | Mirror Passenger Horizontal Switch Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B1790 | Autolamp Sensor Input Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1833 | Door Unlock Disarm Switch Circuit Short to Ground | SJB | REFER to ANTI-THEFT . |
| B1869 | Lamp Air Bag Warning Indicator Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1870 | Lamp Air Bag Warning Indicator Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1884 | PAD Warning Lamp Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1890 | PAD Warning Lamp Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1891 | Air Bag Tone Warning Indicator Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1892 | Air Bag Tone Warning Indicator Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1897 | Horn Switch Circuit Failure | SJB | REFER to HORN . |
| B1921 | Air Bag Diagnostic Monitor Ground Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1950 | Seat Rear Up/Down Feedback Potentiometer Circuit Failure | DSM | REFER to SEATING . |
| B1952 | Seat Rear Up/Down Feedback Potentiometer Circuit Short to Battery | DSM | REFER to SEATING . |
| B1954 | Seat Front Up/Down Feedback Potentiometer Circuit Failure | DSM | REFER to SEATING . |
| B1956 | Seat Front Up/Down Feedback Potentiometer Circuit Short to Battery | DSM | REFER to SEATING . |
| B1958 | Seat Recline Fwd/Backward Feedback Pot. Ckt. Short to Battery | DSM | REFER to SEATING . |
| B1961 | Seat Recline Fwd/Backward Feedback Pot. Circuit Failure | DSM | REFER to SEATING . |
| B1962 | Seat Horizontal Fwd/Rwd Feedback Potentiometer Circuit Failure | DSM | REFER to SEATING . |
| B1964 | Seat Horizontal Fwd/Rwd Feedback Potentiometer Circuit Short to Battery | DSM | REFER to SEATING . |
| B1987 | Pedal Forward/Rearward Motor Stalled | DSM | REFER to BRAKE SYSTEM-GENERAL INFORMATION . |
| B1988 | Pedal Position Forward Switch Circuit Short to Ground | DSM | REFER to BRAKE SYSTEM-GENERAL INFORMATION . |
| B1989 | Pedal Position Rearward Switch Circuit Short to Ground | DSM | REFER to BRAKE SYSTEM-GENERAL INFORMATION . |
| B1990 | Pedal Fwd/Rwd Feedback Potentiometer Circuit Failure | DSM | REFER to BRAKE SYSTEM-GENERAL INFORMATION . |
| B1991 | Pedal Fwd/Rwd Feedback Potentiometer Circuit Short to Battery | DSM | REFER to BRAKE SYSTEM-GENERAL INFORMATION . |
| B2008 | Wipers On Signal Circuit Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2019 | Cinch Time Exceeded | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2020 | Courtesy Lamp Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B2021 | Dome Lamp Output Return Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2023 | Rear Courtesy Lamp Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B2024 | Rear Courtesy Lamp Output Return Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2025 | Demand Lamps Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2026 | Incandescent Backlighting Output Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2027 | LED Backlighting Output Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2028 | Power Liftgate Open/Close Output Circuit Failure | SJB | REFER to BODY CLOSURES . |
| B2029 | Power Liftgate Open/Close Output Circuit Short to Battery | SJB | REFER to BODY CLOSURES . |
| B2030 | Front Fog Lamp Relay Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2031 | Left Corner Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2032 | Right Corner Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2033 | Left Aux. Park Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2034 | Right Aux. Park Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2039 | License Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2040 | Mirror Lamp Output Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2041 | Mirror Lamp Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B2042 | Left Mirror Turn Signal Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2043 | Right Mirror Turn Signal Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2044 | Left Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2045 | Left Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2046 | Right Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2047 | Right Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2048 | Left Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2049 | Left Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2050 | Right Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2051 | Right Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2052 | Accessory Delay Relay Output Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2053 | Accessory Delay Relay 2 Output Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2054 | Accessory Delay Relay 2 Short to Battery | SJB | REFER to INTERIOR LIGHTING . |
| B2055 | LH PSD Open/Close Output Circuit Failure | SJB | REFER to BODY CLOSURES . |
| B2056 | RH PSD Open/Close Output Circuit Failure | SJB | REFER to BODY CLOSURES . |
| B2057 | LH PSD Open/Close Switch Circuit Short to Ground (Overhead Console) | SJB | REFER to BODY CLOSURES . |
| B2058 | RH PSD Open/Close Switch Circuit Short to Ground (Overhead Console) | SJB | REFER to BODY CLOSURES . |
| B2060 | Heated Backlite Indicator Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2061 | Heated Backlite Indicator Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2066 | Park Enabled Status Output Circuit Failure | SJB | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION . |
| B2067 | Park Enabled Status Output Circuit Short to Ground | SJB | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION . |
| B2070 | Trailer Tow Relay Coil(s) Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2071 | Hazard Switch Signal Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2077 | Liftgate Ajar Switch Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2175 | A/C Request Signal Circuit Short to Ground | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2237 | VSS-PARK Mismatch | LH PSD Module | REFER to BODY CLOSURES . |
| B2237 | VSS-PARK Mismatch | RH PSD Module | REFER to BODY CLOSURES . |
| B2237 | Vehicle Signal Indication Park While VSS Present | SJB | REFER to BODY CLOSURES . |
| B2238 | Power Cable for PSD Broken | LH PSD Module | REFER to BODY CLOSURES . |
| B2238 | Power Cable for PSD Broken | RH PSD Module | REFER to BODY CLOSURES . |
| B2254 | Front Fog Lamp Switch Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2266 | Servo Motor Left Blend Door Circuit Failure | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2267 | Servo Motor Right Blend Door Circuit Failure | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2270 | PSD Exceeded Time Allowed to Cinch Door | LH PSD Module | REFER to BODY CLOSURES . |
| B2270 | PSD Exceeded Time Allowed to Cinch Door | RH PSD Module | REFER to BODY CLOSURES . |
| B2271 | PSD Did Not Reach Full Open Position During Self-Test | LH PSD Module | REFER to BODY CLOSURES . |
| B2271 | PSD Did Not Reach Full Open Position During Self-Test | RH PSD Module | REFER to BODY CLOSURES . |
| B2276 | Less Than 2 Transmitters Programmed | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2281 | Right Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2282 | Left Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2290 | Occupant Classification System Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2292 | Restraint System-Seatbelt Pretensioner Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2293 | Restraint System-Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2294 | Restraint System-Curtain Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2295 | Restraint System-Side Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2296 | Restraint System-Impact Sensor Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2312 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2314 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2316 | Mirror Passenger Vertical Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2318 | Mirror Passenger Vertical Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2320 | Mirror Driver Horizontal Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2322 | Mirror Driver Horizontal Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2324 | Mirror Driver Vertical Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2326 | Mirror Driver Vertical Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2362 | Remote Key Fob Open/Close Signal Circuit Short to Ground From SJB | LH PSD Module | REFER to BODY CLOSURES . |
| B2362 | Remote Key Fob Open/Close Signal Circuit Short to Ground From SJB | RH PSD Module | REFER to BODY CLOSURES . |
| B2363 | Optical Sensor System Failure | LH PSD Module | REFER to BODY CLOSURES . |
| B2363 | Optical Sensor System Failure | RH PSD Module | REFER to BODY CLOSURES . |
| B2364 | Fuel Filler Door Open Circuit | LH PSD Module | REFER to BODY CLOSURES . |
| B2364 | Fuel Filler Door Open Circuit | RH PSD Module | REFER to BODY CLOSURES . |
| B2365 | B-Pillar Power Sliding Door Open/Close Switch Circuit Short to Ground | LH PSD Module | REFER to BODY CLOSURES . |
| B2365 | B-Pillar Power Sliding Door Open/Close Switch Circuit Short to Ground | RH PSD Module | REFER to BODY CLOSURES . |
| B2366 | Power Sliding Door Open/Close Switch Circuit Short to Ground (Overhead Console) | LH PSD Module | REFER to BODY CLOSURES . |
| B2366 | Power Sliding Door Open/Close Switch Circuit Short to Ground (Overhead Console) | RH PSD Module | REFER to BODY CLOSURES . |
| B2367 | PSD On/Off Switch Open Circuit | LH PSD Module | REFER to BODY CLOSURES . |
| B2367 | PSD On/Off Switch Open Circuit | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2367 | PSD On/Off Switch Open Circuit | RH PSD Module | REFER to BODY CLOSURES . |
| B2373 | LED #1 Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| B2374 | PSD Detent (Latch) Switch Circuit Short to Ground | LH PSD Module | REFER to BODY CLOSURES . |
| B2374 | PSD Detent (Latch) Switch Circuit Short to Ground | RH PSD Module | REFER to BODY CLOSURES . |
| B2425 | RKE Out of Sync | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2426 | Passenger Solar Radiation Sensor Circuit Open | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2427 | Passenger Solar Radiation Sensor Circuit Short to Ground | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2432 | Drivers Seat Belt Buckle Switch Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2433 | Drivers Seat Belt Buckle Switch Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2434 | Drivers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2435 | Drivers Seat Belt Buckle Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2436 | Passengers Seat Belt Buckle Switch Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2437 | Passengers Seat Belt Buckle Switch Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2438 | Passengers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2439 | Passengers Seat Belt Buckle Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2474 | Passenger Door Lock Switch Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2475 | Passenger Door Unlock Switch Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2477 | Module Configuration Failure | DATC | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Climate Control Seat Module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | ABS Module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Instrument Cluster | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Parking Aid Module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | RCM | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | DSM | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | SJB | REFER to MODULE CONFIGURATION . |
| B2479 | Brake Park Switch Circuit Short to Ground | SJB | REFER to ANTI-LOCK CONTROL . |
| B2483 | Park Signal Open Circuit (From SJB) | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2483 | Park Signal Open Circuit (From SJB) | LH PSD Module | REFER to BODY CLOSURES . |
| B2483 | Park Signal Open Circuit (From SJB) | RH PSD Module | REFER to BODY CLOSURES . |
| B2486 | Climate Control Seat Module Voltage Out of Range | Climate Control Seat Module | REFER to SEATING . |
| B2488 | Thumb-Wheel Switch Out of Range High | Climate Control Seat Module | REFER to SEATING . |
| B2491 | RF Park Lamp Output Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2493 | LF Park Lamp Output Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2499 | Courtesy Lamp Output Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2501 | LF Low Beam Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2503 | RF Low Beam Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2514 | Blower (Fan) Output Short to Battery | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2519 | High Mount Stop Lamp Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2521 | Tach Circuit Failure | Climate Control Seat Module | REFER to SEATING . |
| B2523 | License Lamp Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2525 | Left Rear Backup Lamp Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2528 | Left Rear Stop Lamp Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2529 | Left Rear Turn Lamp Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2532 | Right Rear Backup Lamp Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2534 | Right Rear Stop Lamp Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2543 | Aux. A/C Control Switch Reference Circuit Short to Ground | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2544 | Aux. A/C Control Switch Reference Circuit Short to Battery | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2550 | Lamp Dome Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B2554 | Lamp Dome Output Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2557 | Left Power Sliding Door Open/Close Output Circuit Short to Battery | SJB | REFER to BODY CLOSURES . |
| B2558 | Right Power Sliding Door Open/Close Output Circuit Short to Battery | SJB | REFER to BODY CLOSURES . |
| B2559 | Aux. A/C Blower Motor Relay Circuit Short to Battery | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2561 | Aux. A/C Blower Speed 1 Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2562 | Aux. A/C Blower Speed 1 Circuit Short to Ground | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2563 | Aux. A/C Blower Speed 2 Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2564 | Aux. A/C Blower Speed 2 Circuit Short to Ground | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2565 | Right Park/Tail Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2567 | Reverse Mirror Output Circuit Failure | SJB | REFER to REAR VIEW MIRRORS . |
| B2568 | Reverse Mirror/Reverse Park Aid Output Circuit Short to Ground | SJB | REFER to REAR VIEW MIRRORS . |
| B2577 | Left Park/Tail Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2586 | Headlamp Mode Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2589 | No Detent (Latch) Switch Detected on Closing, and Door Reversed | LH PSD Module | REFER to BODY CLOSURES . |
| B2589 | No Detent (Latch) Switch Detected on Closing, and Door Reversed | RH PSD Module | REFER to BODY CLOSURES . |
| B2591 | No Detent (Latch) Switch Detected on Unlatch | LH PSD Module | REFER to BODY CLOSURES . |
| B2591 | No Detent (Latch) Switch Detected on Unlatch | RH PSD Module | REFER to BODY CLOSURES . |
| B2592 | Door Not Pulled Into Primary During Power Close and High Duty Cycles | LH PSD Module | REFER to BODY CLOSURES . |
| B2592 | Door Not Pulled Into Primary During Power Close and High Duty Cycles | RH PSD Module | REFER to BODY CLOSURES . |
| B2593 | Door Reversed While Closing Due to An Obstacle Was Sensed | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2593 | Door Reversed While Closing Due to An Obstacle Was Sensed | LH PSD Module | REFER to BODY CLOSURES . |
| B2593 | Door Reversed While Closing Due to An Obstacle Was Sensed | RH PSD Module | REFER to BODY CLOSURES . |
| B2594 | No Movement Detected After an Unlatch, During Power Open Operation | LH PSD Module | REFER to BODY CLOSURES . |
| B2594 | No Movement Detected After an Unlatch, During Power Open Operation | RH PSD Module | REFER to BODY CLOSURES . |
| B2598 | Headlamp Relay Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2603 | PSD Not Pulled Into Primary Latch Position During Power Close During Self-Test | LH PSD Module | REFER to BODY CLOSURES . |
| B2603 | PSD Not Pulled Into Primary Latch Position During Power Close During Self-Test | RH PSD Module | REFER to BODY CLOSURES . |
| B2605 | VSS Signal Open Circuit (From SJB) | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2605 | VSS Signal Open Circuit (From SJB) | LH PSD Module | REFER to BODY CLOSURES . |
| B2605 | VSS Signal Open Circuit (From SJB) | RH PSD Module | REFER to BODY CLOSURES . |
| B2666 | Liftgate Release Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2675 | Keypad -B Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2676 | Keypad -C Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2686 | Right Park/Tail Lamp Output Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2687 | Left Park/Tail Lamp Output Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2688 | Aux. A/C Blower Motor Relay Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2695 | Keypad -A Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2699 | Left Pinch Strip Open or Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2700 | Right Pinch Strip Open or Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2701 | Left Pinch Strip Stuck Active | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2702 | Right Pinch Strip Stuck Active | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2704 | Optical Sensor Power Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2713 | Chime Output Circuit Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2714 | Uncinch Output Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2715 | Cinch Output Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2722 | Open/Close Switch Active During Self-Test | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2729 | Cushion Over-Temp Detected | Climate Control Seat Module | REFER to SEATING . |
| B2730 | Back-Over Temp. Detected | Climate Control Seat Module | REFER to SEATING . |
| B2731 | Cushion Temp. 20° Celsius Differential From Back Temp. | Climate Control Seat Module | REFER to SEATING . |
| B2792 | Heat Switch Short to Ground | Climate Control Seat Module | REFER to SEATING . |
| B2793 | Cool Switch Short to Ground | Climate Control Seat Module | REFER to SEATING . |
| B2795 | Driver Solar Radiation Sensor Circuit Short to Ground | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2796 | Driver Solar Radiation Sensor Circuit Open | DATC Module | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2819 | Gate Motor Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2859 | Power Sliding Door Position Out of Range | LH PSD Module | REFER to BODY CLOSURES . |
| B2859 | Power Sliding Door Position Out of Range | RH PSD Module | REFER to BODY CLOSURES . |
| B2908 | Latch Switch Invalid | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2909 | Belt Tension Sensor Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2916 | Aux. (Rear) Climate Control Blend Door Output Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2917 | Aux. Climate Control Mode Door Position Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2919 | Aux. Blower Motor Speed Input Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2920 | Aux. (Rear) Mode Door Position Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2921 | Aux. (Rear) Temperature Blend Door Circuit Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B2931 | Optical Sensor 1 Short to Battery or Open | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2932 | Optical Sensor 1 Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2933 | Optical Sensor 2 Short to Battery or Open | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2934 | Optical Sensor 2 Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2935 | Drive Unit Failure | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2936 | Gate Motor Open | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2937 | Gate Motor Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2938 | Gate Clutch Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2939 | Gate Clutch Short to Ground or Open | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2940 | Chime Output Circuit Short to Ground | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2941 | Cinch Motor Open | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2942 | Cinch Output Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2943 | Uncinch Output Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2944 | Unlatch Output Short to Battery | Power Liftgate Module | REFER to BODY CLOSURES . |
| B2947 | Lighting Mode Switch Input Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| C1093 | Traction Control Disable Switch Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| C1095 | ABS Hydraulic Pump Motor Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1096 | ABS Hydraulic Pump Motor Circuit Open | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1103 | ABS Hydraulic Brake Switch Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1109 | Throttle Did Not Return to Idle After Self-Test | Speed Control Actuator | REFER to SPEED CONTROL . |
| C1115 | ABS Power Relay Output Short Circuit to Battery | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1126 | Command Switch Stuck for 2 Minutes or Longer | Speed Control Actuator | REFER to SPEED CONTROL . |
| C1127 | Deactivator Switch Stuck Open | Speed Control Actuator | REFER to SPEED CONTROL . |
| C1145 | Wheel Speed Sensor RF Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1155 | Wheel Speed Sensor LF Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1165 | Wheel Speed Sensor RR Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1175 | Wheel Speed Sensor LR Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1179 | Excessive Cable Slack in Speed Control Cable | Speed Control Actuator | REFER to SPEED CONTROL . |
| C1185 | ABS Power Relay Output Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1189 | Brake Fluid Level Sensor Input Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER . |
| C1194 | ABS Outlet Valve Coil LF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1198 | ABS Inlet Valve Coil LF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1210 | ABS Outlet Valve Coil RF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1214 | ABS Inlet Valve Coil RF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1222 | Wheel Speed Mismatch | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1233 | Wheel Speed LF Input Signal Missing | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1234 | Wheel Speed RF input Signal Missing | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1235 | Wheel Speed RR Input Signal Missing | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1236 | Wheel Speed LR Input Signal Missing | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1242 | ABS Outlet Valve Coil LR Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1246 | ABS Outlet Valve Coil RR Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1250 | ABS Inlet Valve Coil LR Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1254 | ABS Inlet Valve Coil RR Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1277 | Steering Wheel Angle 1 and 2 Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1278 | Steering Wheel Angle 1 and 2 Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1279 | Yaw Rate Sensor Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1280 | Yaw Rate Sensor Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1281 | Lateral Accelerometer Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1282 | Lateral Accelerometer Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1285 | Booster Solenoid Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1286 | Booster Mechanical Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1287 | Booster Pedal Force Switch Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1288 | Pressure Transducer Main/Primary Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1404 | Traction Control Valve Rear Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1410 | Traction Control Valve LF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1414 | Incorrect Module Design Level | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1445 | Vehicle Speed Signal Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER . |
| C1446 | Brake Switch Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1699 | Rear Outer Left Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1700 | Rear Outer Left Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1701 | Rear Outer Left Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1702 | Rear Outer Right Sensor Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1703 | Rear Outer Right Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1704 | Rear Outer Right Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1705 | Rear Inner Left Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1706 | Rear Inner Left Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1707 | Rear Inner Left Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1708 | Rear Inner Right Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1709 | Rear Inner Right Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1710 | Rear Inner Right Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1711 | Front Outer Left Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1712 | Front Outer Left Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1713 | Front Outer Left Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1714 | Front Outer Right Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1715 | Front Outer Right Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1716 | Front Outer Right Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1717 | Front Inner Left Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1718 | Front Inner Left Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1719 | Front Inner Left Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1730 | Reference Voltage Out of Range | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1739 | Front Inner Right Sensor Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1740 | Front Inner Right Sensor Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1741 | Front Inner Right Sensor Fault | Parking Aid Module | REFER to PARKING AID . |
| C1742 | Rear Sounder Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1743 | Rear Sounder Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1744 | Front Sounder Circuit Failure | Parking Aid Module | REFER to PARKING AID . |
| C1745 | Front Sounder Circuit Short to Battery | Parking Aid Module | REFER to PARKING AID . |
| C1748 | Switch Input Circuit Short to Ground | Parking Aid Module | REFER to PARKING AID . |
| C1779 | Blower Switch Failure | SJB | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| C1920 | LED #1 Circuit Short to Ground | Parking Aid Module | REFER to PARKING AID . |
| C1946 | Front Drivers Seat Track Position Switch Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1947 | Front Drivers Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1948 | Front Drivers Seat Track Position Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1957 | Dynamic Stability Control Valve RF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1958 | Dynamic Stability Control Valve LF Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1963 | Stability Control Inhibit Warning | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1982 | Front Drivers Seat Track Position Switch Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1991 | Module Calibration Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1999 | Vehicle Speed Signal Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER . |
| C2201 | Front Passengers Seat Track Position Switch Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C2202 | Front Passengers Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C2203 | Front Passengers Seat Track Position Switch Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C2204 | Front Passengers Seat Track Position Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| PXXX | PCM | See INTRODUCTION - GASOLINE article. | |
| U1009 | SCP (J1850) Invalid or Missing Data for Engine Torque | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1011 | SCP (J1850) Invalid or Missing Data for Engine Air Intake | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1027 | SCP (J1850) Invalid or Missing Data for Engine RPM | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1027 | Missing or Invalid Throttle Message | Speed Control Actuator | REFER to SPEED CONTROL . |
| U1041 | Missing or Invalid Speed Message | Speed Control Actuator | REFER to SPEED CONTROL . |
| U1041 | SCP (J1850) Invalid or Missing Data for Vehicle Speed | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| U1041 | SCP (J1850) Invalid or Missing Data for Vehicle Speed | SJB | REFER to ANTI-LOCK CONTROL . |
| U1042 | SCP (J1850) Invalid or Missing Data for Traction Control | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1043 | SCP (J1850) Invalid or Missing Data for Traction Control | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| U1050 | SCP (J1850) Invalid or Missing Data for Brakes | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1051 | SCP (J1850) Invalid or Missing Data for Brakes | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1051 | SCP (J1850) Invalid or Missing Data for Brakes | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| U1051 | Missing or Invalid Brake Message | Speed Control Actuator | REFER to SPEED CONTROL . |
| U1059 | SCP (J1850) Invalid or Missing Data for Transmission/Transaxle/PRNDL | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1059 | SCP (J1850) Invalid or Missing Data for Transmission/Transaxle/PRNDL | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| U1059 | Missing or Invalid PRNDL Message | Speed Control Actuator | REFER to SPEED CONTROL . |
| U1073 | SCP (J1850) Invalid or Missing Data for Engine Coolant | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1073 | SCP (J1850) Invalid or Missing Data for Engine Coolant | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1075 | SCP (J1850) Invalid or Missing Data for Engine Oil | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1123 | SCP (J1850) Invalid or Missing Data for Odometer | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1130 | SCP (J1850) Invalid or Missing Data for Fuel System | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1135 | SCP (J1850) Invalid or Missing Data for Ignition Switch/Starter | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1136 | SCP (J1850) Invalid or Missing Data for Telltales | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1222 | SCP (J1850) Invalid or Missing Data for Interior Lamps | Instrument Cluster | REFER to INTERIOR LIGHTING . |
| U1243 | SCP (J1850) Invalid or Missing Data for Exterior Environment | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1249 | SCP (J1850) Invalid or Missing Data for Time/Date | ABS Module | REFER to ANTI-LOCK CONTROL . |
| U1262 | SCP Communication Bus Fault | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1262 | SCP Communication Bus Fault | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1262 | SCP (J1850) Communication Bus Fault | SJB | REFER to MODULE COMMUNICATIONS NETWORK . |
| U2051 | One or More Calibration Files Missing or Corrupt | SJB | REFER to MODULE CONFIGURATION . |
| U2362 | UBP Invalid Data from Node ID $98 | Climate Control Seat Module | REFER to MODULE COMMUNICATIONS NETWORK . |
DTC DESCRIPTION
Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Bussed electrical center (BEC) fuse(s): 10 (30A) 51 (10A) DSM Circuitry
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual.
- Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP, UBP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(ref-234508) . No response/not equipped for DSM, GO to «PINPOINT TEST A»(ref-234516-S38323224962006061000000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out self-test diagnostics for the DSM.
- If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-234516-S05814077162006061000000) to continue diagnostics.
- If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-234516-S33256270892006061000000) .
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the driver seat module (DSM) | Bussed electrical center (BEC) fuse(s): 10 (30A) 51 (30A) Circuit or connection in the universal asynchronous receiver transmitter (UART)-based protocol (UBP) network DSM | GO to PINPOINT TEST A . |
SYMPTOM CHART
Scheme 58
Scheme 59
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Bussed electrical center (BEC) fuse(s): 58 (30A) 62 (30A) 65 (30A) Circuitry Smart junction box (SJB)
- If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual.
- Carry out the diagnostic tool data link test. If the diagnostic tool responds with: ISO, UBP or SCP circuits fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(ref-234508) . No response/not equipped for the SJB, GO to «PINPOINT TEST B»(ref-234516-S32807892262006061000000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out self-test diagnostics for the SJB.
- If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-234516-S05814077162006061000000) .
- If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-234516-S36781577752006061000000) .
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the smart junction box (SJB) | Bussed electrical center (BEC) fuse(s): 58 (30A) 62 (30A) 65 (30A) Circuitry SJB | GO to PINPOINT TEST B . |
SYMPTOM CHART
