HVAC System - Air Conditioning: Component Locations Mercury Monterey VIII

Special Tool(s)

SPECIAL TOOL DESCRIPTION Remover, Compressor Pulley 412-001 (T71P-19703-B) Installer, A/C Compressor Coil 412-065 (T89P-19623-EH) Wrench 205-036 (T70P-4067-A) Installer, A/C Compressor Field Coil 412-078 (T91L-19623-CH) Remover, A/C Compressor Field Coil 412-067 (T89P-19623-FH)

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR»(ref-234497-S01568185462006061000000) .
2. Remove the A/C clutch disc and hub bolt. Using the special tool, hold the A/C clutch disc and hub. Remove the A/C clutch disc and hub bolt.
3. Remove the A/C clutch disc and hub.
4. Remove the A/C clutch disc and hub spacer(s).
5. Remove the A/C clutch pulley snap ring.
6. Remove the A/C compressor pulley. Install the special tool. Remove the A/C compressor pulley.
7. Remove the A/C clutch field coil. Install the special tool. Install the special tool. Remove the A/C clutch field coil.

SPECIAL TOOL DESCRIPTION Wrench 205-036 (T70P-4067-A) Protector, A/C Compressor Shaft Oil Seal 412-094 (T94P-19623-F) Remover, A/C Compressor Shaft Oil Seal 412-059 (T89P-19623-BH) Installer, A/C Compressor Shaft Oil Seal 412-058 (T89P-19623-AH) Remover, A/C Compressor Snap Ring 412-063 (T89P-19623-DH) Remover, O-Ring Seal 100-010 (T71P-19703-C)

Scheme 9

Scheme 10

Scheme 11

SPECIAL TOOL DESCRIPTION Remover, Broken Orifice 412-035 (T83L-19990-B) Remover/Installer, Fixed Orifice 412-034 (T38L-19990-A)
