HVAC System - Control Components: Removal & Installation Mercury Monterey VIII

Automatic HVAC System 7 illustrations ~349 words

Removal and Installation

  1. Lower the glove compartment.
  2. Disconnect the blower motor resistor electrical connector.
  3. Remove the 2 blower motor resistor screws.
  4. Remove the blower motor resistor.
  5. To install, reverse the removal procedure.

Scheme 270

Scheme 270: Climate Control Assembly
Scheme 270: Climate Control Assembly
  1. Remove the center instrument cluster finish panel. Pull outward to release the retaining clips on the center instrument cluster finish panel. Disconnect the electrical connectors.
  2. Remove the 4 climate control assembly screws.
  3. Remove the climate control assembly.
  4. To install, reverse the removal procedure.

Scheme 271

Scheme 271: Blower Motor Speed Control
Scheme 271: Blower Motor Speed Control
  1. Lower the glove compartment.
  2. Disconnect the blower motor speed control electrical connector.
  3. Remove the blower motor speed control screw.
  4. Remove the blower motor speed control.
  5. To install, reverse the removal procedure.

Scheme 272

Scheme 272: In-Vehicle Temperature Sensor
Scheme 272: In-Vehicle Temperature Sensor
  1. Remove the center instrument panel finish panel.
  2. Remove the in-vehicle temperature sensor.
  3. To install, reverse the removal procedure.

Scheme 273

Scheme 273: Temperature Blend Door Actuator - LH
Scheme 273: Temperature Blend Door Actuator - LH

Note. The LH temperature blend door actuator can be accessed from below the LH side of the instrument panel.

  1. Remove the 3 LH temperature blend door actuator screws.
  2. Disconnect the LH temperature blend door actuator electrical connector.
  3. Remove the LH temperature blend door actuator.
  4. To install, reverse the removal procedure.

Scheme 274

Scheme 274: Temperature Blend Door Actuator - RH
Scheme 274: Temperature Blend Door Actuator - RH

Note. The RH temperature blend door actuator can be accessed from below the RH side of the instrument panel.

  1. Disconnect the RH temperature blend door actuator electrical connector.
  2. Remove the 2 RH temperature blend door actuator screws.
  3. Remove the RH temperature blend door actuator.
  4. To install, reverse the removal procedure.

Scheme 275

Scheme 275: Mode Door Actuator - Air Inlet Door
Scheme 275: Mode Door Actuator - Air Inlet Door

Note. The air inlet door mode door actuator can be accessed from below the RH side of the instrument panel.

  1. Disconnect the air inlet door mode door actuator electrical connector.
  2. Remove the 3 air inlet door mode door actuator screws.
  3. Remove the air inlet door mode door actuator.
  4. To install, reverse the removal procedure.

Scheme 276

Scheme 276: Mode Door Actuator - Defrost/Panel/Floor Door
Scheme 276: Mode Door Actuator - Defrost/Panel/Floor Door

Note. The defrost/panel/floor mode door actuator can be accessed from below the LH side of the instrument panel.

  1. Remove the 3 defrost/panel/floor door mode door actuator screws.
  2. Disconnect the defrost/panel/floor door mode door actuator electrical connector.
  3. Remove the defrost/panel/floor door mode door actuator.
  4. To install, reverse the removal procedure.
