Inspection and Verification
- Verify the customer concern by operating the system.
- Visually inspect for obvious signs of mechanical or electrical damage.
- If an obvious cause for an observed or reported concern is found, correct the cause before proceeding to the next step.
- If the concern is not visually evident, verify the symptom. GO to «SYMPTOM CHART»(ref-233016-S31278439712006052400000) . VISUAL INSPECTION Mechanical Electrical Transmission shift cable Manual control lever Transmission control module out of adjustment (6-speed transaxle) Fuse: C34 (30A) C18 (10A) Connections Wiring harness Brake pedal position (BPP) switch Shift lock actuator
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| Shift interlock system does not release/lock correctly | Circuitry open/shorted Fuse(s) Stoplight switch | GO to PINPOINT TEST A . |
| Shift interlock system does not release/lock correctly | Shift lock actuator | INSTALL a new shifter assembly. REFER to SELECTOR LEVER CABLE . |
| Shift control linkage is out of correct gear relationship | Shift linkage out of adjustment | REFER to SELECTOR LEVER CABLE ADJUSTMENT . |
| Loose shift cable bracket | CHECK the shift cable bracket. Tighten as necessary. |
