GENERAL SPECIFICATIONS CHART
| Item | Specification |
|---|---|
| Fluid | |
| CAUTION: MERCON®, MERCON®V, MERCON®SP, Motorcraft Premium Automatic Transmission Fluid and Motorcraft Continuously Variable Chain Type Transmission Fluid are not interchangeable transmission fluids. The use of any fluid other than what is recommended for this transmission will cause transmission damage. Refer to the Owner/Schedule Maintenance Guide to determine the correct service interval for the specific vehicle. | |
| CAUTION: Do not use water-based cleaners to clean or flush the cooler tubes or transmission damage will occur. Mineral spirits can be used to clean the cooler tubes, providing the cooler tubes are flushed with clean automatic transmission fluid and blown dry with shop air. Use only clean automatic transmission fluid designated for the transmission and torque converter being serviced. | |
| Motorcraft Premium Automatic Transmission Fluid XT-8-QAW (US); CXT-8-LAW12 (Canada) | WSS-M2C924-A |
| Fluid Capacities | |
| All | 7.0L (7.4 quarts) |
| Fluid Filter | |
| Internal to the transmission | |
| Lubricants | |
| Multi-Purpose Grease XG-4 and/or XL-5 | ESB-M1C93-B |
| Threadlock and Sealer TA-25 | WSK-M2G351-A5 |
| Torque Converter End Play | |
| New or rebuilt | 0.355--1.04 mm (0.014--0.041 inch) |
| Used | 0.355--1.87 mm (0.014--0.074 inch) |
| CAUTION |
|---|
| MERCON®, MERCON®V, MERCON®SP, Motorcraft Premium Automatic Transmission Fluid and Motorcraft Continuously Variable Chain Type Transmission Fluid are not interchangeable transmission fluids. The use of any fluid other than what is recommended for this transmission will cause transmission damage. Refer to the Owner/Schedule Maintenance Guide to determine the correct service interval for the specific vehicle. |
| CAUTION |
|---|
| Do not use water-based cleaners to clean or flush the cooler tubes or transmission damage will occur. Mineral spirits can be used to clean the cooler tubes, providing the cooler tubes are flushed with clean automatic transmission fluid and blown dry with shop air. Use only clean automatic transmission fluid designated for the transmission and torque converter being serviced. |
GENERAL SPECIFICATIONS CHART
ENGINE RPM SPECIFICATION
| Engine | RPMs |
|---|---|
| 3.0L | 2,390 |
ENGINE RPM SPECIFICATION
TORQUE SPECIFICATIONS CHART
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| Transmission fluid pan bolts | 13 | 10 | |
| Transmission fluid drain plug | 47 | 35 | |
| Transmission fluid fill plug | 39 | 29 | |
| Transmission control module | 24 | 18 | |
| Transmission fluid temperature sensor | 10 | 89 | |
| Main control bolts | 10 | 89 | |
| Starter bolts | 26 | 19 | |
| Starter B+ cable | 12 | 9 | |
| Starter cable (small) | 5 | 44 | |
| Ground wire bolt | 12 | 9 | |
| Torque converter nuts | 36 | 27 | |
| Upper transaxle-to-engine retaining bolts | 40 | 30 | |
| Transaxle-to-engine retaining bolts | 40 | 30 | |
| Manual control lever nut | 12 | 9 | |
| Transmission fluid cooler tubes | 10 | 89 | |
| Transaxle roll restrictor (1) | 55 | 41 | |
| Transaxle roll restrictor brace (1) | 55 | 41 | |
| Upper roll restrictor | 48 | 35 | |
| Shift cable bracket bolts | 25 | 18 | |
| Catalytic converter bracket bolts | 40 | 30 | |
| Catalytic converter bolts | 40 | 30 | |
| Exhaust pipe bolts and nuts | 40 | 30 | |
| Engine knock sensor (KS) | 10 | 89 | |
| Transmission fluid cooler tube bracket | 10 | 89 | |
| Subframe bolts | 90 | 66 | |
| Subframe bracket bolts | 48 | 35 | |
| Rear transaxle mount-to- transaxle bolts (1) | 55 | 41 | |
| Rear transaxle mount-to-subframe bolts | 90 | 66 | |
| Rear motor mount nut | 70 | 52 | |
| Front motor mount | 70 | 52 | |
| Lower stabilizer mount bolt | 70 | 52 | |
| Power steering bolts | 133 | 98 | |
| Power steering line retaining bolts | 7 | 62 | |
| Stabilizer link nuts | 55 | 41 | |
| (1) When reinstalling fasteners originally coated with Loctite, clean the fasteners with a wire brush prior to applying new Loctite. Apply threadlock and sealer to threads of the bolt. | |||
| (1) | When reinstalling fasteners originally coated with Loctite, clean the fasteners with a wire brush prior to applying new Loctite. Apply threadlock and sealer to threads of the bolt. |
TORQUE SPECIFICATIONS CHART
Torque Demand
The torque demand downshift occurs (automatically) during part throttle acceleration when the demand for torque is greater than the engine can provide at that gear ratio. If applied, the transmission will disengage the torque converter clutch (TCC) to provide added acceleration.
Torque Converter Control
Based on output rpm signals, signals from the engine control unit (engine rpm and throttle opening) and vehicle speed, a smooth engagement is carried out through linear control of the torque converter clutch (TCC) solenoid. Also, the slip rate is detected by adding input rpm signals and slip control is carried out.
- Engagement Control - control is carried out using a TCC solenoid. The TCC solenoid is linearly turned ON and OFF. The clutch inside the torque converter is operated and the pump impeller and turbine runner are connected. Through this the engine and the transaxle are coupled and engine output is connected directly to the transaxle, eliminating transaxle loss and enhancing fuel economy
- Slip Control - control is carried out using a TCC solenoid. The TCC solenoid is linearly turned ON and OFF and the clutch within the torque converter is operated outside of the engagement range. The clutch slides without being in a completely coupled condition, increasing transaxle efficiency and enhancing fuel economy.
Torque Converter
The torque converter transmits and multiplies torque by means of automatic transmission fluid inside the torque converter. The torque converter is composed of the following
- Converter case
- Pump impeller assembly
- Turbine assembly
- Stator assembly/one-way clutch
- Lock-up clutch
In addition, the use of the lock-up clutch is intended to improve fuel economy as a direct coupling between the engine and the transmission.
The standard torque converter components operate as follows
Scheme 1
- Rotation of the converter housing and impeller sets the fluid in motion.
- The turbine reacts to the fluid motion from the impeller, transferring rotation to the geartrain through the input shaft.
- The reactor redirects fluid going back into the impeller, providing for torque multiplication.
- The clutch and damper assembly dampens powertrain torsional vibration and provides a direct mechanical connection for improved efficiency.
- Power is transmitted from the torque converter to the planetary gearsets and other components through the input shaft.
Fluid Leakage in Torque Converter Area
Leakage at the front of the transmission, as evidenced by fluid around the torque converter housing part of the case, may have several sources. By careful observation it is possible, in many instances, to pinpoint the source of the leak before removing the transmission from the vehicle. The paths which the fluid takes to reach the bottom of the torque converter housing are shown in the illustration. The 5 numbers in the illustration correspond with the 5 flow path steps.
Scheme 2
Torque Converter Clutch Operations Concerns: Does Not Apply
| Possible Component | Reference/Action |
|---|---|
| 240 - ROUTINE | |
| Torque Converter Does Not Apply | |
| Damaged or malfunctioning solenoid | Carry out pinpoint test. Refer to PINPOINT TESTS - NON OSC EQUIPPED VEHICLE . Install a new main control valve body. Refer to MAIN CONTROL VALVE BODY . |
| Damaged or disconnected wire harness | Inspect wire harness. Check connections to the torque converter clutch (TCC) solenoid. |
| Damaged or malfunctioning torque converter | Install a new torque converter. Refer to TORQUE CONVERTER . |
POSSIBLE COMPONENT AND REFERENCE/ACTION
Torque Converter Clutch Operations Concerns: Cycling/Shutter/Chatters
| Possible Component | Reference/Action |
|---|---|
| 242 - ROUTINE | |
| Torque Converter Cycling, Shudders or Chatters | |
| Damaged or malfunctioning TCC solenoid | Install a new main control valve body. Refer to MAIN CONTROL VALVE BODY . |
| Damaged or disconnected wire harness | Inspect wire harness. Check connections to the torque converter clutch (TCC) solenoid. |
| Damaged or malfunctioning torque converter | Install a new torque converter. Refer to TORQUE CONVERTER . |
POSSIBLE COMPONENT AND REFERENCE/ACTION
- A new or remanufactured torque converter must be installed if one or more of the following statements are true: A torque converter malfunction has been determined based on complete diagnostic procedures. Converter stud(s), impeller hub or bushing are damaged. Discoloration of the torque converter (due to overheating). The torque converter is found to be out of specification when carrying out one of the following torque converter checks: One-Way Clutch Check End Play Check Stator to Turbine Interference Check Stator to Impeller Interference Check Torque Converter Leak Check Evidence of transmission assembly or fluid contamination due to the following transmission or converter failure modes: Major Metallic Failure Multiple Clutches or Clutch Plate Failures Sufficient Component Wear which results in Metallic Contamination
