Automatic Transmission Cooling System: Other Mercury Montego III

Transaxle Cooling

These vehicles are equipped with an external fluid cooler. The cooler is mounted between the engine radiator and the A/C condenser. In operation, transmission fluid travels from the transaxle to the fluid cooler then back to the transaxle. The fluid cooler transfers heat from the transmission fluid to the outside air.

Scheme 578

Scheme 579

Material

MATERIAL SPECIFICATION CHART

Scheme 580

Scheme 581

Note. Refer to the following when adding transmission fluid.

1. The constant variable transmission (CVT) transaxle uses: Motorcraft Continuously Variable Chain Type Transmission Fluid (XT-7-QCFT)
2. The 6-speed transaxle uses: Motorcraft Premium Automatic Transmission Fluid (XT-8-QAW)

Do not mix the fluid together, damage to internal components will result.

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

Scheme 588

Scheme 589

Scheme 590

Scheme 591

Scheme 592

Scheme 593

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-232992) .
2. Remove the 8 retainers for the upper grille opening cover and remove the cover.
3. Remove the 8 retainers for the upper grille opening cover and remove the cover.
4. Remove the LH air deflector push pins. Position the air deflector aside.
5. Remove the RH air deflector push pins. Position the air deflector aside.
6. Remove the bolt from the LH A/C condenser bracket. To install, tighten to 10 Nm (89 lb-in).
7. Remove the bolt from the RH A/C condenser bracket. To install, tighten to 10 Nm (89 lb-in).
8. Carefully lift the A/C condenser off the retaining clips and position the condenser aside.
9. Remove the screw for the cooler tube retainer. To install, tighten to 10 Nm (89 lb-in).
10. Disconnect the fluid cooler hoses from the fluid cooler.
11. Lift the fluid cooler off the retainers and remove the fluid cooler.
12. Remove the fluid fill plug. To install, tighten to 35 Nm (26 lb-ft).
13. Partially fill the transaxle with clean automatic transmission fluid to make up what was lost during the installation of a new transmission fluid cooler. Using the transmission fluid level setting (CVT) procedure, continue filling the transaxle. For additional information, refer to «TRANSAXLE COOLING»(ref-233053-S14269771832006052400000) . 6-speed transaxle
14. Remove the fluid fill plug. To install, tighten to 39 Nm (29 lb-ft).
15. To install, reverse the removal procedure. Fill the transaxle with Motorcraft Premium Automatic Transmission Fluid XT-8-QAW meeting Ford specification WSS-M2C924-A to the specified level. Prior to adding any transmission fluid, make sure that the vehicle is on a level surface. Check the fluid level to determine how much fluid will need to be added. Using a diagnostic tool, monitor the fluid temperature. Make sure that the fluid temperature is within specification. The fluid level should be within the normal operating range on the fluid level indicator.
16. Check the transaxle for correct operation.

MATERIAL SPECIFICATION CHART

Scheme 594

Scheme 595

Note. Refer to the following when adding transmission fluid.

1. The CVT transaxle uses: Motorcraft Continuously Variable Chain Type Transmission Fluid (XT-7-QCFT)
2. The 6-speed transaxle uses: Motorcraft Premium Automatic Transmission Fluid (XT-8-QAW)

Do not mix the fluid together, damage to internal components will result.

Scheme 596

Scheme 597

Scheme 598

Scheme 599

Scheme 600

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-232992) .
2. Disconnect the cooler hoses from the fluid cooler.
3. Disconnect the transmission fluid cooler tubes from the transaxle. To install, tighten to 10 Nm (89 lb-in).
4. Disconnect the wiring harness from the cooler tube.
5. Remove the fluid cooler tube bracket from the transaxle. Remove the fluid cooler tubes. To install, tighten to 10 Nm (89 lb-in).
6. Remove the fluid fill plug. To install, tighten to 35 Nm (26 lb-ft).
7. Partially fill the transaxle with clean automatic transmission fluid to make up what was lost during the installation of a new transmission fluid cooler tube. Using the transmission fluid level setting CVT procedure continue filling the transaxle. For additional information, refer to «TRANSAXLE COOLING»(ref-233053-S14269771832006052400000) .
8. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-232992) .
9. Disconnect the cooler hoses from the fluid cooler.
10. Disconnect the transmission fluid cooler tubes at the transaxle. To install, tighten to 10 Nm (89 lb-in).
11. Disconnect the transmission fluid cooler tube bracket. Remove the fluid cooler tubes. To install, tighten to 10 Nm (89 lb-in).
12. Remove the fluid fill plug. To install, tighten to 39 Nm (29 lb-ft).
13. To install, reverse the removal procedure. Fill the transaxle with Motorcraft Premium Automatic Transmission Fluid XT-8-QAW meeting Ford specification WSS-M2C924-A to the specified level. Prior to adding any transmission fluid, make sure that the vehicle is on a level surface. Check the fluid level to determine how much fluid will need to be added. Using a diagnostic tool, monitor the fluid temperature. Make sure that the fluid temperature is within specification. The fluid level should be within the normal operating range on the fluid level indicator.
14. Check the transaxle for correct operation.
