Inspection and Verification
Verify the condition by operating the accelerator pedal and shaft from idle to wide open-throttle and back again. Check for any resistance in forward travel of the accelerator pedal and shaft or hesitation on return.
If a concern exists, visually inspect all components of the accelerator pedal and shaft. Look for damage or binding of the accelerator cable. Look for obstructions at the throttle body and accelerator pedal and shaft.
For vehicles equipped with speed control, examine the speed control cable. Refer to SPEED CONTROL article.
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| Accelerator pedal is hard to push down or has a rough or sticky feel | Damaged accelerator cable | NOTE: Do not lubricate the accelerator cable. INSTALL a new accelerator cable. REFER to Accelerator Cable - 2.3L or Accelerator Cable - 3.0L (4V) . |
| Accelerator cable | CHECK the accelerator cable for correct installation. | |
| Worn or damaged throttle body | INSTALL a new throttle body. REFER to FUEL CHARGING AND CONTROLS - 2.3L article or FUEL CHARGING AND CONTROLS - 3.0L (4V) article. | |
| Damaged accelerator pedal and shaft | INSTALL a new accelerator pedal and shaft. REFER to Accelerator Pedal and Shaft . | |
| Accelerator pedal shaft lever sticks (does not return freely) | Damaged accelerator cable | INSTALL a new accelerator cable. REFER to Accelerator Cable - 2.3L or Accelerator Cable - 3.0L (4V) . |
| Accelerator cable | CHECK the accelerator cable for correct installation. | |
| Weak or broken throttle body shaft spring | INSTALL a new throttle body. REFER to FUEL CHARGING AND CONTROLS - 2.3L article or FUEL CHARGING AND CONTROLS - 3.0L (4V) article. | |
| Worn or damaged throttle body | INSTALL a new throttle body. REFER to FUEL CHARGING AND CONTROLS - 2.3L article or FUEL CHARGING AND CONTROLS - 3.0L (4V) article. | |
| High engine idle speed | Damaged accelerator cable | INSTALL a new accelerator cable. REFER to Accelerator Cable - 2.3L or Accelerator Cable - 3.0L (4V) . |
| Accelerator cable incorrectly installed | CHECK the accelerator cable for correct installation. | |
| Electrical/mechanical/ vacuum | REFER to the Introduction - Gasoline Engines article. | |
| Idle air control (IAC) valve | INSTALL a new IAC. REFER to ELECTRONIC ENGINE CONTROLS - 2.3L article or ELECTRONIC ENGINE CONTROLS - 3.0L (4V) article. |
| NOTE |
|---|
| Do not lubricate the accelerator cable. |
Symptom Chart
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | W702251 | Accelerator control cover shield screw |
| 2 | Pin-type retainer (part of 9E766) | |
| 3 | 9E766 | Accelerator control cover shield |
| 4 | Accelerator cable-to-throttle body (part of 9A758) | |
| 5 | 9A758 | Accelerator cable |
| 6 | Accelerator cable-to-bracket grommet (part of 9A758) | |
| 7 | Speed control cable-to-throttle body (part of 9A825) | |
| 8 | Speed control cable-to-bracket grommet (part of 9A825) | |
| 9 | W500210 | Accelerator cable bracket bolts (3 required) |
| 10 | 9677 | Accelerator cable bracket |
| 11 | 9A825 | Speed control cable |
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 12 | W520412 | Accelerator cable bracket nut |
| 13 | 9E728 | Accelerator cable bracket |
| 14 | Accelerator cable grommet (part of 9A758) | |
| 15 | Accelerator cable pin-type retainer (part of 9A758) | |
| 16 | 9A758 | Accelerator cable |
| 17 | Accelerator cable to pedal (part of 9A758) |
