Automatic Transmission External Control System - CD4E: Removal & Installation Mercury Mariner II

Automatic Trans 1 illustration ~439 words

REMOVAL AND INSTALLATION

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-292146) article.
  2. Place the floor shift selector level in the (D) position.
  3. Gently pry up to remove the upper shift lever trim ring.
  4. Lift the center console lid and remove the center console compartment tray.
  5. Remove the top finish panel.
  6. Remove the selector lever cable from the gearshift assembly. Disconnect the selector lever cable end from the gearshift lever. Remove the selector lever cable from the bracket.
  7. Remove the 2 grommet nuts for the selector lever cable. To install, tighten to 10 Nm (89 lb-in).
  8. Remove the selector lever cable retainer from the transmission fluid filler tube.
  9. Disconnect the selector lever cable end from the manual lever.
  10. Release the 2 tabs and remove the selector lever cable from the selector lever cable bracket.
  11. To install, reverse the removal procedure. Adjust the selector lever cable after installation. For additional information, refer to «Selector Lever Cable Adjustment»(ref-292225-S35262323702008073100000) .

Scheme 38

Scheme 38: Selector Lever
Scheme 38: Selector Lever
ItemPart NumberDescription
178061A16Trim ring
278044H06Center console compartment tray
378045A76Center console finish panel
47E395Selector lever cable
513A506Wiring harness retainers
614489Selector lever electrical connector
714A459Vehicle wiring harness connector
8070704All wheel drive (AWD) module (AWD vehicles only)
9W705796Center console screw (2 required)
10W713196Selector lever bolt (4 required)
117K004Selector lever assembly

REMOVAL

All vehicles

  1. Place the selector lever in the (D) position.
  2. Gently pry up to remove the upper selector lever trim ring.
  3. Lift the center console lid and remove the center console compartment tray.
  4. Remove the top finish panel.
  5. Remove the selector lever cable from the selector lever assembly. Disconnect the selector lever cable end from the selector lever. Remove the selector lever cable from the bracket.
  6. Disconnect the wiring harness retainers from the selector lever.
  7. Disconnect the electrical connectors from the selector lever. Disconnect the selector lever electrical connector. Remove the vehicle harness connector from the selector lever.
  8. Pull the all wheel drive (AWD) module straight back and remove it from the back of the selector lever.
  9. Remove the 2 screws from the center console.
  10. Remove the 4 bolts and remove the selector lever assembly.

INSTALLATION

All vehicles

  1. Install the selector lever assembly and the 4 bolts. Tighten to 15 Nm (11 lb-ft).
  2. Install the 2 center console screws.
  3. Install the AWD module on to the back of the selector lever.
  4. Connect the electrical connectors to the selector lever. Install the vehicle harness connector on the selector lever. Connect the selector lever electrical connector.
  5. Connect the wiring harness retainers to the selector lever.
  6. Install the selector lever cable on the selector lever assembly. Install the selector lever cable on the bracket. Connect the selector lever cable end.
  7. Install the top finish panel.
  8. Install the center console compartment tray.
  9. Install the upper selector lever trim ring.
  10. Adjust the selector lever cable. For additional information, refer to «Selector Lever Cable Adjustment»(ref-292225-S35262323702008073100000) .
