Control System - HVAC (Full Auto Air Conditioner): Overview Mazda MX-5 NC рестайлинг

Scheme 11

Scheme 12

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION» ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION» ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION» ) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION» ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ) Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION» ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION» ) Female bracket (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY» ) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION» ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ) Fuse box No. 1 Dashboard (See «DASHBOARD REMOVAL/INSTALLATION» )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 13

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION» ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION» ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION» ) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION» ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ) Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION» ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION» ) Female bracket (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY» ) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION» ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ) Fuse box No. 1 Dashboard (See «DASHBOARD REMOVAL/INSTALLATION» )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 14

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION» )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 15

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 16

1. Connect battery positive voltage to blower motor terminal A, ground to terminal B, and then verify that the blower motor operates smoothly. If the operation condition is not normal, replace the blower motor.

Scheme 17

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Disconnect the power MOS FET connector.
4. Remove the power MOS FET as shown in the illustration.
5. Install in the reverse order of removal.
6. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac) )

Scheme 18

1. Verify that the resistance between the terminals of the power MOS FET is as shown in the table. If there is any malfunction, replace the power MOS FET. RESISTANCE REFERENCE Tester lead Resistance (kilohm) (approx. quantity) + - A B 1, 300 A C 1, 300 A D 2.2 B A infinity B C 0.12 B D infinity C A infinity C B 0.12 C D infinity D A 2.2 D B 190 D C 1, 300

Scheme 19

1. Disassemble in the order indicated in the illustration.
2. Assemble in the reverse order of disassembly.
3. Adjust the magnetic clutch clearance. (See «MAGNETIC CLUTCH ADJUSTMENT [FULL-AUTO AIR CONDITIONER]» )

Scheme 20

Scheme 21

1. When removing or installing the bolt, lock the A/C compressor pulley against rotation using the following procedure. CAUTION: When connecting the positive battery cable to the magnetic clutch connector, use a cable with a female terminal of the correct size. Otherwise, load will be applied to the male terminal, resulting in deformation or damage, and poor contact. In addition, the positive battery cable could disconnect from the connector resulting in a short circuit. Apply battery positive voltage to the magnetic clutch terminal and connect the A/C compressor body to the ground. Wrap the drive belt, which is no longer of use, tightly around the A/C compressor pulley. Hold the drive belt in place with pliers. Remove or install the bolt. Tightening torque 11.8-14.7 N.m {1.21-1.49 kgf.m, 8.7-10.8 ft.lbf}

Scheme 22

1. Remove the snap ring using a snap ring pliers.

Scheme 23

Scheme 24

1. Remove the A/C compressor pulley using the SST (49 0839 425C) . CAUTION: Be careful that the SST (49 0839 425C) tabs do not hang over the stator.

Scheme 25

1. Align the positioning pin with the hole of A/C compressor body and insert.

Scheme 26

1. Install the inner wheel of the pulley using a plastic hammer and SST (49 B018 003) to the compressor. CAUTION: If the SST is not properly positioned when the A/C compressor pulley is press-fit, the A/C compressor axle will interfere with the SST, possibly damaging component parts. Verify that the SST and axle are properly positioned and perform the procedure very carefully.

Scheme 27

1. First, insert the 1 mm (0.039 in) thick shim into the shaft.

Scheme 28

1. Measure the clearance around the entire circumference between the pressure plate and A/C compressor pulley using a thickness gauge.
2. Inspect the clearance. If not within the specification, adjust the clearance by changing the shim or the number of shims. Magnetic clutch clearance 0.3-0.6 mm {0.012-0.023 in}

Scheme 29

Scheme 30

1. Connect battery positive voltage to magnetic clutch terminal A and ground.
2. Verify that the magnetic clutch turns on. If the magnetic clutch does not turn on, replace the A/C compressor.

Scheme 31

1. Remove the battery cable.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Pry the solar radiation sensor from the dashboard using a flathead screwdriver wrapped with protective tape.
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 32

1. Shine a fluorescent light or expose the solar radiation sensor to natural sunlight.
2. Connect the positive (+) lead to terminal A and negative (-) lead to terminal B of the solar radiation, and verify that the voltage value is output. If the voltage is 0 V , replace the solar radiation sensor.

Scheme 33

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove the under cover.
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 34

1. Measure the temperature around the ambient temperature sensor and measure the resistance between the ambient temperature sensor terminal. If the characteristics of the ambient temperature sensor are not as shown in the graph, replace the ambient temperature sensor.

Scheme 35

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» )
3. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION» )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 36

Scheme 37

1. Measure the temperature around the passenger compartment temperature sensor and measure the resistance between passenger compartment temperature sensor terminal. If the characteristics of the passenger compartment temperature sensor are not as shown in the graph, replace the passenger compartment temperature sensor.
2. Connect battery positive voltage to passenger compartment temperature sensor terminal A and connect terminal C to ground to verify fan operation. If there is any malfunction, replace the passenger compartment temperature sensor.
