Control System - HVAC (Full Auto Air Conditioner): Removal & Installation Mazda MX-5 NC рестайлинг

Automatic HVAC System 3 illustrations ~137 words

EVAPORATOR TEMPERATURE SENSOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]

  1. Remove the evaporator temperature sensor from the A/C unit. (See «A/C UNIT DISASSEMBLY/ASSEMBLY»(ref-430356-S41095230472011101700000) )

Refrigerant Pressure Switch Installation Note

  1. Apply compressor oil to the O-ring joints.

Scheme 42

Scheme 42: REFRIGERANT PRESSURE SWITCH INSPECTION [FULL-AUTO AIR CONDITIONER]
Scheme 42: REFRIGERANT PRESSURE SWITCH INSPECTION [FULL-AUTO AIR CONDITIONER]

Scheme 43

Scheme 43
Scheme 43
  1. Connect the manifold gauge.
  2. Verify the high-pressure side reading.
  3. Disconnect the refrigerant pressure switch connector.
  4. Verify continuity between the terminals of the refrigerant pressure switch. If the continuity is not normal, replace the refrigerant pressure switch.

Scheme 44

Scheme 44: CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
Scheme 44: CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) )
  4. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) )
  5. Remove the climate control unit from the center panel unit.
  6. Install in the reverse order of removal.
