Basic System (HVAC): Overview Mazda MX-5 NC рестайлинг

Automatic HVAC System 9 illustrations ~580 words

Scheme 45

Scheme 45: HVAC BASIC SYSTEM LOCATION INDEX

Scheme 46

Scheme 46: A/C UNIT REMOVAL/INSTALLATION

Scheme 47

Scheme 47
  1. Remove battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]».)
  3. Discharge the refrigerant from the system. (See «REFRIGERANT RECOVERY»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-recovery) .) (See «REFRIGERANT CHARGING»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-charging) .)
  4. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [LF]».)
  5. Disconnect from A/C unit in the order in the chart. CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  6. Remove the A/C unit and air Distribution (Dist) unit. (See «AIR DIST UNIT REMOVAL/INSTALLATION».)
  7. Disassembly the A/C unit as shown in the illustration.
  8. Install in the reverse order of removal.
  9. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac) .)
  10. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [LF]».)

Scheme 48

Scheme 48: A/C UNIT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in illustration. CAUTION: If a non-specified grease is used, it may result in abnormal noise or improper operation of the links. Apply only the specified grease to each link. If the air mix damper is removed and reinstalled improperly because the original installation position cannot be specified, the air mix damper and air mix actuator may be damaged when it is operated. Therefore, set the air mix to the middle position before disassembling so that the installation position can be specified.
  2. Assemble in the reverse order of disassembly.

Scheme 49

Scheme 49: Evaporator Temperature Sensor Assembly Note
  1. Assemble the evaporator temperature sensor as shown in the illustration.

Scheme 50

Scheme 50: AIR DIST UNIT REMOVAL/INSTALLATION

Scheme 51

Scheme 51

Scheme 52

Scheme 52
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]».)
  3. Discharge the refrigerant from the system. (See «REFRIGERANT RECOVERY»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-recovery) .) (See «REFRIGERANT CHARGING»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-charging) .)
  4. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [LF]».)
  5. Disconnect from A/C unit in the order in illustration. CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  6. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION».) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Knee bolster Column cover (See «COLUMN COVER REMOVAL/INSTALLATION».) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION».) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) Meter hood (See «METER HOOD REMOVAL/INSTALLATION».) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION».) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Female bracket (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY».) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Fuse box No. 1 Dashboard (See «DASHBOARD REMOVAL/INSTALLATION».)
  7. Remove the air Dist unit and A/C unit.
  8. Disassemble the air Dist unit as shown in the illustration.
  9. Install in the reverse order of removal.
  10. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(/mazda/mx-5/nc-2008-2015/remont/automatic-hvac-system/#refrigerant-system-hvac) .)
  11. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [LF]».)

Scheme 53

Scheme 53: AIR DIST UNIT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in illustration. CAUTION: If a non-specified grease is used, it may result in abnormal noise or improper operation of the links. Apply only the specified grease to each link.
  2. Assemble in the reverse order of disassembly.
