Exterior Trim: Overview Mazda MX-5 NC рестайлинг

Scheme 54

Scheme 55

Scheme 56

1. Remove the wiper arm and blade. (See «WIPER ARM AND BLADE REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/wiperwasher-systems/#washer-system-wiper-system) )
2. Remove the covers.
3. Remove the screws.
4. Remove windshield washer hose from cowl grille.
5. Remove the weatherstrip.
6. Pull the cowl grille in the direction of arrow (1) so that it is free from the pins, pull tabs A in the direction of arrow (2), and then remove the windshield.
7. Remove the cowl grille.
8. Install in the reverse order of removal.

Scheme 57

1. Remove the wiper arm and blade. (See «WIPER ARM AND BLADE REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/wiperwasher-systems/#washer-system-wiper-system) )
2. Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION» )
3. Remove the fasteners.
4. Remove the side cowl grill.
5. Install in the reverse order of removal.

Scheme 58

1. Remove the fasteners.
2. Pull the side step molding and remove clips A from the body.
3. Slide the side step molding to the vehicle rear and remove clips B and C from the side step molding.
4. Remove the side step molding.
5. Remove clips B and C from the body, then install it to the side step molding.
6. Install in the reverse order of removal.

See also:
• WIPER ARM AND BLADE REMOVAL/INSTALLATION
