Interior Trim: Removal & Installation Mazda MX-5 NC рестайлинг

SIDE WALL REMOVAL/INSTALLATION

Note. The removal procedure is the same for the driver's side.

Scheme 14

Scheme 15

1. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) )
2. Remove the screws.
3. Detach hook A, tab B, D and clip C while pulling the side wall.
4. Remove the side wall.
5. Install in the reverse order of removal.

Scheme 16

1. Pull the side panel outward and detach clips A.
2. Pull the side panel rearward and detach tab B from the dashboard.
3. Remove the side panel.
4. Install in the reverse order of removal.

Scheme 17

1. Remove the scuff plate. (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) )
2. Remove the seaming welt.
3. Remove the fastener.
4. Pull the front side trim toward you, then disengage clip A and pin B from the body.
5. Remove the front side trim.
6. Install in the reverse order of removal.

Scheme 18

1. Remove the female wedge. (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY»(ref-430307-S36837664932011101700000) )
2. Pull the A-pillar trim, then disengage clip A, B and tab C.
3. Pull the A-pillar trim upward, then disengage tabs D from the body.
4. Remove the A-pillar trim.
5. Install in the reverse order of removal.

Scheme 19

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) )
2. Remove the partition board. (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) .
3. Remove the fasteners.
4. Remove the trunk side trim.
5. Install in the reverse order of removal.

Scheme 20

1. Remove the fasteners.
2. Pull the trunk end trim upward, then disengage pin A.
3. Disconnect the trunk compartment light connector.
4. Disconnect the trunk rid cancel switch connector.
5. Remove the trunk end trim.
6. Install in the reverse order of removal.

Scheme 21

1. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-430296-S25778296992011101700000) )
2. Remove the screws.
3. Remove the knee bolster.
4. Install in the reverse order of removal

Scheme 22

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .
3. Remove the selector lever knob (AT), shift lever knob (MT).
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 23

1. Disassemble in the order indicated in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 24

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) )
4. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) )
5. Remove the screws.
6. Pull the console panel outward and detach tabs A and pins B.
7. Disconnect the seat warmer switch connector. (Vehicles with seat warmer)
8. Disconnect the accessory socket connector.
9. Disconnect the auxiliary jack connector.
10. Remove the console panel.
11. Install in the reverse order of removal.

Scheme 25

1. Pull the decoration panel outward and detach clips A.
2. Remove the decoration panel.
3. Install in the reverse order of removal.

Scheme 26

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) )
4. Remove the three screws.
5. Pull the decoration panel outward and detach clips A and B.
6. Remove the decoration panel.
7. Install in the reverse order of removal.

Removal

Scheme 27

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the female wedge. (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY»(ref-430307-S36837664932011101700000) )
4. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-430298-S35034928232011101700000) )
5. Remove the A-pillar trim. (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-430296-S17095533582011101700000) )
6. Remove the screws.
7. Pull the front header trim toward you, then disengage the clips A and pin B from the body.
8. Remove the front header trim.

Installation

Scheme 28

1. Install the pin A and clip B.
2. Pull down the sunvisor on the right, then install pin C and clips D.
3. Pull down the sunvisor on the left, then install pin E and clips F.
4. Install the screw.
5. Install the A-pillar trim. (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-430296-S17095533582011101700000) )
6. Install the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-430298-S35034928232011101700000) )
7. Install the female wedge. (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY»(ref-430307-S36837664932011101700000) )
8. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
9. Install the battery cover.

SCUFF PLATE REMOVAL/INSTALLATION

Scheme 29

1. Pull the scuff plate upward while detaching tabs C, and then detach clips A and D, and pins B, E from the body, and remove the scuff plate.
2. Install in the reverse order of removal.

Scheme 30

1. Remove the quarter trim. (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) )
2. Remove the scuff plate. (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) )
3. Remove the fasteners.
4. Pull the tire house trim outward and detach clips A.
5. Remove the tire house trim.
6. Install in the reverse order of removal.

Scheme 31

1. Remove the fastener.
2. Remove the tabs A.
3. Pull the quarter trim upward and clips B.
4. Remove the seat belt from the quarter trim through the slit in the quarter trim and remove the quarter trim.
5. Install in the reverse order of removal.

Scheme 32

Scheme 33

Scheme 34

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Affix protective tape to the location in the illustration.
4. Move the hook A in the direction of arrow shown in the illustration using a tape-laped flathead screwdriver and detach it from the door trim.
5. Remove the assist handle cover.
6. Remove the cover.
7. Remove the screws.
8. Detach clips B from the door trim using fastener remover.
9. Pull the door trim upward and detach tabs C from the door.
10. Disconnect the tweeter connector.
11. Disconnect the power outer mirror switch connector, (driver's side)
12. Remove the inner handle cover.
13. Remove the door trim.
14. Install in the reverse order of removal.

Scheme 35

1. Disassemble in the order indicated in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 36

1. Insert a tape-wrapped flathead screwdriver into the service hole.
2. Twist the flathead screwdriver as indicated by the arrow to remove the clips A and tab B.
3. Remove the aeroboard.
4. Install in the reverse order of removal.

Scheme 37

Scheme 38

1. Pull the front seat back bar garnish outward and detach tabs A and pins B.
2. Remove the front seat back bar garnish.
3. Remove the screws.
4. Pull the rear seat back bar garnish upward and detach clips A.
5. Remove the rear seat back bar garnish.
6. Install in the reverse order of removal.

Scheme 39

Scheme 40

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) )
2. Pull the open hook lever outward and remove it while pinching the tabs as shown in the illustration (except the power retractable hardtop).
3. Remove the fasteners.
4. Pull the back trim outward and detach clips A and B.
5. Remove the back trim.
6. Install in the reverse order of removal.

Scheme 41

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) )
2. Remove the fasteners.
3. Slide the seat back bar lower garnish to the vehicle rear and detach clips A and pin B.
4. Remove the seat back bar lower garnish.
5. Install in the reverse order of removal.

Scheme 42

Scheme 43

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Roof hook (See «ROOF HOOK REMOVAL/INSTALLATION»(ref-430307-S42847850202011101700000) )
2. Remove the clip A.
3. Remove the roof stopper.
4. Remove the fasteners.
5. Slide the seat back bar lower garnish to the vehicle rear and detach clips B and pin C.
6. Remove the seat back bar lower garnish.
7. Install in the reverse order of removal.

Scheme 44

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) )
2. Remove the fasteners.
3. Remove the pins A and B.
4. Remove the rear package trim.
5. Install in the reverse order of removal.

Scheme 45

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) )
2. Remove the fasteners.
3. Pull the rear side trim outward and detach pin A, B and tab C.
4. Remove the rear side trim.
5. Install in the reverse order of removal.

Scheme 46

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) )
2. Disconnect the power retractable hardtop drain hose. (See «POWER RETRACTABLE HARDTOP DRAIN HOSE REMOVAL/INSTALLATION»(ref-430307-S27329590662011101700000) )
3. Remove the fasteners.
4. Remove the clip A and pin.
5. Remove the rear side trim.
6. Install the reverse order of removal.

Scheme 47

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) ) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-430296-S26289501072011101700000) )
2. Remove the fasteners.
3. Pull the side shelf outward and detach clip A.
4. Remove the side shelf.
5. Install in the reverse order of removal.

Scheme 48

1. Fully open the deck panel.
2. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) )
3. Remove the fasteners.
4. Pull the side shelf outward and detach clip A.
5. Remove the side shelf.
6. Install in the reverse order of removal.

Scheme 49

1. Remove the fasteners.
2. Remove the partition board.
3. Install in the reverse order of removal.

Scheme 50

1. Remove the fasteners.
2. Remove the trunk mat.
3. Remove the seal fasteners.
4. Install in the reverse order of removal.

Scheme 51

Scheme 52

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Seat (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) ) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) ) Foot rest Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) )
4. Cut away the floor covering as shown in the illustration. NOTE: The cut part needs to match up when installing the floor covering.
5. Remove the fasteners A and B.
6. Remove the floor covering.
7. Install in the reverse order of removal.

Scheme 53

1. Fully open the deck panel.
2. Remove the side shelf. (See «SIDE SHELF REMOVAL/INSTALLATION»(ref-430296-S33668404262011101700000) )
3. Remove the stoppers.
4. Remove the fasteners.
5. Remove the rear floor covering.
6. Install in the reverse order of removal.
