Interior Trim: Overview Mazda MX-5 NC рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) ) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-430296-S25778296992011101700000) ) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-430296-S09121117682011101700000) ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) ) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S13032094912011101700000) ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-430298-S03665070312011101700000) ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-430296-S15633193382011101700000) ) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-430312-S33964143232011101700000) ) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-430296-S24557577942011101700000) ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-430313-S32529974172011101700000) ) Female wedge (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY»(ref-430307-S36837664932011101700000) ) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-430296-S17095533582011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) ) Fuse box No. 1
4. Disconnect the dashboard wiring harness connectors.
5. Remove in the order indicated in the illustration.
6. Install in the reverse order of removal.

Scheme 6

1. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-430296-S14460807182011101700000) ) Hazard warning switch (See «HAZARD WARNING SWITCH REMOVAL/INSTALLATION»(ref-430298-S01218194882011101700000) ) Center speaker cover (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-430309-S10571967122011101700000) ) Center speaker (vehicles with Bose®) (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-430309-S10571967122011101700000) ) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S38081106132011101700000) )
2. Disassemble in the order indicated in the illustration.
3. Assemble in the reverse order of disassembly.

Scheme 7

1. Remove the tab A, then remove the upper column cover.
2. Remove the screws, then remove the lower column cover.
3. Remove the ignition key illumination. (See «IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-430298-S02075100872011101700000) )
4. Install in the reverse order of removal.

Scheme 8

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Pull the meter hood upward and detach clips A.
4. Disconnect the microphone connector. (See «MICROPHONE REMOVAL/INSTALLATION»(ref-430309-S19156620022011101700000) )
5. Remove the meter hood.
6. Install in the reverse order of removal.

Scheme 9

1. Remove the dumper clip.
2. Bend the stoppers inward, then remove.
3. Turn the glove compartment downward and pull the pins.
4. Remove the glove compartment.
5. Install in the reverse order of removal.

Scheme 10

1. Pull the lower panel outward and detach clips A and tab B.
2. Turn the lower panel downward and remove the tabs C.
3. Remove the lower panel.
4. Install in the reverse order of removal.

Scheme 11

1. Remove the decoration panel, (driver's side) (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-430296-S14460807182011101700000) )
2. Remove the screws.
3. Remove the ventilator grille.
4. Install in the reverse order of removal.

Scheme 12

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) ) Decoration panel (passenger's side) (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-430296-S14460807182011101700000) )
4. Remove the screws.
5. Remove the ventilator grille.
6. Install in the reverse order of removal.

Scheme 13

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) ) Decoration panel (passenger's side) (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-430296-S14460807182011101700000) )
4. Remove the screws.
5. Remove the ventilator grille.
6. Install in the reverse order of removal.
