Security System and Locks System (Advanced Keyless System): Removal & Installation Mazda MX-5 NC

DOOR KEY CYLINDER REMOVAL/INSTALLATION

1. Remove the following parts: Door trim (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-244480-S17210560282006092400000) .) Door glass (See «DOOR GLASS REMOVAL/INSTALLATION»(ref-244534-S12792454742006092400000) .) Door speaker (See «DOOR SPEAKER REMOVAL/INSTALLATION»(ref-244490-S37574542912006092400000) .) Door unit (See «DOOR UNIT REMOVAL/INSTALLATION»(ref-244533-S22744253902006092400000) .) Outer handle (See «OUTER HANDLE REMOVAL/INSTALLATION»(ref-244491-S37642494722006092400000) .)
2. Detach the door key cylinder rod.
3. Turn the door key cylinder so that the tab is aligned with the notch.
4. Remove the door key cylinder by pulling it out from the front door.
5. Install in the reverse order of removal.

DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION

1. Remove the following parts: Door trim (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-244480-S17210560282006092400000) .) Door glass (See «DOOR GLASS REMOVAL/INSTALLATION»(ref-244534-S12792454742006092400000) .) Door speaker (See «DOOR SPEAKER REMOVAL/INSTALLATION»(ref-244490-S37574542912006092400000) .) Door unit (See «DOOR UNIT REMOVAL/INSTALLATION»(ref-244533-S22744253902006092400000) .)
2. Detach the cables from the inner handle and the door lock knob.
3. Detach the rods from the key cylinder and the outer handle.
4. Remove the screws, then remove the door latch and lock actuator.
5. Install in the reverse order of removal.

DOOR LOCK STRIKER REMOVAL/INSTALLATION

1. Remove the screws, and then remove the door lock striker.
2. Install in the reverse order of removal.
3. Adjust the door. (See «DOOR ADJUSTMENT»(ref-244533-S29857404312006092400000) .)

RH

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-244480-S17210560282006092400000) .)
3. Remove the screws, then remove the door lock switch.
4. Install in the reverse order of removal.

Scheme 28

Scheme 29

1. Inspect for continuity between the door lock switch terminals. If not as specified, replace the door lock switch.

Scheme 30

1. To remove the fuel-filler lid opener, remove the trunk side trim (LH). (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244480-S21785645352006092400000).)
2. When removing the fuel-filler lid opener lever and cable, perform the following procedure: Remove the seats. (See «SEAT REMOVAL/INSTALLATION»(ref-244525-S19284171462006092400000).) Remove the back trim. (See «BACK TRIM REMOVAL/INSTALLATION»(ref-244480-S05269527192006092400000).) Remove the seat back bar lower garnish. (See «SEAT BACK BAR LOWER GARNISH REMOVAL/INSTALLATION»(ref-244480-S22542033022006092400000).)
3. Remove in the order indicated in (Scheme 34).
4. Install in the reverse order of removal.
5. Adjust the fuel-filler lid. (See «FUEL-FILLER LID ADJUSTMENT»(ref-244484-S27806244732006092400000).)

Scheme 31

1. Remove in the order indicated in (Scheme 35).
2. Install in the reverse order of removal.
3. Adjust the hood. (See «HOOD ADJUSTMENT»(ref-244484-S12985612862006092400000).)

Scheme 32

1. Pull the lever.
2. While pushing the tab in the direction of the arrow using a tape-wrapped, small flathead screwdriver, detach it from the dashboard. CAUTION: Remove the hood release lever while taking care not to damage the hood release cable with the flathead screwdriver.
3. Under the condition in Step 2 , pull the hood release lever outward, then remove it from the dashboard.

Scheme 33

1. Remove the bolt, then remove the hood striker.
2. Install in the reverse order of removal.

Scheme 34

1. Open the hood.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Disconnect the hood latch switch connector.
4. Inspect for continuity between the hood latch switch terminals A and B. If there is no continuity, replace the hood latch switch.
5. Lock the hood latch using a flathead screwdriver or equivalent (Scheme 39)
6. Inspect for continuity between the hood latch switch terminals A and B If there is continuity, replace the hood latch. CAUTION: After the inspection, unlock the hood latch. If closing the hood with the hood latch locked, the hood latch and/or hood striker may be broken.

TRUNK LID OPENER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244480-S41692017792006092400000) .)
3. Detach the rod.
4. Disconnect the trunk lid opener connector and the trunk compartment light connector.
5. Remove the bolts, then remove the trunk lid opener.
6. Install in the reverse order of removal.

Scheme 35

1. Apply battery positive voltage and connect the ground to the corresponding the trunk lid opener terminals, and inspect the trunk lid opener operation. If the trunk lid opener does not operate as indicated in «TRUNK LID OPENER INSPECTION DESCRIPTION TABLE»(ref-244491-S31465478282006092400000) , replace the trunk lid opener.

TRUNK LID OPENER OPERATION TABLE

TRUNK KEY CYLINDER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244480-S41692017792006092400000) .)
3. Detach the rod.
4. Remove the nuts, then remove the trunk key cylinder.
5. Install in the reverse order of removal.

Scheme 36

Scheme 37

1. Remove the trunk key cylinder switch.
2. Inspect for continuity between the trunk key cylinder switch terminals. If not as specified, replace the trunk key cylinder.

TRUNK LID OPENER SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Using a small flathead screwdriver, detach the tabs of the trunk lid opener switch from the dashboard.
3. Push the trunk lid opener switch into the dashboard and remove.
4. Disconnect the trunk lid opener switch connector.
5. Install in the reverse order of removal.

Scheme 38

Scheme 39

1. Remove the trunk lid open switch.
2. Inspect for continuity between the trunk lid open switch terminals. If not as specified, replace the trunk lid open switch.

TRUNK LID STRIKER REMOVAL/INSTALLATION

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244480-S41692017792006092400000) .)
2. Remove the bolts, then remove the trunk lid striker.
3. Install in the reverse order of removal.

TRUNK LID OPENER CANCEL SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244480-S41692017792006092400000) .)
3. Squeeze the tabs of the trunk lid opener cancel switch and pull it forward to remove it.
4. Disconnect the trunk lid opener cancel switch connector.
5. Remove the trunk lid opener cancel switch.
6. Install in the reverse order of removal.

Scheme 40

Scheme 41

1. Remove the trunk lid open cancel switch.
2. Inspect for continuity between the trunk lid open cancel switch terminals. If not as specified, replace the trunk lid open cancel switch.

KEYLESS CONTROL MODULE REMOVAL/INSTALLATION

Note. If the keyless control module is replaced, always perform the following procedure. Without immobilizer system Card key programming (See CARD KEY ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM] .) Steering lock unit programming (See STEERING LOCK UNIT ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM] .) With immobilizer system Card key programming (See CARD KEY ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM] .) Steering lock unit programming (See STEERING LOCK UNIT ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM] .) Immobilizer system resetting (with immobilizer system) (See IMMOBILIZER SYSTEM COMPONENT REPLACEMENT/KEY ADDITION AND CLEARING [WITH ADVANCED KEYLESS SYSTEM] .)

Scheme 42

Scheme 43

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the side panel. (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244480-S16982559972006092400000) .)
3. Remove the bolt and nut.
4. While inclining the keyless control module along the body panel in the direction indicated by the arrow, disengage the bracket tab from the hole in the body panel.
5. Disconnect the keyless control module connector.
6. Remove the keyless control module.
7. Remove the screw, then remove the bracket. NOTE: The screw which fixes the keyless control module and bracket is for a body ground connection. Be sure to secure the screw when installing.
8. Install in the reverse order of removal.

KEYLESS BEEPER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244480-S21785645352006092400000) .)
3. Remove the nuts.
4. Disconnect the connector.
5. Remove the keyless beeper.
6. Install in the reverse order of removal.

COIL ANTENNA REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS SYSTEM]

Note. Do not remove the coil antenna unless you are replacing it. When only the coil antenna is replaced, the immobilizer system reprogram procedure is not necessary.

Scheme 44

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
2. Remove the column cover.
3. Remove in the order indicated in see scheme 64.
4. Install in the reverse order of removal.

Scheme 45

1. Install the hole of coil antenna to the tab of steering lock.
2. Install the hook of coil antenna to the steering lock.
