Security System and Locks System (Advanced Keyless System): Other Mazda MX-5 NC

Door Lock Actuator

1. Disconnect the door lock actuator connector.
2. Apply battery positive voltage and connect the ground to the corresponding door lock actuator terminals and inspect the door lock actuator operation. If not as specified, replace the door lock actuator.

ACTUATOR OPERATION TABLE

() :RH

Scheme 46

Scheme 47

Scheme 48

1. Disconnect the door lock actuator connector.
2. Inspect for continuity between the door lock-link switch terminals. If not as specified, replace the door lock actuator.

Scheme 49

Scheme 50

1. Disconnect the door lock actuator connector.
2. Inspect for continuity between the door lock-link switch terminals. If not as specified, replace the door lock actuator.

CARD KEY ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM]

Note. Use the WDS or equivalent and start programming if the condition corresponds to the following: One or No Programmed Card Keys Keyless control module is replaced If six card keys are already programmed, the programming mode does not activate. If programming is needed, use the WDS or equivalent to erase the unnecessary card key programming.

With Two Programmed Card Keys

1. Bring the programmed card keys (2) and a unprogrammed card key into the vehicle.
2. Close all doors.
3. Insert the supplementary key into the ignition key cylinder. NOTE: Complete the procedures up to Step 7 within 30 s after the supplementary key is inserted.
4. Turn the ignition switch to the ON position.
5. Press the UNLOCK button on card key 1.
6. Press the UNLOCK button on card key 2.
7. From the ignition switch in the ON position, switch the ignition switch in the order indicated below. - ACC-->ON-->ACC-->ON-->ACC-->ON
8. Open the driver-side front door, press the door switch twice , and then close the door. NOTE: After Step 3 is completed and the card key programming mode is activated, the door lock actuator operates to lock, and then operates to unlock. If the door lock actuator does not operate, repeat the procedure from Step 2 .
9. Press the UNLOCK button on the unprogrammed card key twice. NOTE: After Step 8 is completed and the card key is programmed, the door lock actuator operates to lock, and then operates to unlock.
10. If programming more card keys, remove the supplementary key once, and then repeat the procedure from Step 2 .

Using WDS or Equivalent

1. Fully lower the driver-side door glass.
2. Connect the WDS or equivalent to the DLC-2.
3. Pull out the WDS or equivalent cable from the door glass opening and set the WDS or equivalent outside the vehicle. CAUTION: Protect the cable and body contact area with a clean rag, otherwise they could be damaged.
4. Select "BODY/SECURITY/PATS (immobilizer)" from the WDS or equivalent screen menu.
5. Security access begins and the WDS or equivalent displays the "OUT-CODE". NOTE: When "OUT-CODE" is first displayed, turning the ignition switch from the LOCK to the ON position 5 times will change the "OUT-CODE".
6. Input the "IN-CODE" that corresponds to the "OUT-CODE" displayed on the WDS or equivalent screen.
7. Select "CARD KEY PROGRAMMING" from the WDS or equivalent screen menu. NOTE: After Step 7 is completed and the card key programming is activated, the door lock actuator operates to lock, and then operates to unlock.
8. Press the unprogrammed card key UNLOCK button twice. NOTE: After Step 8 is completed and the card key is programmed, the door lock actuator operates to lock, and then operates to unlock.
9. If programming more card keys, remove the supplementary key once, and then repeat the procedure from Step 7 by following the instructions on the WDS or equivalent screen.

CLEARING CARD KEY [WITH ADVANCED KEYLESS SYSTEM]

1. Fully lower the driver-side door glass.
2. Connect the WDS or equivalent to the DLC-2.
3. Pull out the WDS or equivalent cable from the door glass opening and set the WDS or equivalent outside the vehicle. CAUTION: Protect the cable and body contact area with a clean rag, otherwise they could be damaged.
4. Select "BODY/SECURITY/PATS (immobilizer)" from the WDS or equivalent screen menu.
5. Security access begins and the WDS or equivalent displays the "OUT-CODE". NOTE: When "OUT-CODE" is first displayed, turning the ignition switch from the LOCK to the ON position 5 times will change the "OUT-CODE".
6. Input the "IN-CODE" that corresponds to the "OUT-CODE" displayed in the WDS or equivalent screen.
7. Select "CARD KEY CLEARING" from the WDS or equivalent screen menu.

STEERING LOCK UNIT ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM]

Note. The steering lock unit and steering lock component are a single unit. Therefore, replace the steering lock component when replacing steering lock unit. (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) For this procedure, a programmed card key is necessary. If there is no programmed card key, perform the steering lock unit programming after the card key programming.

1. Bring the programmed card key into the vehicle.
2. Fully lower the driver-side door glass.
3. Connect the WDS or equivalent to the DLC-2.
4. Pull out the WDS or equivalent cable from the door glass opening and set the WDS or equivalent outside the vehicle.
5. Select "BODY/SECURITY/PATS (immobilizer)" from the WDS or equivalent screen menu.
6. Perform the security access according to the directions on the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .)
7. The security access begins and the WDS or equivalent displays "OUT-CODE". NOTE: When "OUT-CODE" is first displayed, turning the ignition switch from the LOCK to the ON position 5 times will change the "OUT-CODE".
8. Input the "IN-CODE" that corresponds to the "OUT-CODE" displayed on the WDS or equivalent screen.
9. Select "STEERING LOCK UNIT PROGRAMMING" and perform procedures according to the directions on the WDS or equivalent screen.

KEYLESS CONTROL MODULE CONFIGURATION [WITH ADVANCED KEYLESS SYSTEM]

1. Connect the WDS or equivalent to the DLC-2.
2. Select "Module Programming".
3. Select "Configuration/PMI".
4. Select "RKE" and perform procedures according to directions on the screen.

CUSTOMIZED FUNCTION SETTING PROCEDURE [WITH ADVANCED KEYLESS SYSTEM]

1. Connect the WDS or equivalent to the DLC-2.
2. Select "Module Programming".
3. Select "Programming change available parameter/RKE".
4. Select the item name, and than select either "Disable/Enable". Items Automatic Lock Answer Back Buzzer Low Battery Warning

Front

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the glove compartment lid. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-244480-S01520918242006092400000) .)
3. Disconnect the keyless receiver module connector.
4. Remove the nut, then remove the keyless receiver (front).
5. Install in the reverse order of removal.

Rear

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244480-S21785645352006092400000) .)
3. Remove the nuts.
4. Disconnect the connector.
5. Remove the keyless receiver (rear).
6. Install in the reverse order of removal.

Driver-side/passenger-side Door

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-244480-S17210560282006092400000) .)
3. Remove the screws.
4. Disconnect the connector, then remove the keyless antenna.
5. Install in the reverse order of removal.

Exterior, Rear

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the nuts.
3. Disconnect the connector, then remove the keyless antenna.
4. Install in the reverse order of removal.

Scheme 51

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the scuff plate. (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-244480-S39395734462006092400000) .)
3. Remove the side panel. (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244480-S16982559972006092400000) .)
4. Partially peel back the floor covering so that the foot support can be removed.
5. Remove the foot support.
6. Disconnect the connector, then remove the screws.
7. Remove the keyless antenna.
8. Install in the reverse order of removal.

Interior, Middle

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-244480-S13223079142006092400000) .)
3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244480-S26287572182006092400000) .)
4. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-244480-S42244014272006092400000) .)
5. Remove the clips.
6. Disconnect the connector, then remove the keyless antenna.
7. Install in the reverse order of removal.

Interior, Rear

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-244480-S13223079142006092400000) .)
3. Remove the back trim. (See «BACK TRIM REMOVAL/INSTALLATION»(ref-244480-S05269527192006092400000) .)
4. Remove the nuts.
5. Disconnect the connector, then remove the keyless antenna.
6. Install in the reverse order of removal.

Interior, Trunk

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244480-S21785645352006092400000) .)
3. Remove the nuts.
4. Disconnect the connector, then remove the keyless antenna.
5. Install in the reverse order of removal.

Driver-side/passenger-side

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-244480-S17210560282006092400000) .)
3. Remove the outer handle. (See «OUTER HANDLE REMOVAL/INSTALLATION»(ref-244491-S37642494722006092400000) .)
4. Remove the screws A, then remove the handle seat and plate.
5. Remove screw B, then remove the request switch.
6. Install in the reverse order of removal.

Trunk Lid

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
2. Open the trunk lid.
3. Remove the request switch.
4. Install in the reverse order of removal.

Scheme 52

Scheme 53

1. Inspect for continuity between request switch terminals A and B. If not as specified, replace the request switch.

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. Pull out the auxiliary key.
2. Replace the cap using a flathead screwdriver, then rotate and remove the cap. CAUTION: Do not turn the cap excessively. The cap may be damaged.
3. Insert a flathead screwdriver into the crack and press the battery out.
4. Insert the new battery (CR2025) with the positive pole (+) facing the (+) mark on the cap. Battery specification Lithium CR2025 x 1 NOTE: The batteries will last about 1 years when used 10 times a day.
5. Rotate and close the cap.
6. Reinsert the auxiliary key.

Foreword

1. When performing the following procedures, the immobilizer resetting procedure using the WDS or equivalent must also always be performed: "Keyless control module replacement", "PCM replacement", "Steering lock unit replacement", "Keyless control module and PCM joint replacement", "Keyless control module, PCM, and steering lock unit joint replacement", and "Key ID number clearing". The engine will not start unless all work is performed using the WDS or equivalent.
2. A card key that can start the engine is necessary for the key programming. If there is no card key that can start the engine, perform the key programming after the card key programming. (See «CARD KEY ID CODE REGISTRATION [WITH ADVANCED KEYLESS SYSTEM]»(ref-244491-S00847874812006092400000) .)
3. There are two ways to add supplemental key: Using the WDS or equivalent or using two keys that can start the engine to program.
4. When replacing any of the immobilizer system component parts, adding/clearing keys, or performing other functions, refer to «IMMOBILIZER SYSTEM FUNCTION TABLE»(ref-244491-S12305437792006092400000) and perform the applicable procedure (No.1 to 5).
5. Verify that the room fuse is equipped.

IMMOBILIZER SYSTEM FUNCTION TABLE

Note. The "valid key" used in this article indicates the key that can start the engine. If the key adding, programming, clearing, and immobilizer system construction parts replacement are performed, verify that the all keys can start the engine within 5 s after the procedure. When verifying that the engine starts, wait at least 5 s or more before starting the engine using the next key. If the engine cannot be started using a programmed key, repeat the procedure from the beginning. Do not start the engine unless indicated in the procedure. If the engine is started during the programming procedure, programming is stopped at that point. Repeat the procedure starting from the beginning if the engine is started before completion. Do not place the card key in the vehicle or bring it within approx. 1 m of the vehicle unless indicated in the procedure. Two or more key ID numbers must be programmed for the engine to start. A maximum of eight key ID numbers can be programmed for one vehicle. The WDS or equivalent can be used to verify the number of key ID numbers programmed to a single vehicle. Do not select a WDS or equivalent screen menu other than one indicated in the procedure.

WDS or Equivalent Connecting Procedure

1. Fully lower the door glass.
2. Connect the WDS or equivalent to the DLC-2.
3. Pull out the WDS or equivalent cable from the door glass opening and set the WDS or equivalent outside the vehicle.

Scheme 59

No.1 Additional Key Programming Procedure (Using Two Valid Keys)

Condition

1. Have two or more valid keys.

Note. A maximum of eight keys can be programmed for one vehicle. If key programming is not successful and DTC 15 appears even though the procedure was performed properly, use the PID/data monitor function of the WDS or equivalent and verify the number of keys that have been programmed. If eight keys have already been programmed, and it is necessary to program other keys, the previously programmed key ID numbers must first be cleared. To clear the key, refer to NO.3 PCM REPLACEMENT PROCEDURE .

Scheme 60

1. Prepare key 3 for programming.
2. Start the engine using key 1.
3. Verify that the security light illuminates for approx. 3 s , and then goes out.
4. Turn the ignition switch to the LOCK position.
5. Using key 1, turn the ignition switch to the ON position.
6. Verify that the security light illuminates for approx. 3 s , and then goes out.
7. Using key 1, turn the ignition switch to the LOCK position within approx. 4 s after the security light goes out.
8. Remove key 1.
9. Repeat Steps 2 thru 5 using key 2 instead of key 1.
10. Repeat Steps 5 thru 8 using key 3 instead of key 1.
11. If additional keys need to be programmed, repeat Steps 1 thru 10 , and replace key 3 in Step 10 with the key to be programmed (key 4).

1. There is only one valid key. Or, there is no valid key but there is a card key that can start the engine.

Note. A maximum of eight keys can be programmed for one vehicle. If key registration is not successful and DTC 15 appears even though the procedure was performed properly, use the PID/data monitor function of the WDS or equivalent and verify the number of keys that have been programmed. If eight keys have already been programmed, and it is necessary to program other keys, the previously programmed key ID numbers must first be cleared. To clear the key ID number, refer to NO.3 PCM REPLACEMENT PROCEDURE .

Procedure

1. Prepare key 1 for programming.
2. Start the engine using a valid key or card key. CAUTION: Do not place the card key in the vehicle when starting the engine with the valid key, otherwise programming cannot be performed. If the engine is started with the card key, remove the card key from the vehicle after the engine is started.
3. Verify that the security light illuminates for approx. 3 s , and then goes out.
4. Turn the ignition switch to the LOCK position.
5. Connect the WDS or equivalent to the DLC-2. (See «WDS OR EQUIVALENT CONNECTING PROCEDURE»(ref-244491-S21422122692006092400000) .)
6. Using key 1, turn the ignition switch to the ON position. NOTE: Although the security light flashes and DTC 15 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
7. Select "BODY/SECURITY/PATS (immobilizer) function" from the WDS or equivalent screen menu.
8. Select "Ignition key additional programming" from the WDS or equivalent screen menu. NOTE: After selecting the above menu, "operation is successful" is displayed. At this point, the key that turned the ignition switch to the ON position is completely programmed. In this procedure, the necessary number of the keys are completely programmed. To finish the additional key programming, go to Step 13 . If additional keys need to be programmed, go to the next step.
9. Perform the security access according to the directions on the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .)
10. After verifying that the PATS function menu is displayed again on the WDS or equivalent screen, turn the ignition switch to the LOCK position and remove key 1.
11. Using the key to be programmed, turn the ignition switch to the ON position.
12. Return to the Step 6 .
13. After verifying that the PATS function menu is displayed again on the WDS or equivalent screen, select the "Finish (this menu)" to finish the WDS or equivalent procedure.
14. After Step 10 , wait 5 s or more , and then turn the ignition switch to the LOCK position.

1. Have two or more keys to be programmed after the key ID number clearing.

Scheme 61

Scheme 62

1. Prepare two or more keys to be programmed after the key ID number clearing.
2. Connect the WDS or equivalent to the DLC-2. (See «WDS OR EQUIVALENT CONNECTING PROCEDURE»(ref-244491-S21422122692006092400000) .)
3. Using key 1, turn the ignition switch to the ON position. NOTE: Although the security light flashes and DTC 15 or 21 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
4. Verify that the keyless warning light illuminates for approx. 3 s , and then goes out.
5. Select "BODY/SECURITY/PATS (immobilizer) function" from the menu.
6. Perform the security access according to the direction of the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .)
7. Select "Parameter Reset" from the WDS or equivalent screen menu.
8. After verifying that the PATS function menu is displayed again on the WDS or equivalent screen, select "Finish (this menu)" to finish the WDS or equivalent procedure.
9. After Step 8 , wait 5 s or more , and then turn the ignition switch to the LOCK position.
10. Using key 1, turn the ignition switch to the ON position.
11. After verifying that the security light and keyless warning light illuminates for 3 s or more turn the ignition switch to the LOCK position and remove key 1. NOTE: Although the security light flashes and DTC 21 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
12. Using key 2, turn the ignition switch to the ON position.
13. Verify that the security light and keyless warning light illuminates for approx. 3 s , and then goes out.
14. After verifying that the security light goes out, turn the ignition switch to the LOCK position using key 2, and then remove key 2.
15. If an additional key needs to be programmed, repeat Steps 13 thru 14 with the additional key being key 3. If the ignition switch is held in the ON position for 1 min or more , the additional key programming procedure according to Steps 13 thru 14 will not be possible. If this occurs, refer to «NO.1 ADDITIONAL KEY PROGRAMMING PROCEDURE (USING TWO VALID KEYS)»(ref-244491-S36528486592006092400000) to register any additional keys.
16. Start the engine with the key 1.
17. Verify that the security light and keyless warning light operate as follows: From the point when the ignition switch is turned to the ON position, the security light illuminates for approx. 3 s and goes out. The keyless warning light illuminates with the ignition switch turned to the ON position, and after approx. 1 s after the engine is started, it goes out and displays the number of programmed keys.
18. After verifying that the keyless warning light goes out, turn the ignition switch to the LOCK position using key 1.
19. Repeat Steps 17 thru 18 using key 2 instead of key 1. NOTE: Perform Steps 17 thru 18 as well when there are three or more programmed keys.
20. Start the engine with the card key and remove any key from the key cylinder. CAUTION: Remove any key from the key cylinder.
21. Verify that the security light and keyless warning light operate as follows: From the point when the ignition switch is turned to the ON position, the security light illuminates for approx. 3 s , and goes out. The keyless warning light illuminates when the ignition switch is turned to the ON position, and after approx. 1 s after the engine is started, it goes out.
22. Turn the ignition switch to the LOCK position after verifying that the keyless warning light goes out.

No. 4 Key Additional Programming Procedure Changing

Note. This procedure is performed for enabling/dialing the NO.1 ADDITIONAL KEY PROGRAMMING PROCEDURE (USING TWO VALID KEYS) setting. This procedure is possible when the vehicle is new, and when replacing the keyless unit with a new one. If NO.1 ADDITIONAL KEY PROGRAMMING PROCEDURE (USING TWO VALID KEYS) is set to disable, the additional key programming can be only performed using the WDS or equivalent preventing the forging of a spare key by using two keys that can start the engine. This function is for use by rental car agencies or other companies with vehicle fleets.

1. Using the key, turn the ignition switch to the ON position. (The key can be either the valid key or an unprogrammed key) NOTE: Although the security light flashes and DTC 15 is displayed when an unprogrammed key is used, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
2. Connect the WDS or equivalent to the DLC-2.
3. Select "BODY/SECURITY/PATS (immobilizer) function" from the WDS or equivalent screen menu.
4. Select "Customer spare key programming enable" or "Customer spare key programming disable" from the WDS or equivalent screen menu. The key additional programming procedure is as follows according to the selected menu: KEY ADDITIONAL PROGRAMMING PROCEDURE TABLE Setting Additional key programming procedure Method using two valid keys Method using the WDS or equivalent Customer spare key programming enable - - Customer spare key programming disable x - ?: Available x: Unavailable
5. Perform the security access according to the directions on the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .)
6. After verifying that the PATS function menu is displayed again on the WDS or equivalent screen, select "Finish (this menu)" to finish the WDS or equivalent procedure.
7. After Step 6 , wait 5 s or more and then turn the ignition switch to the LOCK position.

1. When the keyless control module is replaced Have one or more card keys to be programmed after the replacement. Have two or more keys to be programmed after the replacement.
2. When the keyless control module is not to be replaced Have one or more card keys to be programmed. Have two or more keys to be programmed after the replacement.

Scheme 63

Scheme 64

1. Prepare two or more keys to be programmed after the key ID number is cleared.
2. Connect the WDS or equivalent to the DLC-2. (See «WDS OR EQUIVALENT CONNECTING PROCEDURE»(ref-244491-S21422122692006092400000) .)
3. Using key 1, turn the ignition switch to the ON position.
4. Verify that the keyless warning light illuminates for approx. 3 s and then goes out.
5. Select "BODY/SECURITY/PATS (immobilizer) function" from the WDS or equivalent screen menu.
6. Select "Ignition key ID number clearing" from the WDS or equivalent screen menu and perform the procedure according to the WDS or equivalent screen.
7. Perform the security access according to the directions on the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .) CAUTION: The WDS or equivalent displays "At least two or more keys must be programmed", however, do not perform the key programming and proceed to Step 8 . If the procedure is not followed, the engine may not be started. The key programming procedure is performed at Step 13 thru 16 .
8. Select "Parameter Reset" from the WDS or equivalent screen menu.
9. Perform security access again as indicated on the WDS or equivalent screen. (See «SECURITY ACCESS PROCEDURE»(ref-244491-S14059160322006092400000) .)
10. Select the replaced part as indicated on the WDS or equivalent screen. When replacing only the PCM: Select "PCM". When replacing only the instrument cluster: Select "HEC". NOTE: At this time, do not select any other parts from the WDS or equivalent screen menu.
11. After verifying that the PATS function menu is displayed again on the WDS or equivalent screen, select "Finish (this menu)" to finish the WDS or equivalent procedure.
12. After Step 11 , wait 5 s or more and then turn the ignition switch to the LOCK position.
13. Using key 1, turn the ignition switch to the ON position.
14. After verifying that the security light and keyless warning light illuminate for 3 s or more , turn the ignition switch to the LOCK position and remove key 1. NOTE: Although the security light flashes and DTC 21 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
15. Using key 2, turn the ignition switch to the ON position.
16. Verify that the security light and keyless warning light illuminate for approx. 3 s , and then goes out.
17. After verifying that the security light goes out, turn the ignition switch to the LOCK position using key 2, and then remove key 2.
18. If additional keys need to be programmed, repeat Steps 13 thru 14 with the additional key to be programmed being key 3. If the ignition switch is held in the ON position for 1 min or more , additional key programming according to Steps 13 thru 14 will not be possible. If this occurs, refer to «NO.1 ADDITIONAL KEY PROGRAMMING PROCEDURE (USING TWO VALID KEYS)»(ref-244491-S36528486592006092400000) to program any additional keys.
19. Start the engine with key 1.
20. Verify that the security light and keyless warning light operate as follows: From the point when the ignition switch is turned to the ON position, the security light illuminates for approx. 3 s , and goes out. The keyless warning light illuminates when the ignition switch is turned to the ON position, and the light goes out after approx. 1 s , and then displays the number of the programmed keys.
21. After verifying that the keyless warning light goes out, turn the ignition switch to the LOCK position using key 1, and then remove the key.
22. Repeat Steps 20 thru 21 using key 2 instead of key 1. NOTE: Perform Steps 20 thru 21 as well when three or more keys are to be programmed.
23. Start the engine using the card key. CAUTION: Remove any key from the key cylinder.
24. Verify that the security light and keyless warning light operate as follows: From the point that ignition switch is turned to the ON position, the security light illuminates for approx. 3 s , and goes out. The keyless warning light illuminate when the ignition switch is turned to the ON position for approx. 1 min , and goes out.
25. After verifying that the keyless warning light goes out, turn the ignition switch to the LOCK position.

SECURITY ACCESS PROCEDURE

1. Connect the WDS or equivalent to the DLC-2.
2. Select "BODY/SECURITY/PATS (immobilizer) function" from the WDS or equivalent screen menu.
3. Select the items to be performed from the following: Additional card key programming Card key ID number clearing Steering lock unit programming Ignition key additional programming (with immobilizer system) Ignition key ID number clearing (with immobilizer system) Customer spare key programming enable (with immobilizer system) Customer spare key programming disable (with immobilizer system)
4. The security access begins and the WDS or equivalent displays the "OUT-CODE". NOTE: When "OUT-CODE" is first displayed, turning the ignition switch from the LOCK to the ON position 5 times will change the "OUT-CODE".
5. Input "IN-CODE" corresponding to "OUT-CODE" displayed on the WDS or equivalent screen.
6. If the security access is successful, selected item can be performed.
