Security System and Locks System (Advanced Keyless System): Overview Mazda MX-5 NC

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove the following parts: Door trim (See «DOOR TRIM REMOVAL/INSTALLATION».) Door glass (See «DOOR GLASS REMOVAL/INSTALLATION».) Door speaker (See «DOOR SPEAKER REMOVAL/INSTALLATION».) Door unit (See «DOOR UNIT REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2005-2008/remont/exterior-body-panels/#doors-and-liftgate).)
2. Detach the rod from the outer handle.
3. Remove the cover.
4. Remove the bolts.
5. Secure the rear part of the front outer handle and, with the front outer handle lever pulled outward (1), remove the rear part of the front outer handle from the front door.
6. Pull out the front part of the front outer handle from the front door.
7. Install in the reverse order of removal.

Scheme 24

1. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION».)
2. Remove the screws, then remove the inner handle.
3. Detach the cables from the inner handle and door lock knob.
4. Install in the reverse order of removal.

Scheme 25

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION».) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION».) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION».) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION».) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION».) Seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION».) Back trim (See «BACK TRIM REMOVAL/INSTALLATION».) Seat back bar lower garnish (See «SEAT BACK BAR LOWER GARNISH REMOVAL/INSTALLATION».)
2. Remove the bolts.
3. Remove the open hook.
4. Install in the reverse order of removal.

See also:
• DOOR UNIT REMOVAL/INSTALLATION
