Automatic Transmission Shift Mechanism: Overview Mazda MX-5 NC

Automatic Trans 2 illustrations

Scheme 172

Scheme 172: AUTOMATIC TRANSMISSION SHIFT MECHANISM LOCATION INDEX
Scheme 172: AUTOMATIC TRANSMISSION SHIFT MECHANISM LOCATION INDEX

Scheme 173

Scheme 173: SHIFT LOCK INSPECTION
Scheme 173: SHIFT LOCK INSPECTION
  1. Turn the ignition switch to the ON position (engine off).
  2. Verify that the selector lever is in the P position.
  3. Without the brake pedal depressed, verify that the selector lever cannot be shifted the P position.
  4. Depress the brake pedal and verify that the selector lever can be shifted from the P position. If there is any malfunction, adjust the interlock cable. (See «INTERLOCK CABLE ADJUSTMENT».)
