Entertainment System: Removal & Installation Mazda MX-5 NB рестайлинг

DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-194477-S33480948512005092800000) .)
3. Remove the screws.
4. Disconnect the door speaker connector and remove the door speaker.
5. Position the door speaker so that the terminals face downward and install in the reverse order of removal.

Scheme 15

Scheme 16

1. Remove the door speaker. (See «DOOR SPEAKER REMOVAL/INSTALLATION»(ref-194481-S33781853342005092800000) .)
2. Inspect for resistance between the door speaker terminals using an ohmmeter. If not as specified, replace the door speaker.

TWEETER REMOVAL/INSTALLATION

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-194477-S33480948512005092800000) .)
3. Remove the screws, then remove the tweeter.
4. Install in the reverse order of removal.

Scheme 18

Scheme 19

1. Remove the tweeter speaker. (See «TWEETER REMOVAL/INSTALLATION»(ref-194481-S05733035062005092800000) .)
2. Inspect for resistance between the tweeter speaker terminals using an ohmmeter. If not as specified, replace the tweeter speaker.

Scheme 20

1. Disconnect the negative battery cable.
2. Remove the trunk side trim (LH). (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-194477-S38218080682005092800000) .)
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 21

1. Use snap-ring pliers to remove the mounting nut.

Scheme 22

1. Disassemble in the order indicated in the figure.
2. Assemble in the reverse order of disassembly.

Scheme 23

Scheme 24

1. Remove the trunk side trim (LH). (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-194477-S38218080682005092800000) .)
2. Disconnect the power antenna connector.
3. Connect ground to terminal H of the power antenna.
4. Connect B+ to the following terminals of the power antenna. Verify that the power antenna operated as indicated. If not as specified, replace the necessary part.

ANTENNA MAST REMOVAL

Scheme 25

1. Use snap-ring pliers to remove the mounting nut.
2. Turn the ignition switch to the ON position or the ACC position.
3. Audio power switch is the ON position.
4. Press AM/FM button and turn on the radio.
5. Pull out the antenna mast after it fully extends.

Scheme 26

1. Turn the ignition switch to the ON position or the ACC position.
2. Straighten the warp of rack end.
3. Audio power switch is the ON position.
4. Press AM/FM button and turn on the radio.
5. Turn audio power switch off, then immediately insert the rack into the power antenna.
6. After the antenna mast is fully retracted, tighten the mounting nut to the specification. Tightening torque 1.5-2.9 N.m {15-30 kgf.cm, 14-26 in.lbf}
7. Verify that the power antenna operates smoothly when the audio unit radio is on.

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL»(ref-194481-S30241241982005092800000) .) (See «AUDIO UNIT INSTALLATION»(ref-194481-S21464162382005092800000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-194477-S27064776492005092800000) .)
4. Disconnect the connection between the front antenna feeder and the rear antenna feeder.
5. Remove in the order indicated in the figure.
6. Install in the reverse order of removal.

Scheme 28

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL»(ref-194481-S30241241982005092800000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-194477-S27064776492005092800000) .)
4. Disconnect the connection between front antenna feeder and the rear antenna feeder.
5. Verify that there is no continuity between front antenna feeder terminals A and B using an ohmmeter.
6. Inspect for continuity between the front antenna feeder terminals using an ohmmeter. If not as specified, replace the front antenna feeder.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the trunk side trim (LH). (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-194477-S38218080682005092800000) .)
3. Disconnect the connection between the rear antenna feeder and the power antenna. (With manual antenna: manual antenna)
4. Remove the rear package trim. (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-194477-S01827199012005092800000) .)
5. Turn over the floor covering from the right side. (See «FLOOR COVERING REMOVAL/INSTALLATION»(ref-194477-S23445765522005092800000) .)
6. Disconnect the connection between the front antenna feeder and the rear antenna feeder.
7. Remove in the order indicated in the figure.
8. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-194477-S27064776492005092800000) .)
2. Disconnect the connection between the front antenna feeder and the rear antenna feeder.
3. Remove the trunk side trim (LH). (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-194477-S38218080682005092800000) .)
4. Disconnect the connection between the rear antenna feeder and the power antenna. (With manual antenna: manual antenna)
5. Verify that there is no continuity between rear antenna feeder terminals A and B using an ohmmeter.
6. Inspect for continuity between the rear antenna feeder terminals using an ohmmeter. If not as specified, replace the rear antenna feeder.

Scheme 33

1. If the anti-theft system protection has been activated, any one of the following conditions will trigger the system: Disconnected battery cable Discharged battery Disconnected audio unit connectors
2. If the system is triggered, the audio unit will then be inoperative when it is reconnected to a power source, and "code" will flash on the display until the preselected code number is input. If the anti-theft system is triggered, follow the procedures in "Canceling Anti-theft Operation" to reset the unit.

AUDIO UNIT INSTALLATION

Scheme 34

1. Install the audio unit service hole covers.
2. Connect the audio unit connectors and antenna jacks.
3. Insert the audio unit until each clip clicks.
4. Connect the negative battery cable.
5. Operate the anti-theft system by setting the code number. (For vehicles equipped with anti-theft system)

Scheme 35

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL»(ref-194481-S30241241982005092800000) .)
3. Remove in the order indicated in the figure.
4. Install in the order of removal.

Scheme 36

1. Insert a screwdriver into the hole stamped mark.
2. To remove upper module, lift it by pushing down the screwdriver's handle.

Scheme 37

1. Insert a tape-wrapped screwdriver between the cover and the base unit, then unhook the hook A.
2. To unhook the hook B, pull the cover upward.

Screw Installation Note

Scheme 38

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL»(ref-194481-S30241241982005092800000) .)
3. Remove in the order indicated in the figure.
4. Install in the order of removal.

Scheme 39

1. Insert the SST into the service holes on the bottom surface of the lower module.
2. To remove the cover, push the SST in the direction shown by the arrow.
