Entertainment System: Diagnosis Mazda MX-5 NB рестайлинг

STARTING PROCEDURE FOR ON-BOARD DIAGNOSTIC TEST MODE

Note. All DTCs displayed in the on-board diagnostic test mode should be entered in the Audio Exchange Order Form.

Scheme 12

1. Turn the ignition switch to the ACC or ON position.
2. First press the POWER button and hold it, then press the AM button and CLOCK button for 2 seconds or more. NOTE: If several DTCs are in the memory, they can be displayed using the SEEK button.
3. To stop the on-board diagnostic test mode, turn the ignition switch to the LOCK position.

CIGARETTE LIGHTER INSPECTION

Note. Verify that the cigarette lighter plug will move normally within 20-30 seconds, after pressing the plug into the socket. If the fuse does not move, perform the procedures.

Scheme 13

1. Remove the socket. (See «CIGARETTE LIGHTER REMOVAL/INSTALLATION»(ref-194481-S42571152582005092800000) .)
2. Verify the bimetals in the socket are not warped.
3. Inspect if the backs of the bimetals can be seen from the inside or outside. If the back of the bimetal can be seen from the inside, replace the socket. If the fuse has been burnt, replace the socket. If the bimetal and the socket are normal, replace the cigarette lighter plug.
