Entertainment System: Overview Mazda MX-5 NB рестайлинг

Scheme 4

Canceling Anti-theft Operation

Properly input the selected code number to deactivate the anti-theft system and resume normal audio operation.

Scheme 5

Scheme 6

Scheme 7

1. Turn the ignition switch to ACC position. ("CODE" will flash on the display.)
2. First press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds until dashes appears on the display. NOTE: Perform Step 3 within 10 seconds after Step 2.
3. Use channel buttons 1-4 to input the selected code number. Press button 1 for the first digit, 2 for the second, 3 for the third, and 4 for the last digit. Input the number within 10 seconds. If the display is deleted, repeat the procedure from Step 1. CAUTION: Three consecutive errors, including turning the ignition switch to LOCK position and disconnecting the audio unit, will activate the anti-theft system and render the audio unit completely inoperative.
4. With the code number displayed, press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds. "CODE" will flash for approximately 5 seconds.
5. If "Err" (error) appears on the display, repeat the procedure from Step 1.

Scheme 8

Scheme 9

1. Cancel the anti-theft operation. (For vehicles equipped with anti-theft system)
2. Disconnect the negative battery cable.
3. Remove the service hole covers by inserting a small tape-wrapped flathead screwdriver into the slot and carefully pry them off without scratching the center panel. Pry up and pull off the service hole covers carefully to prevent the posts from breaking off. NOTE: Two sets of the SSTs (Removing tool) are necessary to remove the audio unit.
4. With the beveled parts of the SST (Removing tool) facing inward, insert them into the audio unit.
5. Pull the SST (Removing tool) outward and rearward to slide out the audio unit.
6. Disconnect the audio unit connectors and antenna jacks.

SUPPLIER IDENTIFICATION PROCEDURE

Note. When asking the supplier (service center) for repair or replace, verify which supplier the module belongs to and enter in the Audio Exchange Order Form. (See Warranty Bulletin Category AD, number 32.) Use the table and illustration to determine the audio supplier.

Scheme 10

Scheme 11

1. To get the supplier name, compare the leftmost number of the ID code (4 digits), printed on the upper right corner of the LCD, with the figure.
