Setting the Code Number

Complete each step (Steps 1-3) within 10 seconds or the setting procedure will be canceled.

Scheme 40

Scheme 40: Setting the Code Number

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43
  1. Turn the ignition switch to ACC position and then turn off the audio unit.
  2. First press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds until "CODE" appears on the display.
  3. Press the AUTO-M button again, then simultaneously press channel button 6 until dashes appear on the display.
  4. Select a personal code number and record it before inputting it. If the number is input and then forgotten, it cannot be canceled, and if the unit is disconnected again, the audio unit will be inoperative.
  5. Use channel buttons 1-4 to input the selected code number. Press button 1 for the first digit, 2 for the second, 3 for the third, and 4 for the last digit. Input the number within 10 seconds. If the display is deleted, repeat the procedure from Step 1. NOTE: Perform Step 6 within 10 seconds after Step 5.
  6. With the code number displayed, press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds. "CODE" will be displayed for approximately 5 seconds. After it disappears, the code number is set.
  7. If "Err" (error) appears on the display, repeat the procedure from Step 1. If input error is repeated three times, turn the ignition switch to LOCK position and repeat the procedure from Step 1.

Canceling the Code Number

Complete each step (Steps 1-3) within 10 seconds or the canceling procedure will be canceled.

Scheme 44

Scheme 44: Canceling the Code Number

Scheme 45

Scheme 45

Scheme 46

Scheme 46

Scheme 47

Scheme 47
  1. Turn the ignition switch to ACC position and then turn off the audio unit.
  2. First press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds until "CODE" appears on the display.
  3. Press the AUTO-M button again, then simultaneously press channel button 6 until dashes appear on the display.
  4. Use channel buttons 1-4 to input the current code number. Press button 1 for the first digit, 2 for the second, 3 for the third, and 4 for the last digit. Input the number within 10 seconds. If the display is deleted, repeat the procedure from Step 1. NOTE: Perform Step 5 within 10 seconds after Step 4.
  5. With the code number displayed, press the AUTO-M button, then simultaneously press channel button 6 for approximately 2 seconds. "CODE" will be displayed for approximately 5 seconds. After it disappears, the code number is canceled.
  6. If "Err" (error) appears on the display, repeat the procedure from Step 4.

Upper/lower module

  1. Remove the audio unit.
  2. Verify the supplier name written in the label attached on each module.

Scheme 48

Scheme 48: Identification With On-board Diagnostic Test Mode

Scheme 49

Scheme 49

Scheme 50

Scheme 50
  1. Start the on-board diagnostic test mode.
  2. Verify the device code and supplier code displayed in the LCD. NOTE: When no DTCs are in the memory, device code and supplier codes will not be displayed.

Scheme 51

Scheme 51: DTC CLEARING PROCEDURE
  1. Start the on-board diagnostic test mode.
  2. First press the POWER button and hold it, then press AUDIO CONT button for 2 seconds or more. CAUTION: Before clearing the DTCs, be sure to enter all of them displayed in the on-board diagnostic test mode in the Audio Exchange Order Form.
  3. To stop the on-board diagnostic test mode, turn the ignition switch to the LOCK position.

Scheme 52

Scheme 52: DTC TABLE

Scheme 53

Scheme 53: DTC 09: ER22

Scheme 54

Scheme 54: Diagnostic procedure

Scheme 55

Scheme 55: DTC 09:ER20

Scheme 56

Scheme 56: Diagnostic procedure

Scheme 57

Scheme 57: DTC 00: ER10

Scheme 58

Scheme 58: Diagnostic procedure

Scheme 59

Scheme 59: DTC 03:ER10

Scheme 60

Scheme 60: Diagnostic procedure

Scheme 61

Scheme 61: DTC 05:ER10

Scheme 62

Scheme 62: Diagnostic procedure

Scheme 63

Scheme 63: DTC 06:ER10

Scheme 64

Scheme 64: Diagnostic procedure

Scheme 65

Scheme 65: DTC 07:ER10

Scheme 66

Scheme 66: Diagnostic procedure

Scheme 67

Scheme 67: DTC 03:ER01

Scheme 68

Scheme 68: Diagnostic procedure

Scheme 69

Scheme 69: DTC 03:ER02

Scheme 70

Scheme 70: Diagnostic procedure

Scheme 71

Scheme 71: DTC 03:ER07

Scheme 72

Scheme 72: Diagnostic procedure

Scheme 73

Scheme 73: DTC 00:ER01

Scheme 74

Scheme 74: Diagnostic procedure

Scheme 75

Scheme 75: DTC 00:ER03

Scheme 76

Scheme 76: Diagnostic procedure

Scheme 77

Scheme 77: DTC 00:ER04

Scheme 78

Scheme 78: Diagnostic procedure

Scheme 79

Scheme 79: DTC 05:ER01

Scheme 80

Scheme 80: Diagnostic procedure

Scheme 81

Scheme 81: DTC 05:ER07

Scheme 82

Scheme 82: Diagnostic procedure

Scheme 83

Scheme 83: DTC 06:ER01

Scheme 84

Scheme 84: Diagnostic procedure

Scheme 85

Scheme 85: DTC 06:ER02

Scheme 86

Scheme 86: Diagnostic procedure

Scheme 87

Scheme 87: DTC 06:ER07

Scheme 88

Scheme 88: Diagnostic procedure

Scheme 89

Scheme 89: DTC 07:ER01

Scheme 90

Scheme 90: Diagnostic procedure

Scheme 91

Scheme 91: DTC 07:ER02

Scheme 92

Scheme 92: Diagnostic procedure

Scheme 93

Scheme 93: DTC 07:ER07

Scheme 94

Scheme 94: Diagnostic procedure

Scheme 95

Scheme 95: Switch Location

Scheme 96

Scheme 96: LCD Inspection
  1. With audio on, first press the POWER button and hold it, then press the SEEK button (upper) for approximately 1 second.
  2. Inspect the LCD according to the figure
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 97

Scheme 97: Button Inspection
  1. With audio on, first press the POWER button and hold it, then press the CLOCK button for approximately 1 second.
  2. Inspect the button according to the table: NOTE: The button inspection mode is designed for base unit button. The following lower module button cannot be inspected in this mode. (A buzz will not sound.) Cassette deck: DOLBY button, EJECT button MD player: DISP button, EJECT button
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 98

Scheme 98: Speaker Inspection
  1. With audio on, first press the POWER button and hold it, then press the AUTO-M button for approximately 1 second.
  2. Inspect the speaker according to the figure
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 99

Scheme 99: Radio reception condition Inspection
  1. With audio on and at radio mode, first press the POWER button and hold it, then press the preset button "2" for approximately 1 second.
  2. Inspect the radio reception condition according to the figure
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 100

Scheme 100: Power antenna inspection
  1. With audio on and at radio mode, first press the POWER button and hold it, then press the AM button for approximately 1 second.
  2. Inspect the power antenna according to the figure
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 101

Scheme 101: Audio amplifier (external) inspection
  1. With audio on, first press the POWER button and hold it, then press the SCAN button for approximately 1 second.
  2. Inspect the audio amplifier (external) according to the figure
  3. Turn the audio off or the ignition switch to the LOCK position to stop the diagnostic assist function.

Scheme 102

Scheme 102: AUDIO AMPLIFIER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-194477-S25371269412005092800000) .)
  3. Remove in the order indicated in the figure.
  4. Install in the reverse order of removal.

Scheme 103

Scheme 103: AUDIO RELAY REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the center lower panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-194477-S42545492742005092800000) .)
  3. Disconnect the audio relay connector.
  4. Remove the audio relay.
  5. Install in the reverse order of removal.

Scheme 104

Scheme 104: CIGARETTE LIGHTER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the center panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-194477-S42545492742005092800000) .)
  3. Remove in the order indicated in the figure.
  4. Install in the reverse order of removal.

Scheme 105

Scheme 105: Socket Removal Note
  1. Pry up the stopper with the tape-wrapped flathead screwdriver.
  2. Pull the socket while prying up the stopper.
