FLUID CAPACITIES
| Application | Refill - Qts. (L) | Dry Fill - Qts. (L) |
|---|---|---|
| Millenia | N/A | 8.2 (7.8) |
| MPV | N/A | 8.5 (8.0) |
| 626 | N/A | 8.5 (8.0) |
TRANSAXLE FLUID CAPACITIES
No Torque Converter Clutch
Possible cause: Torque Converter Clutch (TCC) burnt or slipping, TCC piston hydraulic pressure system, low line pressure, TP sensor malfunction, ECT malfunction, VSS malfunction, faulty input/turbine speed sensor, poor sensor ground, TCC solenoid valve sticking and/or faulty control valve body.
SHIFT SPEED SPECIFICATIONS
Note. For shift speed specifications, refer to appropriate illustrations. (Scheme 98)- (Scheme 105).
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Scheme 107
Scheme 108
Scheme 109
Below Specifications
Engine out of tune. One-way clutch slipping within torque converter.
TORQUE CONVERTER
- Torque converter is a sealed unit and cannot be disassembled for service. Inspect for damage and cracks. Replace torque converter if defective. Remove any rust from pilot hub and boss of converter. Replace torque converter if converter boss bushing inner diameter exceeds specification. Maximum bushing diameter on converter is 2.088" (53.03 mm).
- Flush torque converter. After converter is removed from cleaner, thoroughly drain solvent through hub. Add about .53 qt. (.5L) clean ATF to converter. Agitate fluid by hand. Drain ATF from converter.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Bearing Housing Mounting Bolt | 20-25 (27-34) | |
| Detent Spring Bolt | 11-15 (15-20) | |
| Idler Gear Lock Nut | 109-144 (148-195) | |
| Manual Plate Nut | 31-40 (42-54) | |
| Manual Shaft Nut | 24-33 (33-45) | |
| Oil Pump Bolt | 14-18 (19-24) | |
| Piston Stem Lock Nut | 19-28 (26-38) | |
| Transaxle Case-To-Converter Housing Bolt | 28-38 (38-52) | |
| INCH Lbs. (N.m) | ||
| Inspection Port Square Head Plug | ||
| Millenia & MPV | 43-87 (5-10) | |
| 626 | 44-87 (5-10) | |
| 2-3 Accumulator Piston Bolt | 70-95 (8-11) | |
| 2-4 Brake Band Piston Stem | 104-130 (12-15) | |
| Actuator Support | 96-121 (11-14) | |
| Bearing Cover Installation Bolts | 96-121 (11-14) | |
| Bearing Housing Baffle Plate Bolt | 35-51 (4-6) | |
| Control Valve Body Cover Bolts | 74-95 (8-11) | |
| Control Valve Body-To-Transaxle Case Bolts | 96-130 (11-15) | |
| Differential Cover Screws | 709-95 (8-11) | |
| Differential Ring Gear Bolts | 83-99 (11-15) | |
| Front Control Valve Body Mounting Bolts | 58-69 (7-8) | |
| Input/Turbine Speed Sensor | 70-95 (8-11) | |
| Main Separator Plate Nuts | 15-19 (1.7-2.2) | |
| Oil Baffle Bolt | 58-69 (7-8) | |
| Oil Dipstick & Oil Filler Tube Bolt | 70-95 (8-11) | |
| Oil Pan Bolts | 74-95 (8-11) | |
| Oil Pipe Component Bolt | 58-69 (7-8) | |
| Oil Strainer Bolts | 70-95 (8-11) | |
| Pre-Main Control Valve Body Plate Bolts | 58-69 (7-8) | |
| Rear Control Valve Body Bolts | 58-69 (7-8) | |
| Solenoid Valve Body Bolts | 58-69 (7-8) | |
| TFT Sensor Bolt | 58-69 (7-8) | |
| TR Switch | 70-95 (8-11) | |
TORQUE SPECIFICATIONS
TRANSAXLE SPECIFICATIONS
| Application | Specification | ||
|---|---|---|---|
| Bearing Preload | |||
| Differential | |||
| Torque Wrench | 27-35 INCH Lbs. (3.0-3.9 N.m) | ||
| Pull Scale | 6.6-8.8 Lbs. (3.0-4.0 kg) | ||
| Output Gear | |||
| Torque Wrench | 7.9-17.7 INCH Lbs. (0.9-2.0 N.m) | ||
| Pull Scale | 2.0-4.6 Lbs. (0.9-2.1 kg) | ||
| Brake Snap Ring-To-Retaining Plate Clearance, Low-Reverse Brake | .059-.071" (1.50-1.80 mm) | ||
| Clutch Drive Plate Minimum Thickness (All Clutches) | .055" (1.40 mm) | ||
| Clutch Snap Ring-To-Retaining Plate Clearance | |||
| Coasting Clutch | .039-.047" (1.00-1.20 mm) | ||
| Forward Clutch | .039-.047" (1.00-1.20 mm) | ||
| Reverse Clutch | .059-.071" (1.50-1.80 mm) | ||
| 3-4 Clutch | .051-.059" (1.30-1.50 mm) | ||
| Oil Pump | |||
| Rotor End Clearance | .0008-.0016" (.020-.040 mm) | ||
| Rotor Side Clearance | .0016-.0045" (.040-.115 mm) | ||
| Seal Ring Inner Diameter | 2.026" (51.45 mm) | ||
| Planetary Pinion Gear Clearance | .008-.028" (.20-.70 mm) | ||
| Torque Converter Bushing Inside Diameter (Maximum) | 2.088" (53.03 mm) | ||
TRANSAXLE SPECIFICATIONS
