SHIFT LOCK SYSTEM

With ignition on, when brake pedal is depressed, park position switch on, an input signal is sent from brakelight switch to the actuator. The shift lock actuator then operates the lock lever (release position), so shift lever can be moved into Park.

FUNCTIONAL CHECK

  1. With ignition key removed, ensure gear selector cannot be moved from Park. Insert key in ignition switch.
  2. Turn ignition on. Ensure gear selector can only be moved with brake pedal pressed down. Move gear selector to Reverse.
  3. Ensure ignition key cannot be removed, Move gear selector to Park. Ensure it is not possible to remove ignition key.
  4. If shift lock system does not operate as described, check gear selector, shift lock solenoid and control cable.
  5. On MPV, place gear selector in Park, depress and hold emergency override link. (Scheme 206) On all other models, place gear selector in Park. Using a screwdriver, push down emergency override button on shifter console and verify gear selector can be moved from Park position. (Scheme 207) On all models, if gear selector cannot be moved out of Park, adjust or replace shift lock actuator.

Scheme 206

Scheme 206

Scheme 207

Scheme 207

Miata

Disconnect negative battery cable. Remove rear console. Remove indicator screws and lift up panel. Disconnect park position switch. Check continuity between connector terminals. (Scheme 208) Continuity should exist with switch released. Continuity should not exist with switch depressed. Replace as needed.

Scheme 208

Scheme 208: Miata

Millenia

Disconnect negative battery cable. Remove rear console and center panel. Remove indicator screws and lift up panel. Disconnect park position switch. Check continuity between terminals "k" and "h". (Scheme 209) Continuity should exist with switch released. Continuity should not exist with switch depressed. Replace as needed.

Scheme 209

Scheme 209: Millenia

MX-6, Protege & 626

Disconnect negative battery cable. Remove rear ashtray, rear console and front console. Remove indicator screws and lift up panel. Disconnect park position switch. Check continuity between connector terminals. (Scheme 210)or (Scheme 211). Continuity should exist with switch released. Continuity should not exist with switch depressed. Replace as needed.

Scheme 210

Scheme 210: MX-6, Protege & 626

Scheme 211

Scheme 211
  1. Remove rear console. Remove selector knob and indicator panel screws. Lift up selector lever, selector sleeve and indicator. Disconnect HOLD switch connector. Ensure selector lever is in Park position.
  2. Turn ignition on. Check voltage at selected connector terminals. (Scheme 208) If voltage is not as specified, inspect harness and connector. Repair as needed. If harness and connector is okay, replace shift lock actuator.
  3. Turn ignition off. Check continuity at selected connector terminals. If continuity is not as specified, inspect harness and connector. Repair as needed. If harness and connector is okay, replace shift lock actuator.
  1. Remove rear console and center panel. Turn ignition on. Check voltage at selected connector terminals. (Scheme 209) If voltage is not as specified, inspect harness and connector. Repair as needed. If harness and connector are okay, replace shift lock actuator.
  2. Turn ignition off. Check continuity at selected connector terminals. If continuity is not as specified, inspect harness and connector. Repair as needed. If harness and connector is okay, replace shift lock actuator.
  1. Remove rear ashtray, rear console and front console. Turn ignition on. Check voltage at selected connector terminals. (Scheme 210) If voltage is not as specified, inspect harness and connector. Repair as needed. If harness and connector are okay, replace shift lock actuator.
  2. Turn ignition off. Check continuity at selected connector terminals. If continuity is not as specified, inspect harness and connector. Repair as needed. If harness and connector are okay, replace shift lock actuator.

SHIFT LOCK SOLENOID (MPV)

Note. Shift lock solenoid is also known as shift lock solenoid valve.

  1. Remove steering column covers. Turn ignition on. Measure voltage between Orange wire and ground. (Scheme 212) With gear selector in Park and brake pedal depressed, battery voltage should be present. If voltage is present, go to next step. If no voltage is present, check shift lock solenoid and related circuits.
  2. Release brake pedal. Voltage should be less than 1.5 volts. With gear selector in any position except "P", voltage should be less than 1.5 volts. If voltage is not as described, check inhibitor switch, brakelight circuit or Central Processing Unit (CPU).

Scheme 212

Scheme 212

Shift Interlock System Wiring Diagram (1997 B2300 & B4000). Scheme 213

Scheme 213: Shift Interlock System Wiring Diagram (1997 B2300 & B4000)

Shift Interlock System Wiring Diagram (1997 Miata). Scheme 214

Scheme 214: Shift Interlock System Wiring Diagram (1997 Miata)

Shift Interlock System Wiring Diagram (1997 Millenia). Scheme 215

Scheme 215: Shift Interlock System Wiring Diagram (1997 Millenia)

Shift Interlock System Wiring Diagram (1997 MPV). Scheme 216

Scheme 216: Shift Interlock System Wiring Diagram (1997 MPV)

Shift Interlock System Wiring Diagram (1997 MX-6 & 626). Scheme 217

Scheme 217: Shift Interlock System Wiring Diagram (1997 MX-6 & 626)

Shift Interlock System Wiring Diagram (1997 Protege). Scheme 218

Scheme 218: Shift Interlock System Wiring Diagram (1997 Protege)

Shift Interlock System Wiring Diagram (1998 B2500, B3000 & B4000). Scheme 219

Scheme 219: Shift Interlock System Wiring Diagram (1998 B2500, B3000 & B4000)

Shift Interlock System Wiring Diagram (1998 Millenia). Scheme 220

Scheme 220: Shift Interlock System Wiring Diagram (1998 Millenia)

Shift Interlock System Wiring Diagram (1998 MPV). Scheme 221

Scheme 221: Shift Interlock System Wiring Diagram (1998 MPV)

Shift Interlock System Wiring Diagram (1998 Protege). Scheme 222

Scheme 222: Shift Interlock System Wiring Diagram (1998 Protege)
