Servicing - A/t: Adjustments Mazda Millenia I

ADJUSTMENTS

Note. Adjustment information for MX-6 and 626 with 2.0L engine is not available from the manufacturer.

Scheme 253

1. Disconnect negative battery cable. Loosen oil pan and drain fluid. Remove bracket, oil pan and gasket. Disconnect vacuum hose at vacuum diaphragm (modulator), and remove vacuum diaphragm.
2. Disconnect solenoid valve connector, and remove harness from bracket. Remove valve body bolts and valve body assembly. Loosen lock nut on 2nd gear brake band while holding piston stem stationary. (Scheme 253)
3. Tighten piston stem to 106-130 INCH lbs. (12-15 N.m). Loosen piston stem 2 1/2 turns. Tighten lock nut to 11-29 ft. lbs (15-39 N.m) while holding stem stationary. Install valve body assembly. Tighten bolts to specifications. See «TORQUE SPECIFICATIONS»(ref-2430-S03546018212000031800000).
4. Connect solenoid valve connector and install harness. Clean oil pan and install using NEW pan gasket. Tighten pan bolts to specification. See «TORQUE SPECIFICATIONS»(ref-2430-S03546018212000031800000). Install vacuum diaphragm and connect vacuum hose. Connect negative battery cable. Add fluid and check level. DO NOT overfill.
