Sunroof: Removal & Installation Mazda CX-9 I

Sun Roof/t-Top/convertible Top 5 illustrations ~1421 words

FRONT DRAIN HOSE INSTALLATION

CAUTIONIf the front drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the front drain hose. Fix any problem if found.
  1. Apply soapy water to the front drain hose inserting area.
  2. Insert one end (the wider end) of the front drain hose into the sunroof frame.
  3. Install the front drain hose to the clips, parallel to the pillar and free of slack.
  4. Insert the front drain hose joint into the hinge pillar inner hole.
  5. Install the following parts: Dashboard. See «DASHBOARD REMOVAL/INSTALLATION»(ref-345331-S28664278972009102000000) . Side panel. See «SIDE PANEL REMOVAL/INSTALLATION»(ref-345331-S06165285212009102000000) . Steering shaft. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . Audio unit. See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-345330-S42396879762009102000000) . Instrument cluster. See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-345363-S11148620752009102000000) . Meter hood. See «METER HOOD REMOVAL/INSTALLATION»(ref-345331-S34116172672009102000000) . Center panel. See «CENTER PANEL REMOVAL/INSTALLATION»(ref-345331-S22152336712009102000000) . Combination switch. See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-345339-S03518932132009102000000) . Steering wheel. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . Driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-345337-S10259074632009102000000) . Column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) . Hood release lever. See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-345344-S38720975792009102000000) . Lower panel. See «LOWER PANEL REMOVAL/INSTALLATION»(ref-345331-S27563849592009102000000) . Glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-345331-S00629389742009102000000) . Front side trim. See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S41141327992009102000000) . Console. See «CONSOLE REMOVAL/INSTALLATION»(ref-345331-S33017209812009102000000) . Console cover. See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-345331-S33051633072009102000000) . Console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-345331-S12921188482009102000000) . Side wall. See «SIDE WALL REMOVAL/INSTALLATION»(ref-345331-S28735626472009102000000) . Dashboard under cover. See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) . Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-345331-S24413902932009102000000) . Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) .
  6. Install the seaming welt.

Scheme 9

Scheme 9: REAR DRAIN HOSE REMOVAL
Scheme 9: REAR DRAIN HOSE REMOVAL
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) . Headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) .
  4. Disconnect the rear drain hose from the sunroof frame.
  5. Remove the rear drain hose from the clips.
  6. Pull the rear drain hose into the room side.
  7. Remove the rear drain hose.

REAR DRAIN HOSE INSTALLATION

CAUTIONIf the rear drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the rear drain hose. Fix any problem if found.
  1. Apply soapy water to the rear drain hose inserting area.
  2. Insert one end (the wider side) of the rear drain hose into the sunroof frame.
  3. Install the rear drain hose to the clips parallel to the pillar and free of slack.
  4. Insert the rear drain hose joint into the rear pillar inner hole.
  5. Install the following parts: Headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Front seat belt upper anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt lower anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) .
  6. Install the seaming welt.

Scheme 10

Scheme 10: SUNROOF MOTOR REMOVAL/INSTALLATION
Scheme 10: SUNROOF MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) .
  3. Remove the sunroof seaming welt.
  4. Remove the headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) .
  5. Disconnect the sunroof motor connector.
  6. Remove the screws, and then remove the sunroof motor.
  7. Install in the reverse order of removal. NOTE: If the glass panel or the sunroof motor is moved with the sunroof motor removed, initial position setting of the sunroof motor will be required. Perform initial position setting referring to the «SUNROOF MOTOR ASSEMBLY NOTE»(ref-345437-S37570859682009102000000) . See «SUNROOF UNIT DISASSEMBLY/ASSEMBLY»(ref-345437-S07571572632009102000000) .
  1. Measure the voltage at each terminal (other than terminal G). If not as specified, inspect the parts listed under "Inspection item" and the related wiring harnesses.
  2. Disconnect the negative battery cable.
  3. If the parts and wiring harnesses are normal but the system still does not work properly, replace the sunroof motor.

Scheme 11

Scheme 11: Terminal Voltage Table (Reference)
Scheme 11: Terminal Voltage Table (Reference)
TerminalSignalConnected toTest conditionVoltage (V)Inspection item
ASlide openSunroof switchSunroof is fully opening.B+Sunroof switch Related wiring harnesses
Other1.0 or less
BSlide close/tilt downSunroof switchSunroof is closing/tilting down.B+Sunroof switch Related wiring harnesses
Other1.0 or less
CTilt upSunroof switchSunroof is tilting up.B+Sunroof switch Related wiring harnesses
Other1.0 or less
EIG1METER 10A fuseTurn the ignition switch to the ON position.B+METER 10A fuse Related wiring harnesses
Other1.0 or less
FVehicle speedInstrument clusterPulse signalInstrument cluster Related wiring harnesses
GGNDGNDUnder any condition1.0 or lessRelated wiring harnesses
HCommunicationBCMBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.BCM Related wiring harnesses
JPower supplySUNROOF 15A fuseUnder any conditionB+SUNROOF 15A fuse Related wiring harnesses

CONNECTOR TERMINALS REFERENCE

Note. The sunroof switch is together with the front map light.

  1. Disconnect the negative battery cable.
  2. Remove the map light from the headliner. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) .
  3. Install in the reverse order of removal.

Scheme 12

Scheme 12: SUNROOF SWITCH INSPECTION
Scheme 12: SUNROOF SWITCH INSPECTION

Scheme 13

Scheme 13
Scheme 13
  1. Verify that the continuity between the sunroof switch terminals is as indicated in the table. If not as specified, replace the sunroof switch.
