LIGHT SWITCH INSPECTION

  1. Verify that the continuity between the light switch terminals is as indicated in the table. If not as indicated in the table, replace the light switch.

Scheme 4

Scheme 4: Headlight Switch (Vehicle Without Auto Light)

Scheme 5

Scheme 5

Scheme 6

Scheme 6: Headlight Switch (Vehicle With Auto Light)

Scheme 7

Scheme 7

Scheme 8

Scheme 8: Turn Switch

Scheme 9

Scheme 9

Scheme 10

Scheme 10: FRONT FOG LIGHT SWITCH INSPECTION

Scheme 11

Scheme 11
  1. Verify that continuity between the front fog light switch terminals is as indicated in the table.

Scheme 12

Scheme 12: HAZARD WARNING SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-345331-S24413902932009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) . Center panel. See «CENTER PANEL REMOVAL/INSTALLATION»(ref-345331-S22152336712009102000000) .
  3. Remove in hazard warning switch.
  4. Install in the reverse order of removal.

Scheme 13

Scheme 13: HAZARD WARNING SWITCH INSPECTION

Scheme 14

Scheme 14
  1. Verify that the continuity between the hazard switch terminals is as indicated in the table. If not as indicated in the table, replace the hazard warning switch.

Scheme 15

Scheme 15: HEADLIGHT LEVELING SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover. (Driver side). See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) .
  3. Remove the hood release lever. See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-345344-S38720975792009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 16

Scheme 16: HEADLIGHT LEVELING SWITCH INSPECTION

Scheme 17

Scheme 17
  1. Verify that continuity between the headlight leveling switch terminals is as indicated in the table. If not as indicated in the table, replace the headlight leveling switch.

Scheme 18

Scheme 18: Auto Light/Wiper Control Module Vehicles With DRL

Vehicles without DRL

Scheme 19

Scheme 19

Scheme 20

Scheme 20: Auto Light-Off Control Module

Scheme 21

Scheme 21: AUTO LIGHT-OFF CONTROL MODULE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover (Driver side). See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

AUTO LIGHT-OFF CONTROL MODULE INSPECTION

  1. Measure the voltage at the auto light-off control module terminals as indicated below.

Scheme 22

Scheme 22: Terminal Voltage List (Reference)
TerminalSignalConnectionTest conditionVoltage (V)Action
2CIG 1METER 10 A fuseIgnition switch at ONB+METER 10 A fuse Related wiring harnesses
Ignition switch at LOCK or ACC1.0 or less
2DPower supplyBCM ROOM 15 A fuseConstantB+BCM. See BODY CONTROL MODULE (BCM) INSPECTION . Inspect ROOM 15 A fuse Related wiring harnesses
2GTNS relay operationTNS relayLight switch at low-beam or high-beam positionBelow 1.5TAIL 10 A fuse TNS relay. See RELAY INSPECTION . Related wiring harnesses
Light switch at OFFB+
2KH/L LOW relay operationH/L LOW relayLight switch at high-beam positionBelow 1.5H/L LOW relay. See RELAY INSPECTION . Related wiring harnesses
Light switch at OFF or low-beam positionB+
2MTNS switch on/offLight switchIgnition switch at ONLight switch at low-beam or high-beam position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
Light switch at OFF positionB+
2NLight switch on/offLight switchIgnition switch at ONLight switch at low-beam or high-beam position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
Light switch at OFF positionB+
2OGNDGNDUnder any condition1.0 or lessRelated wiring harnesses

CONNECTOR TERMINALS REFERENCE

AUTO LIGHT/WIPER CONTROL MODULE INSPECTION

  1. Measure the voltage at the auto light/wiper control module terminals as indicated below.

Scheme 23

Scheme 23: Terminal Voltage List (Reference)
TerminalSignalConnectionTest conditionVoltage (V)Action
1A (1)RH headlight operation (high-beam)RH headlight (high-beam)Light switch at HEAD positionDimmer switch at the high-beam positionB+RH headlight Related wiring harnesses
Dimmer switch at the low-beam position1.0 or less
DRL modeApprox 6.0
1B (1)LH headlight operation (high-beam)LH headlight (high-beam)Light switch at HEAD positionDimmer switch at the high-beam positionB+LH headlight Related wiring harnesses
Dimmer switch at the low-beam position1.0 or less
DRL modeApprox 6.0
1CAutostop switch signalAutostop switchIgnition switch at ONWindshield wiper switch at LO positionB+Autostop switch (Windshield wiper motor). See WINDSHIELD WIPER MOTOR INSPECTION . Related wiring harnesses
Windshield wiper switch at OFF position1.0 or less
1DWindshield wiper switch signal (OFF)Windshield wiper and washer switchIgnition switch at ONWindshield wiper switch at LO positionB+Windshield wiper and washer switch. See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION . Related wiring harnesses
Windshield wiper switch at OFF position1.0 or less
1EIG2WIPER 30 A fuseIgnition switch at ONB+WIPER 30 A fuse Related wiring harnesses
Ignition switch at LOCK or ACC1.0 or less
1FWindshield wiper switch signal (HI)Windshield wiper and washer switchIgnition switch at ONWindshield wiper switch at HI positionB+Windshield wiper and washer switch. See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION . Related wiring harnesses
Windshield wiper switch at OFF position1.0 or less
1G (1)GNDGNDUnder any condition1.0 or lessRelated wiring harnesses
1HWindshield wiper switch signal (AUTO)Windshield wiper and washer switchIgnition switch at ONWindshield wiper switch at AUTO positionB+Windshield wiper and washer switch. See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION . Related wiring harnesses
Windshield wiper switch at OFF position1.0 or less
1I (1)Power supplyHEAD LIGHT 20 A fuseConstantB+HEAD LIGHT 20 A fuse Related wiring harnesses
1JWasher switch signalWindshield wiper and washer switchIgnition switch at ONWasher switch at ON positionB+Windshield wiper and washer switch. See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION . Related wiring harnesses
Washer switch at OFF position1.0 or less
1K (1)LH headlight operation (high-beam)LH headlight (high-beam)Light switch at the OFF positionIgnition switch at ON positionB+LH headlight Related wiring harnesses
Ignition switch LOCK or ACC position1.0 or less
1L (1)High-beam on/offLight switchIgnition switch at ONDimmer switch at high-beam position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
Dimmer switch at low-beam positionB+
2AVehicle speed signal inputInstrument clusterBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.Instrument cluster. See INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE . Related wiring harnesses
2BSensitivity adjustment volumeWindshield wiper and washer switchIgnition switch at ONSensitivity adjustment volume turned from + position to - position0 --> 0.8 --> 1.5 --> 1.9 --> 2.2Windshield wiper and washer switch. See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION . Related wiring harnesses
2CIG 1METER 10 A fuseIgnition switch at ONB+METER 10 A fuse Related wiring harnesses
Ignition switch at LOCK or ACC1.0 or less
2DPower supplyBCM ROOM 15 A fuseConstantB+BCM. See BODY CONTROL MODULE (BCM) INSPECTION . ROOM 15 A fuse Related wiring harnesses
2EWiper or headlight operation requestRain sensorBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.Rain sensor Related wiring harnesses
2FDLC-2 power supplyDLC-2Under any conditionB+Related wiring harnesses
2GTNS relay operationTNS relayLight switch at low-beam or high-beam positionBelow 1.5TNS relay. See RELAY INSPECTION . Related wiring harnesses
Light switch at OFFB+
2HRain sensor operation requestRain sensorBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.Rain sensor Related wiring harnesses
2KH/L LOW relay operationH/L LOW relayLight switch at high-beam positionBelow 1.5H/L LOW relay. See RELAY INSPECTION . Related wiring harnesses
Light switch at OFF or low-beam positionB+
2LLight switch signalLight switchIgnition switch at ONLight switch at AUTO position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
OtherB+
2MTNS switch on/offLight switchIgnition switch at ONLight switch at low-beam or high-beam position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
Light switch at OFF positionB+
2NLight switch on/offLight switchIgnition switch at ONLight switch at low-beam or high-beam position1.0 or lessLight switch. See LIGHT SWITCH INSPECTION . Related wiring harnesses
Light switch at OFF positionB+
2OGNDGNDUnder any condition1.0 or lessRelated wiring harnesses
2P (1)Parking brake switch on/offBCM Parking brake switchIgnition switch at ONParking brake switch on1.0 or lessBCM. See BODY CONTROL MODULE (BCM) INSPECTION . Parking brake switch Related wiring harnesses
Parking brake switch OFFB+
(1) For vehicles with DRL only.
(1)For vehicles with DRL only.
