Lighting Systems: Other Mazda CX-9 I

Discharge Headlight Control Module Reuse

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge Type

Scheme 53

1. Disconnect the negative battery cable.
2. Remove the coolant reserve tank. (RH only). See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-345349-S27340291352009102000000) .
3. Remove in the order indicated in the table. CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Install in the reverse order of removal.

Scheme 54

1. Press sections A to release the bulb retaining wire and remove the discharge headlight bulb.

Scheme 55

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
3. Install in the reverse order of removal.

AUTO LIGHT/WIPER CONTROL MODULE CONFIGURATION

Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the AUTO LIGHT/WIPER CONTROL MODULE CONFIGURATION.

Scheme 56

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "LCM".
4. Perform the configuration according to the directions on the screen.
5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. See «DTC TABLE [AUTO LIGHT/WIPER CONTROL MODULE]»(ref-345416-S15109125192009102000000) .

Without Using M-MDS

Note. Perform the procedure in a condition that allows verification of the headlight illumination because it is necessary to verify the setting condition according to the number of times headlights turn on.

1. Turn the ignition switch to the ON position with the light switch in the OFF position and pulled back (Flash-to-pass ON).
2. Switch the light switch from the OFF to TNS position five times and return it to the OFF position.
3. Pull the light switch back once. (Flash-to-pass ON)
4. Turn the light switch to the TNS position.
5. Switch the light switch from the TNS to ON position five times and return it to the TNS position.
6. Turn the light switch to the ON position.
7. Switch the light switch from the ON to AUTO position five times and return it to the ON position.
8. Turn the light switch to the TNS position. NOTE: Switches to the sensitivity setting mode when the above operations are performed. The headlights turn on for the number of times according to the current setting conditions. Illumination (Two times): Standard sensitivity Illumination (Three times): Low sensitivity
9. Switch the sensitivity by pulling the light switch back (Flash-to pass ON).
10. Verify the number of times the headlights turn on and that the sensitivity is set properly. Illumination (Two times): Standard sensitivity Illumination (Three times): Low sensitivity

Scheme 57

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming". When using the PDS (Pocket PC) Select "Programming". Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "Exterior Lighting". Select "Autolamp On Setting- (GEM)".
4. Select "Standard (Other)" or "Low (Other)" on the M-MDS to set the illumination level. NOTE: When the M-MDS is set to Low (Other), the auto-light sensor sensitivity decreases, and the TNS and headlight illumination timing is slower.
5. Perform the procedure as indicated on the screen.

Scheme 58

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 59

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 60

Scheme 61

1. Verify that the continuity between the front map light terminals is as indicated in the table. If not as indicated in the table, replace the front map light.

Scheme 62

Scheme 63

1. Disconnect the negative battery cable.
2. Install in the reverse order of removal.
3. Remove the following parts: A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) . Headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) .
4. Detach the tab and remove the bulb housing. NOTE: The valve housing and the wiring harness have been integrated and attached to the headliner. When replacing the valve housing, remove the wiring harness which passes under the urethane by cutting the urethane.
5. Pull in the direction of the arrows and detach the tabs.
6. Remove the interior light.
7. Install in the reverse order of removal. NOTE: After installing the wiring harness, reinforce the urethane that was cut when removing the valve housing with vinyl tape.

Scheme 64

Scheme 65

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the rear interior light bulb.
4. Install in the reverse order of removal.

Scheme 66

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 67

Scheme 68

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the cargo compartment light bulb.
4. Install in the reverse order of removal.

Scheme 69

Scheme 70

1. Verify that the continuity between the cargo compartment light terminals is as indicated in the table. If not as indicated in the table, replace the cargo compartment light.

Scheme 71

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 72

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 73

1. Disconnect the negative battery cable.
2. Pull the upper column cover upward and detach the upper column cover from the lower column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) .
3. Put aside the upper column cover.
4. Remove the ignition key illumination bulb.
5. Install in the reverse order of removal.

Scheme 74

1. Disconnect the negative battery cable.
2. Remove the lower column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) .
3. Remove the coil antenna. See «COIL ANTENNA REMOVAL/INSTALLATION [ADVANCED KEYLESS SYSTEM]»(ref-345344-S03163858982009102000000) .
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 75

1. Remove the socket by turning it in the direction shown by the arrow.

Scheme 76

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 77

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 78

1. Insert a tape-wrapped flathead screwdriver into the service hole, and pry it in the direction indicated by the arrow to remove the lens.

Scheme 79

Scheme 80

1. Remove the sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) .
2. Verify that the continuity between the vanity mirror illumination terminals is as indicated in the table. If not as indicated in the table, inspect the bulb. If there is no malfunction, replace the sunvisor.

Scheme 81

1. Disconnect the negative battery cable.
2. Remove the front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) .
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 82

1. Disconnect the negative battery cable.
2. Remove the front door trim. See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-345331-S18852454002009102000000) .
3. Remove the handle pull. See «FRONT DOOR TRIM DISASSEMBLY/ASSEMBLY»(ref-345331-S33628001362009102000000) .
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 83

1. Open the cover in the direction of the arrow and remove the front door pocket indirect illumination.

Scheme 84

1. Disconnect the negative battery cable.
2. Remove the rear door trim. See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-345331-S20461355772009102000000) )
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 85

1. Open the cover in the direction of the arrow and remove the rear door pocket indirect illumination.

Scheme 86

1. Disconnect the negative battery cable.
2. Disassemble in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 87

Scheme 88

1. Verify that the continuity between door switch terminal and the body ground is as indicated in the table. If not as indicated in the table, replace the door switch.
