Sunroof: Overview Mazda CX-9 I

Scheme 1

Scheme 2

1. Fully open the glass panel.
2. Press the spring in the direction shown by the arrow and remove it from the hook.
3. Remove the deflector.
4. Install in the reverse order of removal.

Scheme 3

Scheme 4

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. See «GLASS PANEL ADJUSTMENT»(ref-345437-S13389571352009102000000) .

Scheme 5

Scheme 6

1. Fully close the glass panel.
2. Measure the gap and height between the glass panel and body.
3. If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance a:0-2.7 mm {0-0.106 in} b: 0 mm {0 in}
4. Tighten the installation screws.
5. Insert a plastic card between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the credit card is moved). If the sunroof is not shut tightly, readjust by performing Steps 3 and 4 .

Scheme 7

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) .
3. Remove the sunroof seaming welt.
4. Remove the headliner.. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) .
5. Remove the glass panel. See «GLASS PANEL REMOVAL/INSTALLATION»(ref-345437-S41941876592009102000000) .
6. Disconnect the front and rear drain hose from the sunroof frame.
7. Remove the bolts.
8. Remove the nuts, and then remove the sunroof unit.
9. Install in the reverse order of removal.
10. Adjust the glass panel.. See «GLASS PANEL ADJUSTMENT»(ref-345437-S13389571352009102000000) .

Note. If the guide or sunroof motor is removed, the glass panel will not be positioned properly after the re-installation. To ensure proper positioning of the glass panel, place alignment marks on the guide pin and frame before removing the guide or sunroof motor.

Scheme 8

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Note. If the guide or sunroof motor is removed, the sunroof motor initial position setting has to be performed. After installing the sunroof unit, perform the initial position setting using the following procedure.

1. The initialization mode starts after approx. 13 s from when the tilt up switch has been pressed and held. The glass stops after it has moved approx. 30 mm {1.2 in} towards the closed position. NOTE: Only the tilt up switch is available during the initialization mode. The initialization may finish at the first inching operation depending on the glass position when the motor is installed. If the glass position is between the closed and semi-tilt positions when the motor is removed, the glass moves in the tilt up direction (to the full tilt position stored in the motor). However, if the tilt up switch is pressed and held, the initialization mode starts.
2. When the tilt up switch is pressed again, the glass continues to move approx. 30 mm {1.2 in} and stops.
3. Repeat this procedure several times so that the glass moves to the fully closed, full tilt (normal operation position), and full tilt (mechanical stopper position) positions.
4. After the glass is moved to the full tilt position (mechanical stopper position), it returns to the tilt down direction slightly and the initialization is completed.
