Sunroof: Overhaul Mazda CX-9 I

Sun Roof/t-Top/convertible Top 6 illustrations ~544 words

Rear Drip Assembly Note

Note. If the rear drip is removed, butyl seal must be applied when re-installing.

Scheme 14

Scheme 14: Rear Drip Assembly Note
Scheme 14: Rear Drip Assembly Note
  1. Apply a 6.0-8.0 mm {0.24-0.31 in} wide line of butyl seal to the area shown in the figure.

Scheme 15

Scheme 15: Guide Disassembly Note
Scheme 15: Guide Disassembly Note

Scheme 16

Scheme 16
Scheme 16
  1. Place an alignment mark on the guide pin and flame.
  2. Slide the guide to the rear of the sunroof frame, and remove the guide and decoration link as a single unit.

Scheme 17

Scheme 17: Guide Assembly Note
Scheme 17: Guide Assembly Note
  1. Move the pin to the position shown in the figure.

Scheme 18

Scheme 18: Decoration Link Assembly Note
Scheme 18: Decoration Link Assembly Note
  1. Set the guide pin to the decoration link.

Scheme 19

Scheme 19: FRONT DRAIN HOSE REMOVAL
Scheme 19: FRONT DRAIN HOSE REMOVAL
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Front seat belt lower anchor installation bolt (Driver side). See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar lower trim. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S40781975872009102000000) . Front seat belt upper anchor installation bolt. See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S03975048282009102000000) . B-pillar upper trim. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S19168328582009102000000) . Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Second-row seat belt upper anchor installation bolt. See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S40666828502009102000000) . C-pillar trim. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S41987911772009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) . Front map light. See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-345339-S14093089532009102000000) . Sunvisor. See «SUNVISOR REMOVAL/INSTALLATION»(ref-345331-S03157284332009102000000) . Assist handle. See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345331-S16702384632009102000000) . RES unit cover (Vehicles with RES). See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) . Headliner. See «HEADLINER REMOVAL/INSTALLATION»(ref-345331-S02660874092009102000000) . Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-345331-S24413902932009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) . Dashboard under cover. See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) . Side wall. See «SIDE WALL REMOVAL/INSTALLATION»(ref-345331-S28735626472009102000000) . Console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-345331-S12921188482009102000000) . Console cover. See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-345331-S33051633072009102000000) . Console. See «CONSOLE REMOVAL/INSTALLATION»(ref-345331-S33017209812009102000000) . Front side trim. See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S41141327992009102000000) . Glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-345331-S00629389742009102000000) . Hood release lever. See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-345344-S38720975792009102000000) . Lower panel. See «LOWER PANEL REMOVAL/INSTALLATION»(ref-345331-S27563849592009102000000) . Column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) . Driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-345337-S10259074632009102000000) . Steering wheel. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . Combination switch. See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-345339-S03518932132009102000000) . Center panel. See «CENTER PANEL REMOVAL/INSTALLATION»(ref-345331-S22152336712009102000000) . Meter hood. See «METER HOOD REMOVAL/INSTALLATION»(ref-345331-S34116172672009102000000) . Instrument cluster. See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-345363-S11148620752009102000000) . Audio unit. See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-345330-S42396879762009102000000) . Steering shaft. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . Side panel. See «SIDE PANEL REMOVAL/INSTALLATION»(ref-345331-S06165285212009102000000) . Dashboard. See «DASHBOARD REMOVAL/INSTALLATION»(ref-345331-S28664278972009102000000) .
  4. Disconnect the front drain hose from the sunroof frame.
  5. Remove the front drain hose from the clips.
  6. Pull the front drain hose into the room side.
  7. Remove the front drain hose.
