Automatic Transaxle Shift Mechanism: Removal & Installation Mazda CX-5 I

Selector Cable (Selector Lever Side) Installation Note

1. Verify that the selector lever is in the P position.
2. Verify that the manual shaft is in the P position. see scheme 19: Setting Manual Shaft To P Position
3. Press in the lock piece in the direction of the arrow (1) shown in the figure, press in the safety lock in the direction of the arrow (2) shown in the figure, and lock it. see scheme 20: Removing Selector Cable (Selector Lever Side)

Scheme 1254

1. Assemble the cable outer end (transaxle side) to the bracket so that the marking is in the area of the arrow shown in the figure. (Scheme 1254): Locating Marking Area Between Cable Outer End And Bracket

Scheme 1255

1. Switch the ignition ON (engine off or on).
2. Perform the following procedures to inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-615439-S02571559392014051000000) ). Verify that the selector lever can be operated as shown in the figure. Verify that the selector lever can be operated smoothly and moderately. (Scheme 1255): Checking Selector Lever Operation

Shift-Lock System Inspection

1. Switch the ignition ON (engine off).
2. Shift the selector lever to the P position.
3. Verify that the selector lever cannot be shifted from P to R position when the brake pedal is released. If it can be verified, go to the next step. If not as verified, inspect the following parts: Shift-lock solenoid (See «SHIFT-LOCK SYSTEM INSPECTION»(ref-615439-S03352018522014051000000) ). Not P position switch (See «NOT P POSITION SWITCH INSPECTION»(ref-615439-S42694762962014051000000) ). Brake switch (See «BRAKE SWITCH INSPECTION»(ref-615413-S31954500032014051000000) ). Start stop unit (See «START STOP UNIT INSPECTION»(ref-615426-S02790603172014051000000) ). PCM (See «PCM INSPECTION [SKYACTIV-G 2.0]»(ref-615396-S32068462542014051000000) ).
4. Verify that the selector lever can be shifted from P to R position when the brake pedal is depressed. If it can be verified, go to the next step. If not as verified, inspect the following parts: Shift-lock solenoid (See «SHIFT-LOCK SYSTEM INSPECTION»(ref-615439-S03352018522014051000000) ). Not P position switch (See «NOT P POSITION SWITCH INSPECTION»(ref-615439-S42694762962014051000000) ). Brake switch (See «BRAKE SWITCH INSPECTION»(ref-615413-S31954500032014051000000) ). Start stop unit (See «START STOP UNIT INSPECTION»(ref-615426-S02790603172014051000000) ). PCM (See «PCM INSPECTION [SKYACTIV-G 2.0]»(ref-615396-S32068462542014051000000) ).

Shift-Lock Solenoid Inspection

Note. The shift-lock solenoid is built into the selector lever component.

Scheme 1256

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ).
3. Reconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
4. Verify that the voltages of each of the selector lever component terminals are as indicated in the table. (Scheme 1256): Identifying Selector Lever Component Connector

SHIFT-LOCK SOLENOID SPECIFICATION

1. If the voltage is not as indicated in the table, repair or replace the related wiring harness.
2. If the voltage can be verified as indicated in the table, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-615439-S02571559392014051000000) ).

Scheme 1257

1. Switch the ignition to off.
2. Verify that the selector lever is in the P position.
3. Without the brake pedal depressed, verify that the selector lever cannot be shifted from the P position.
4. Remove the emergency override hole cover using a tape-wrapped flathead screwdriver.
5. Insert the flathead screwdriver into the emergency override hole and push it down.
6. Verify that the selector lever can be shifted from the P position. If not as verified, replace the selector lever. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-615439-S02571559392014051000000) ). (Scheme 1257): Removing Emergency Override Hole Cover Using Tape-Wrapped Flathead Screwdriver
