No Torque Converter Clutch
Check PCM and/or wiring, check valve body and torque converter.
Torque Converter Clutch Always Engaged
Check PCM and/or wiring, valve body, oil pump, torque converter and/or damaged transaxle case.
Torque Converter End Play Check
With torque converter removed from transaxle, position End Play Checking Device (49 UN01 123 ) and Sleeve (49 UN01 120 ) in converter hub. Tighten nut on device. Position a dial indicator on device. Position dial indicator pointer on the converter shell. (Scheme 1) Lift up on device handles. If dial indicator reading exceeds.050" (1.27 mm), replace converter.
Scheme 1
Torque Converter Leakage Check
With torque converter removed from transaxle, check for leakage using torque converter leak tester.
One-Way Clutch Check
Place 90 degree end of pick tool in slot on bottom of converter stator. While holding pick, rotate inner race with fingers. One-way clutch should not rotate in counterclockwise direction and should rotate in clockwise direction. Replace converter if one-way clutch does not operate as specified.
Turbine Torque Check
Install End Play Checking Tool (49 UN01 123 ) with Sleeve (49 UN01 120 ) into turbine splines in converter. Using torque wrench, measure turbine turning torque. Replace converter if torque exceeds 71 INCH lbs. (8 N.m).
TORQUE SPECIFICATIONS
| Application | Ft Lbs. (N.m) |
|---|---|
| Axle Nut | 131-173 (174-235) |
| Drain Plug | 11-26 (15-35) |
| Ball Joint Clamp Bolt | 25-42 (34-57) |
| Bearing Bracket Bolt | 31-46 (42-62) |
| Main Control Cover Bolt | 10-13 (14-18) |
| Manual Control Lever Bolt | 18-22 (24-30) |
| Stabilizer Link Nut | 27-40 (36-54) |
| Steering Knuckle Clamp Bolt | 25-42 (34-57) |
| Tie Rod End Nut | 20 (28) |
| Transaxle Case Bolt | 15-18 (20-24) |
| Transmission Speed Sensor Bolt | 11 (15) |
| Wheel Lug Nut | 65-87 (88-118) |
| INCH Lbs. (N.m) | |
| Accumulator-To-Transfer Plate Bolt | 89 (10) |
| Valve Body-To-Transfer Plate Bolt | 89 (10) |
| Manual Valve Lever Ball Stud Nut | 96-117 (11-13) |
| Oil Level Control Valve Bolt | 96-117 (11-13) |
| Oil Pump Bolt | 117 (13) |
| Pressure Tap Plate Bolt | 71 (8) |
| Transmission Speed Sensor | 106-124 (12-14) |
| Valve Body-To-Transaxle Case Bolt | 80-96 (9-11) |
| Vehicle Speed Sensor Bolt | 44-53 (5-6) |
TORQUE SPECIFICATIONS
TRANSAXLE SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Direct Clutch Pack Clearance | .020-.044 (.52-1.12) |
| Forward/Coast Clutch Pack Clearance | .019-.043 (.50-1.09) |
| Reverse Clutch Pack Clearance | .012-.035 (.33-.89) |
| Low/Reverse Clutch Pack Clearance | .021-.046 (.54-1.17) |
| Low/Intermediate Planetary Thrust Clearance | .006-.028 (.15-.72) |
| Oil Pump Drive Gear Clearance | .0015-.0030 (.040-.080) |
| Oil Pump Driven Gear Clearance | .0015-.0030 (.040-.080) |
| Reverse/OD Planetary Thrust Clearance | .006-.028 (.15-.72) |
| INCH Lbs. (N.m) | |
| Oil Pump Rotating Torque | 2 (.3) |
TRANSAXLE SPECIFICATIONS
