Diagnosis - LA4A-EL: Specifications Mazda 626 GF

Automatic Trans 3 illustrations

Torque Converter Engagement

CAUTIONDO NOT depress TCC switch with transmission in gear and vehicle at a stop. Damage to TCC may result.

Accelerate and upshift vehicle into 3rd gear. Maintain constant speed and depress TCC switch. Torque converter clutch should engage and engine RPM should decrease.

TRANSAXLE ELECTRICAL SPECIFICATIONS

ApplicationResistance/Ohms
Shift Solenoid12.0-22.0
TCC Solenoid12.5-19.0
EPC Solenoid3.8-5.9
TSS140.0-290.0

LA4A-EL ELECTRICAL SPECIFICATIONS

Transaxle Wiring Diagram (1997 626 & MX-6 2.0L). Scheme 32

Scheme 32: Transaxle Wiring Diagram (1997 626 & MX-6 2.0L)
Scheme 32: Transaxle Wiring Diagram (1997 626 & MX-6 2.0L)

Transaxle Wiring Diagram (1998 626 2.0L). Scheme 33

Scheme 33: Transaxle Wiring Diagram (1998 626 2.0L)
Scheme 33: Transaxle Wiring Diagram (1998 626 2.0L)

Transaxle Wiring Diagram (1999 626 2.0L). Scheme 34

Scheme 34: Transaxle Wiring Diagram (1999 626 2.0L)
Scheme 34: Transaxle Wiring Diagram (1999 626 2.0L)
