Entertainment System: Component Locations Mazda 6 GJ

Entertainment Systems 16 illustrations ~1272 words

ANTENNA FEEDER LOCATION

Note. GPS antenna feeder is integrated in the instrument panel wiring harness. (Scheme 45): Antenna Feeder Location

Scheme 45

Scheme 45: ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION
Scheme 45: ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-581615-S41865543102013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S10735079002013101400000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-581620-S26915536712013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-581651-S30763301102013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Audio unit (With audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000).) Car-navigation unit (With car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-581616-S02637365352013101400000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-581614-S07883015262013101400000).) SIRIUS satellite radio unit (With SIRIUS satellite radio system) (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-581616-S38070671012013101400000).) aa. Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S16434598032013101400000).) ab. A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) ac. Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-581614-S23273769092013101400000).)
  3. Remove the clips A and B.
  4. Remove the antenna feeder No.1.
  5. Install in the reverse order of removal. (Scheme 46): Antenna Feeder No.1, Dashboard, Clip A And B (With Audio System) (Scheme 47): Antenna Feeder No.1, Dashboard, Connector, Clip A And B (With Car-Navigation System)

Scheme 47

Scheme 47: ANTENNA FEEDER NO.1 INSPECTION
Scheme 47: ANTENNA FEEDER NO.1 INSPECTION

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000).) Audio unit (With audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000).) Car-navigation unit (With car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-581616-S02637365352013101400000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).)
  3. Disconnect the antenna feeder No.2. (Scheme 48): Antenna Feeder No.1 And No.2
  4. Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table. (Scheme 49): Checking Antenna Feeder No.1 Connector Terminals (With Audio System) (Scheme 50): Checking Antenna Feeder No.1 Connector Terminals (With Car-Navigation System) If not as indicated in the table, replace antenna feeder No.1. (Scheme 51): Antenna Feeder No.1 Terminals Continuity Chart (With Audio System) (Scheme 52): Antenna Feeder No.1 Terminals Continuity Chart (With Car-Navigation System)

Scheme 52

Scheme 52: ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION
Scheme 52: ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
  5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
  6. Peel off the tape and remove antenna feeder No.2.
  7. Install in the reverse order of removal. (Scheme 53): Antenna Feeder No.2, Headliner And Tape

Scheme 53

Scheme 53: ANTENNA FEEDER NO.2 INSPECTION
Scheme 53: ANTENNA FEEDER NO.2 INSPECTION

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56
  1. Disconnect the negative battery cable.
  2. Remove the following parts: A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (RH) (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (RH) (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
  3. Disconnect the antenna feeder No.1. (Scheme 54): Antenna Feeder No.1
  4. Disconnect the antenna feeder No.3. (Scheme 55): Antenna Feeder No.3
  5. Verify that the continuity between antenna feeder No.2 terminals is as indicated in the table. (Scheme 56): Checking Continuity Between Antenna Feeder No.2 Terminals If not as indicated in the table, replace antenna feeder No.2. (Scheme 57): Antenna Feeder No.2 Terminals Continuity Chart

Scheme 57

Scheme 57: ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION
Scheme 57: ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
  5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
  6. Disconnect the connector.
  7. Remove the clips A and B. (Scheme 58): Antenna Feeder No.3, Connector, Clips A And B
  8. Remove the antenna feeder No.3.
  9. Install in the reverse order of removal.

Scheme 58

Scheme 58: ANTENNA FEEDER NO.3 INSPECTION
Scheme 58: ANTENNA FEEDER NO.3 INSPECTION

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. Disconnect the negative battery cable.
  2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
  4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
  5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
  6. Disconnect the antenna feeder No.2. (Scheme 59): Antenna Feeder No.2
  7. Verify that the continuity between antenna feeder No.3 terminals is as indicated in the table. (Scheme 60): Checking Continuity Between Antenna Feeder No.3 Terminals If not as indicated in the table, replace antenna feeder No.3. see scheme 68: Antenna Feeder No.3 Terminals Continuity Chart
