Entertainment System: Other Mazda 6 GJ

Entertainment Systems 32 illustrations ~1225 words

Welcome Mode ON/OFF Setting

Note. Welcome mode is controlled by the instrument cluster. Refer to the instrument cluster description.

  1. Refer to «INSTRUMENTATION/DRIVER INFO. PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-581651-S35664845842013101400000) .

Scheme 61

Scheme 61: With audio unit (without display only)
Scheme 61: With audio unit (without display only)

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63
  1. Switch the ignition to ACC or ON.
  2. Turn the audio unit power to ON.
  3. Press the AUDIO CONT switch. (Scheme 61): Audio Control Switch
  4. Select "Welcome ON" or "Welcome OFF". (Scheme 62): Welcome Sound On/Off Setting Procedure Flow Chart
  5. Press the AUDIO CONT switch.
  6. Select "ON" or "OFF". (Scheme 63): Audio Cont Tune On And Off Position

Scheme 64

Scheme 64: With car-navigation unit
Scheme 64: With car-navigation unit

Scheme 65

Scheme 65
Scheme 65
  1. Switch the ignition to ACC or ON.
  2. Turn the car-navigation unit power to ON.
  3. Press the DISP switch (panel switch). (Scheme 64): DISP Switch
  4. Select "SETTINGS".
  5. Select "ON" or "OFF". (Scheme 65): Screen Display - Settings (Car-Navigation Unit)

Scheme 66

Scheme 66: CAR-NAVIGATION UNIT REMOVAL/INSTALLATION
Scheme 66: CAR-NAVIGATION UNIT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000).)
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal. CAUTION: When installing the car-navigation unit, make sure that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the wiring harness or the antenna feeder is caught between the unit and dashboard, it may cause malfunctions. (Scheme 66): Car-Navigation Unit, Screw, Bolt, Connector And Antenna Feeder With Torque Specification

Scheme 67

Scheme 67: Car-Navigation Unit Removal Note
Scheme 67: Car-Navigation Unit Removal Note
  1. Pull the car-navigation unit outward, detach tab, clip from the dashboard, and then remove the car-navigation unit. (Scheme 67): Car-Navigation Unit Tabs And Clips

Scheme 68

Scheme 68: AUDIO AMPLIFIER REMOVAL/INSTALLATION
Scheme 68: AUDIO AMPLIFIER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).)
  3. Remove in the order indicated in the table. (Scheme 68): Audio Amplifier, Connector, Bolt And Nut With Torque Specification
  4. Install in the reverse order of removal.

Scheme 69

Scheme 69: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 69: FRONT DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 70

Scheme 70
Scheme 70
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
  4. Remove in the order indicated in the table. (Scheme 69): Identifying Front Door Speaker, Screw And Connector (With Bose®) (Scheme 70): Identifying Front Door Speaker, Screw And Connector (Without Bose®)
  5. Install in the reverse order of removal.

Scheme 71

Scheme 71: Front Door Speaker Removal Note
Scheme 71: Front Door Speaker Removal Note

Scheme 72

Scheme 72
Scheme 72
  1. Remove the front door speaker in the direction of the arrow shown in the figure. (Scheme 71): Removing Front Door Speaker (With Bose®) (Scheme 72): Removing Front Door Speaker (Without Bose®)

Scheme 73

Scheme 73: FRONT DOOR SPEAKER INSPECTION
Scheme 73: FRONT DOOR SPEAKER INSPECTION

Scheme 74

Scheme 74
Scheme 74
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
  4. Remove the front door speaker. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S15222844692013101400000).)
  5. Verify the resistance between the front door speaker terminals. (Scheme 73): Front Door Speaker Circuit If not within the specification, replace the front door speaker. (Scheme 74): Front Door Speaker Terminal Resistance Chart Resistance Without Bose®: 3.4-4.6 ohms With Bose®: 1.83-2.47 ohms

Scheme 75

Scheme 75: REAR DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 75: REAR DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 76

Scheme 76
Scheme 76
  1. Disconnect the negative battery cable.
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S26913575372013101400000).)
  3. Remove in the order indicated in the table. (Scheme 75): Identifying Rear Door Speaker, Connector And Screws (With Bose®) (Scheme 76): Identifying Rear Door Speaker, Connector And Screws (Without Bose®)
  4. Install in the reverse order of removal.

Scheme 77

Scheme 77: Rear Door Speaker Removal Note
Scheme 77: Rear Door Speaker Removal Note

Scheme 78

Scheme 78
Scheme 78
  1. Remove the rear door speaker in the direction of the arrow shown in the figure. (Scheme 77): Removing Rear Door Speaker (With Bose®) (Scheme 78): Removing Rear Door Speaker (Without Bose®)

Scheme 79

Scheme 79: REAR DOOR SPEAKER INSPECTION
Scheme 79: REAR DOOR SPEAKER INSPECTION

Scheme 80

Scheme 80
Scheme 80
  1. Disconnect the negative battery cable.
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S26913575372013101400000).)
  3. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S17737955772013101400000).)
  4. Verify the resistance between the rear door speaker terminals. (Scheme 79): Rear Door Speaker Circuit If not within the specification, replace the rear door speaker. (Scheme 80): Rear Door Speaker Terminal Resistance Chart Resistance Without Bose®: 3.4-4.6 ohms With Bose®: 1.83-2.47 ohms

Scheme 81

Scheme 81: FRONT CENTER SPEAKER REMOVAL/INSTALLATION
Scheme 81: FRONT CENTER SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).)
  3. Remove in the order indicated in the table. (Scheme 81): Front Center Speaker And Screw
  4. Install in the reverse order of removal.

Scheme 82

Scheme 82: FRONT CENTER SPEAKER INSPECTION
Scheme 82: FRONT CENTER SPEAKER INSPECTION

Scheme 83

Scheme 83
Scheme 83
  1. Disconnect the negative battery cable.
  2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).)
  3. Remove the front center speaker. (See «FRONT CENTER SPEAKER REMOVAL/INSTALLATION»(ref-581616-S39245013282013101400000).)
  4. Verify the resistance between the front center speaker terminals. (Scheme 82): Front Center Speaker Circuit If not within the specification, replace the front center speaker. (Scheme 83): Front Center Speaker Terminal Resistance Chart Resistance 2.24-3.96 ohms

Scheme 84

Scheme 84: REAR CENTER SPEAKER REMOVAL/INSTALLATION
Scheme 84: REAR CENTER SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000) ) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) ) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
  3. Remove in the order indicated in the table. (Scheme 84): Rear Center Speaker, Connector And Screws
  4. Install in the reverse order of removal.

Scheme 85

Scheme 85: REAR CENTER SPEAKER INSPECTION
Scheme 85: REAR CENTER SPEAKER INSPECTION

Scheme 86

Scheme 86
Scheme 86
  1. Disconnect the negative battery cable.
  2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000) ) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) ) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-581614-S05682126252013101400000).)
  3. Verify the resistance between the rear center speaker terminals. (Scheme 85): Rear Center Speaker Circuit If not within the specification, replace the rear center speaker. (Scheme 86): Rear Center Speaker Terminal Resistance Chart Resistance 0.9-1.1 ohms

Scheme 87

Scheme 87: REAR SPEAKER REMOVAL/INSTALLATION
Scheme 87: REAR SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000) ) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) ) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
  3. Remove in the order indicated in the table. (Scheme 87): Rear Speaker, Connector And Screws
  4. Install in the reverse order of removal.

Scheme 88

Scheme 88: REAR SPEAKER INSPECTION
Scheme 88: REAR SPEAKER INSPECTION

Scheme 89

Scheme 89
Scheme 89
  1. Disconnect the negative battery cable.
  2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000) ) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) ) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-581614-S05682126252013101400000).) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S32103152162013101400000).)
  3. Verify the resistance between the rear speaker terminals. (Scheme 88): Rear Speaker Circuit If not within the specification, replace the rear speaker. (Scheme 89): Rear Speaker Terminal Resistance Chart Resistance 2.24-3.96 ohms

Scheme 90

Scheme 90: TWEETER REMOVAL/INSTALLATION
Scheme 90: TWEETER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
  3. Remove the tweeter in the direction of the arrow shown in the figure. (Scheme 90): Tweeter Removal Direction
  4. Install in the reverse order of removal.

Scheme 91

Scheme 91: TWEETER INSPECTION
Scheme 91: TWEETER INSPECTION

Scheme 92

Scheme 92
Scheme 92
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
  3. Remove the tweeter. (See «TWEETER REMOVAL/INSTALLATION»(ref-581616-S28073137732013101400000).)
  4. Verify the resistance between tweeter terminals. (Scheme 91): Tweeter Circuit If not within the specification, replace the tweeter. (Scheme 92): Tweeter Terminal Resistance Chart Resistance Without Bose®: 3.4-4.6 ohms With Bose®: 3.06-3.94 ohms
