Entertainment System: Removal & Installation Mazda 6 GJ

AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION

Note. "AudioPilot®2" is a registered trademark of Bose® Corporation.

Scheme 20

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table. (Scheme 20): AudioPilot®2 Microphone, Bolt And Connector With Torque Specification
3. Install in the reverse order of removal.

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
6. Remove in the order indicated in the table. (Scheme 21): SIRIUS Satellite Radio Antenna, Nut And Connector With Torque Specification
7. Install in the reverse order of removal.
8. After installation, verify that waterproof rubber of the SIRIUS satellite radio antenna is installed to the roof panel without any gaps.
9. After installing the SIRIUS satellite radio antenna, verify that the gap between the SIRIUS satellite radio antenna and roof panel is within the following range. Standard values 0.6 mm {0.02 in} Maximum values 1.2 mm {0.047 in} Minimum values 0 mm {0 in} Side by difference 0.7 mm {0.03 in}

Scheme 22

1. Remove the SIRIUS satellite radio antenna in the direction of the arrow (2) shown in the figure while pressing the SIRIUS satellite radio antenna tabs in the direction of the arrow (1). (Scheme 22): SIRIUS Satellite Radio Antenna And Components

Scheme 23

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).) SIRIUS satellite radio antenna (See «SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION»(ref-581616-S05921457352013101400000).)
6. Verify that the continuity between SIRIUS satellite radio antenna terminals is as indicated in the table. (Scheme 23): SIRIUS Satellite Radio Antenna Connector Terminals If not as indicated in the table, replace the SIRIUS satellite radio antenna. (Scheme 24): SIRIUS Satellite Radio Antenna Terminals Continuity Chart

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Disconnect the antenna amplifier connector B. (See «ANTENNA AMPLIFIER REMOVAL/INSTALLATION»(ref-581616-S22172811632013101400000).)
3. Inspect the glass antenna for damage visually.
4. Inspect for continuity between the glass antenna terminals using an ohmmeter. (Scheme 25): Glass Antenna Connector If not as specified, repair the glass antenna. (See «FILAMENT REPAIR»(ref-581623-S20479084132013101400000).) (Scheme 26): Glass Antenna Terminals Continuity Chart

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
6. Remove in the order indicated in the table. (Scheme 27): Antenna Amplifier, Bolt, Clip, Connector A And B With Torque Specification
7. Install in the reverse order of removal.

Scheme 28

1. Remove the connector B in the direction of the arrow (2) shown in the figure while pressing the glass antenna terminal in the direction of the arrow (1). (Scheme 28): Antenna Amplifier Connector B

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
3. Disconnect the rain sensor connector. (with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-581623-S34107739722013101400000).) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-581623-S28262716272013101400000).)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
6. Connect the negative battery cable.
7. Switch the ignition to ON.
8. Turn the audio unit power to ON.
9. Tune in the radio.
10. Verify that voltage is B+ at the antenna amplifier terminal A. (Scheme 29): Antenna Amplifier Connector Terminals If not as replace antenna amplifier.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).)
3. Remove in the order indicated in the table. (Scheme 30): SIRIUS Satellite Radio Unit, Connector And Screws
4. Install in the reverse order of removal.

Scheme 31

1. Spread the SIRIUS satellite radio unit bracket apart in the direction of the arrow shown in the figure (1) to remove the SIRIUS satellite radio unit (2). (Scheme 31): Spreading SIRIUS Satellite Radio Unit Bracket

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000) ) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) ) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
3. Remove in the order indicated in the table. (Scheme 32): Condenser, Connector And Bolts With Torque Specification
4. Install in the reverse order of removal.

SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION

Note. SIRIUS satellite radio antenna feeder is integrated with the antenna feeder.

1. Refer to «ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION»(ref-581616-S31939097612013101400000) .
2. Refer to «ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION»(ref-581616-S03136847242013101400000) .
3. Refer to «ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION»(ref-581616-S09728666192013101400000) .

GPS ANTENNA FEEDER REMOVAL/INSTALLATION

Note. GPS antenna feeder is integrated with the antenna feeder No.1.

1. Refer to «ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION»(ref-581616-S31939097612013101400000) .

REAR MOUNT CAMERA REMOVAL/INSTALLATION

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-581614-S10051324362013101400000).)
3. Remove the rear finisher. (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-581657-S20520189782013101400000).)
4. Remove the clip.
5. Disconnect the connector.
6. Remove the rear mount camera in the direction of the arrow (2) shown in the figure while pressing the rear mount camera tab in the direction of the arrow (1). (Scheme 34): Rear Mount Camera And Components
7. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).) Audio amplifier (With Bose®) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-581616-S17006069772013101400000).)
3. Remove in the order indicated in the table. (Scheme 35): Bluetooth Unit, Connector And Nut With Torque Specification
4. Install in the reverse order of removal.

Scheme 35

Scheme 36

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).)
3. Remove in the order indicated in the table. (Scheme 36): Center Lower Panel, Accessory Socket (Front) And Cap (With Keyless Entry System) (Scheme 37): Center Lower Panel, Accessory Socket (Front) And Cap (With Advanced Keyless Entry And Push Button Start System)
4. Install in the reverse order of removal.

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-581614-S10948366582013101400000).)
3. Remove in the order indicated in the table. (Scheme 38): Rear Console, Accessory Socket (Rear) And Cap
4. Install in the reverse order of removal.

Scheme 38

1. Remove the socket in the direction of the arrow (2) shown in the figure while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover. (Scheme 39): Accessory Socket

Scheme 39

1. Remove the cap in the direction of the arrow (2) shown in the figure while pressing the cap tabs in the direction of the arrow (1). (Scheme 40): Removing Accessory Socket Cap

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).)
3. Connect a tester as shown in the figure and verify that there is continuity. (Scheme 41): Identifying Accessory Socket (Front) Connector Terminals If the continuity cannot be verified, replace the accessory socket (Front).

Scheme 41

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-581614-S10948366582013101400000).) Accessory socket (Rear) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-581616-S34657377962013101400000).)
3. Connect a tester as shown in the figure and verify that there is continuity. (Scheme 42): Identifying Accessory Socket (Rear) Connector Terminals If the continuity cannot be verified, replace the accessory socket (Rear).

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-581614-S10948366582013101400000).)
3. Remove the auxiliary jack in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack tabs in the direction of the arrow (1). (Scheme 43): Auxiliary Jack And Tabs
4. Install in the reverse order of removal.

Scheme 43

Scheme 44

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-581614-S10948366582013101400000).)
3. Connect a commercially-available nonresistant plug to the auxiliary jack. (Scheme 44): Connecting Commercially-Available Nonresistant Plug To Auxiliary Jack
4. Verify that the continuity between the auxiliary jack terminals is as indicated in the table. see scheme 93: Auxiliary Jack Terminals Continuity Reference Chart If not as indicated in the table, replace the auxiliary jack.
