COMBINATION SWITCH DISASSEMBLY/ASSEMBLY
| CAUTION | The clock spring is generally not to be removed from the combination switch as may result in a malfunction of the steering angle sensor. However, remove it only when replacing the clock spring as a single unit by referring to CLOCK SPRING REMOVAL/INSTALLATION. (See CLOCK SPRING REMOVAL/INSTALLATION. ) |
Scheme 79
- Disassemble in the order indicated in the table.
- Assemble in the reverse order of disassembly.
Scheme 80
Scheme 80: INBOARD COMBINATION LIGHT REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION [SPORT SEDAN].»(ref-288737-S28407969662008062500000) )
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 81
Scheme 81: Inboard Combination Light Installation Note
Scheme 82
- Insert the inboard combination light into the trunk lid as shown in the figure, then pivot it inward and fix in place.
- Place the bracket in the proper position as shown in the figure and press it to the trunk lid to attach.
Scheme 83
Scheme 83: STEERING ANGLE SENSOR INSPECTION
- Disconnect the steering angle sensor connector.
- Connect battery positive voltage to terminal A and ground to terminal F of the steering angle sensor.
- Turn the steering wheel to the right and left, and verify that the voltage and pulses at the terminals are as shown in the figure. If there is any malfunction, replace the body of the combination switch.
Scheme 84
Scheme 84: LIGHT SWITCH REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION.»(ref-288737-S02237188592008062500000) )
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
