Lighting Systems: Other Mazda 6 GH

Steering Column Switches 4 illustrations ~471 words

Discharge Headlight Control Module Reuse

  1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
  2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Scheme 85

Scheme 85: FRONT COMBINATION LIGHT REMOVAL/INSTALLATION
Scheme 85: FRONT COMBINATION LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION.»(ref-288739-S41552866532008062500000) )
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.
  5. Adjust the headlight aiming. (See «HEADLIGHT ADJUSTMENT»(ref-288774-S35317971952008062500000) ).

Scheme 86

Scheme 86: Halogen type
Scheme 86: Halogen type
  1. Disconnect the negative battery cable.
  2. Set the coolant reserve tank out of the way (RH).
  3. Remove in the order indicated in the table. CAUTION: A halogen bulb generates extremely high heat when it is used. If the surface of the bulb is soiled, excessive heat will build up and the lights life will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  4. Install in the reverse order of removal.

Discharge type

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS ).

Scheme 87

Scheme 87
Scheme 87
  1. Disconnect the negative battery cable.
  2. Set the coolant reserve tank out of the way (RH).
  3. Remove in the order indicated in the table. CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  4. Install in the reverse order of removal.

Scheme 88

Scheme 88: High-beam
Scheme 88: High-beam
  1. Disconnect the negative battery cable.
  2. Set the air cleaner case out of the way (LH). (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3].»(ref-288764-S40241065462008062500000) ) (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ].»(ref-288770-S05460329182008062500000) )
  3. Remove in the order indicated in the table. CAUTION: A halogen bulb generates extremely high heat when it is used. If the surface of the bulb is soiled, excessive heat will build up and the light's life will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  4. Install in the reverse order of removal.
