SUPPLIER IDENTIFICATION PROCEDURE
Note. The supplier can vary with the module. When asking the supplier (service center) for repair or replacement, identify the supplier and fill in the Audio Repair Order Form with the following procedures.
Identification Using the Label or Inscribed Lettering
- Remove the audio unit.
- Verify the supplier by referring to the label attached to each unit.
Identification Using the On-board Diagnostic Test Mode.
- Start the on-board diagnostic test mode.
- Identify the device and supplier codes by referring to the LCD display. NOTE: If no DTC is stored, no codes will be displayed.
| Supplier code | Supplier name |
|---|---|
| 1 | SANYO Automedia |
| 2 | Panasonic |
| 3 | Clarion |
| 4 | Pioneer |
SUPPLIER CODE AND NAME CHART
| Part number | Part name |
|---|---|
| 00 | Cassette deck |
| 03 | CD player |
| 06 | CD changer (upper module) |
| 07 | MD player |
| 09 | Base unit |
| 10 | MP3 applicable CD player system |
| 16 | CAN system |
| 17 | CAN system |
| 18 | CAN system |
| 19 | CAN system |
| 21 | Center panel |
| 22 | MP3 applicable CD changer |
PART NUMBER AND NAME CHART
Scheme 45
Scheme 46
- Start the on-board diagnostic test mode.
- While pressing the POWER button, simultaneously press the AUDIO CONT button for 2 s or more. CAUTION: Before clearing the memory, be sure to enter all of the DTCs displayed in the on-board diagnostic test mode in the Audio Repair Order Form.
- To stop the on-board diagnostic test mode, turn the ignition switch off.
