FOREWORD [ENTIRE AUDIO SYSTEM]
Note. Record all radio programs set by customer prior to the repairs. Reset all radio programs and adjust the time after repairs.
CONFIRMATION STEP 1: AUDIO PANEL SWITCH CONFIRMATION
- Make sure to verify the customer complaint and identify if it's either the center panel malfunction or audio unit malfunction.
How to activate audio panel switch confirmation mode
- Turn the audio system to ON.
- Press both POWER SW and MEDIA buttons for a second at the same time.
- The audio panel switch confirmation mode is now activated. DIAGNOSTIC PROCEDURE STEP INSPECTION ACTION 1 Press each button on the center panel. Does buzzer sound when pressing each button? Yes Make sure to confirm the customer complaint and then perform appropriate symptom troubleshooting procedure. No Go to the next step. 2 Disassemble and reassemble the center panel and audio unit. Activate the audio panel switch confirmation mode. Does buzzer sound when pressing each button? Yes Go to the next step. No Replace the center panel. 3 Does the audio system operate properly? Yes The system is normal. No Make sure to confirm the customer complaint and then perform appropriate symptom troubleshooting procedure.
CONFIRMATION STEP 2: AUDIO CONTROL SWITCH CONFIRMATION
- Make sure to verify the customer complaint and identify if it's either the audio control switch malfunction or audio unit malfunction.
| STEP | INSPECTION | ACTION |
|---|
| 1 | Is the symptom related to either the audio control switch or audio panel operation? | Yes | Make sure to verify the customer complaint and then perform appropriate symptom troubleshooting procedure. |
| No | The symptom is related to the audio panel operation: Follow the "Confirmation Step 1". The symptom is related to the audio control switch operation: Go to the next step. |
| 2 | Disconnect the audio unit connector (24-pin). Inspect both the audio unit and wiring harness-side connectors for poor connection, (such as damaged/pulled-out pins, corrosion). Terminal N (ST SW1) Terminal P (ST SW2) Are all the pins normal? | Yes | Go to the next step. |
| No | If the audio unit side connector is wrong: Replace the audio unit. If the wiring harness-side connector is wrong: Repair or replace the pins and/or the connector. |
| 3 | Inspect the continuity between the audio unit wiring harness-side connector terminal N and P while operating the audio control switch. Does the resistance change? | Yes | Make sure to verify the customer complaint and then perform appropriate symptom troubleshooting procedure. |
| No | Go to the next step. |
| 4 | Turn the ignition switch to the LOCK position. Remove the audio control switch. Inspect the continuity between the audio unit wiring harness-side connector (24-pin) terminal and the audio control switch wiring harness-side connector (8-pin) terminal. Terminal N (24-pin) - Terminal C (8-pin) Terminal P (24-pin) - Terminal D (8-pin) Is there the continuity? | Yes | Replace the audio control switch. |
| No | Repair or replace the suspect wiring harness. |
NO. 2 NO POWER ON THE ENTIRE AUDIO SYSTEM
| 2 | No power on the entire audio system/Possible DTC: 09:Er20 |
|---|
| Troubleshooting hints Poor connection of audio unit connector, terminal damage Audio unit malfunction Burnt fuse (B+) Burnt fuse (ACC) Open or short circuit in power supply (B+) wiring harness Open or short circuit in power supply (ACC) wiring harness |
NO. 3 NO SOUND FROM ALL SPEAKERS
| 3 | No sound from all speakers/Possible DTC: 00:Er10, 03:Er07, 03:Er10, 06:Er07, 06:Er10, 09:Er20, 09:Er21, 10:Er10, 11:Er10, 22:Er07, 22:Er10 |
|---|
| Troubleshooting hints Speaker malfunction (e.g., any foreign material, broken) Audio unit malfunction Short circuit in wiring harness between audio unit and speaker Short circuit inside speaker |
NO. 4 NO SOUND FROM CERTAIN SPEAKER
| 4 | No sound from certain speaker/Possible DTC |
|---|
| Troubleshooting hints Speaker malfunction (e.g., any foreign material, broken) Audio unit malfunction Short circuit inside speaker Open or short circuit in wiring harness between audio unit and speaker |
NO. 5 BROKEN SOUND OR POOR SOUND QUALITY
| 5 | Broken sound or poor sound quality/Possible DTC: 09:Er21 |
|---|
| Troubleshooting hints Speaker malfunction (e.g., any foreign material, broken) Improper speaker installation Audio unit malfunction Vibration of door trim and/or package trim |
NO. 6 SOUND BECOMES LOUDLY OR WEAKLY WHILE DRIVING THE VEHICLE
| 6 | Sound becomes loudly or weakly while driving the vehicle/Possible DTC |
|---|
| Troubleshooting hints Audio unit malfunction NOTE: Inspect the ALC function while driving the vehicle with playing the CD, etc. |
| NOTE |
|---|
| Inspect the ALC function while driving the vehicle with playing the CD, etc. |
NO. 7 ALC FUNCTION IS INOPERATIVE
| 7 | ALC function is inoperative/Possible DTC: 16:Er12, 17:Er11 |
|---|
| Troubleshooting hints Audio unit malfunction CAN signal wiring harness malfunction Open or short circuit in vehicle speed signal wiring harness (e. g., instrument cluster) NOTE: Inspect the ALC function while driving the vehicle with playing the CD, etc. |
| NOTE |
|---|
| Inspect the ALC function while driving the vehicle with playing the CD, etc. |
NO. 8 AUDIO SYSTEM ILLUMINATION DOES NOT ILLUMINATE AT ALL
| 8 | Audio system illumination does not illuminate at all/Possible DTC: 09:Er20, 21:Er19 |
|---|
| Troubleshooting hints Poor connection of audio unit connector, terminal damage Audio unit malfunction Burnt fuse (TNS signal) Open or short circuit in TNS signal wiring harness Center panel malfunction |
NO. 9 LCD DOES NOT DISPLAY AT ALL
| 9 | LCD does not display at all/Possible DTC: 09:Er20, 21:Er19 |
|---|
| Troubleshooting hints Audio unit malfunction Information display malfunction |
FOREWORD [RADIO]
Note. In case location, time, and broadcasting station etc. can be specified through interview to customer, possibility that signal environment causes problem is high. Perform confirmation of symptom and evaluation under conditions that customer reported (location, time, broadcasting station etc.). If not possible, perform it under equivalent conditions. Before inspection or repair, record the broadcasting stations that customer preset and reset them accordingly after the inspection or repair. Adjust the clock too.
NO. 1 NO RADIO RECEPTION (AM/FM)/NO OR LOW VOLUME
| 1 | No radio reception (AM/FM)/no or low volume/Possible DTC: 09:Er20, 09:Er22 |
|---|
| POSSIBLE CAUSE | Jamming from aftermarket electronic equipment (two-way radio, navigation system, mobile phone, etc.) Audio unit malfunction Antenna plug poor connection Antenna feeder malfunction Electronic jamming from outside, or inferior condition of broadcasting station radio wave Antenna rod is not installed |
POSSIBLE CAUSE CHART (SYMPTOM)
NO. 4 CANNOT TUNE (SEEK DOES NOT STOP)
| 4 | Cannot tune (seek does not stop)/Possible DTC: 09:Er20, 09:Er22 |
|---|
| POSSIBLE CAUSE | Center panel malfunction Antenna plug poor connection Antenna feeder malfunction Audio unit malfunction Electronic jamming from outside, or inferior condition of broadcasting station radio wave Antenna rod not installed |
POSSIBLE CAUSE CHART (SYMPTOM)
NO. 5 CANNOT PRESET (PRESET FUNCTION DOES NOT OPERATE)
| 5 | Cannot preset (preset function does not operate)/Possible DTC: 21:Er19 |
|---|
| POSSIBLE CAUSE | Audio unit malfunction Center panel malfunction |
POSSIBLE CAUSE CHART (SYMPTOM)
NO. 6 RECEPTION FREQUENCY OF RADIO SLIPS
| 6 | Reception frequency of radio slip/Possible DTC: 09:Er22 |
|---|
| POSSIBLE CAUSE | Audio unit malfunction Electronic jamming from outside, or inferior condition of broadcasting station radio wave |
POSSIBLE CAUSE CHART (SYMPTOM)
NO. 1 NO SOUND OF CASSETTE TAPE
| 1 | No sound of the cassette tape/Possible DTC: 00:Er01, 00:Er03, 00:Er10 |
|---|
| Troubleshooting hints Tape head gathers oxide residue from cassette tape Cassette tape is malfunctioning Cassette tape player is malfunctioning |
TROUBLESHOOTING REFERENCE
NO. 2 CASSETTE TAPE PLAYER DOES NOT EJECT THE CASSETTE TAPE
| 2 | Cassette tape player does not eject the cassette tape/Possible DTC: 00:Er01, 00:Er04, 00:Er10 |
|---|
| Troubleshooting hints Cassette tape is malfunctioning. Cassette tape player is malfunctioning. Cassette patch is broken. Poor installation of cassette patch. NOTE: The cassette tape player may not eject the cassette tape due to the tape slack, peel-off or seal on it. |
| NOTE |
|---|
| The cassette tape player may not eject the cassette tape due to the tape slack, peel-off or seal on it. |
TROUBLESHOOTING REFERENCE
NO. 3 CASSETTE TAPE PLAYER DOES NOT LOAD THE CASSETTE TAPE
| 3 | Cassette tape player does not load the cassette tape/Possible DTC: 00:Er01, 00:Er10 |
|---|
| Troubleshooting hints Cassette tape is malfunctioning Cassette tape player is malfunctioning Cassette patch is broken Poor installation of cassette patch Poor connection of cassette tape player connector |
TROUBLESHOOTING REFERENCE
NO. 4 CASSETTE TAPE PLAYER EJECT THE CASSETTE TAPE IMMEDIATELY
| 4 | Cassette tape player ejects the cassette tape immediately/Possible DTC: 00:Er04, 00:Er10 |
|---|
| Troubleshooting hints Cassette tape is malfunctioning Cassette tape player is malfunctioning |
TROUBLESHOOTING REFERENCE
NO. 5 WAVERING SOUND AND/OR POOR SOUND QUALITY OF THE CASSETTE TAPE
| 5 | Wavering sound and/or poor sound quality of the cassette tape/Possible DTC |
|---|
| Troubleshooting hints Cassette tape is malfunctioning. Cassette tape player is malfunctioning. |
TROUBLESHOOTING REFERENCE
NO. 7 POOR SOUND QUALITY (POOR TREBLE SOUND)
| 7 | Poor sound quality (Poor treble sound)/Possible DTC |
|---|
| Troubleshooting hints Tape head gathers oxide residue from cassette tape Cassette tape is malfunctioning Cassette tape player is malfunctioning Dolby noise reduction is used improperly |
TROUBLESHOOTING REFERENCE
NO. 8 ABNORMAL SOUND OF THE CASSETTE TAPE (PLAY BACKWARDS)
| 8 | Abnormal sound of the cassette tape (Play backwards)/Possible DTC |
|---|
| Troubleshooting hints Cassette tape is malfunctioning Cassette tape player is malfunctioning |
TROUBLESHOOTING REFERENCE
NO. 1 CD PLAYER/CHANGER DOES NOT LOAD THE CD OR EJECTS THE CD IMMEDIATELY
| 1 | CD player/changer does not load the CD or ejects the CD immediately Possible DTC: 03:Er01, 03:Er10, 06:Er01, 06:Er10, 10:Er01, 10:Er10, 22:Er01, 22:Er10 |
|---|
| Troubleshooting hints CD is inserted upside down Audio units is malfunctioning Defective CD (e.g., cracked, badly bent, rough edges, scratch, dirty CD, condensation) Non-conventional discs (e.g., 8 cm (3 in) CD, 8 cm (3 in) disc adapter, heart-shaped disc, octagonal disc) Poor connection of audio unit connector or terminal (e.g., damaged, bent, pulled-out pin, corrosion) Deformed disc is used (e.g., out of specification (thickness), bent disc) |
TROUBLESHOOTING REFERENCE
NO. 2 CD PLAYER/CHANGER DOES NOT EJECT THE CD
| 2 | CD player/changer does not eject the CD Possible DTC:03:Er01, 06:Er01, 10:Er01, 22:Er01 |
|---|
| Troubleshooting hints Audio units is malfunctioning Defective CD. (e.g., cracked, badly bent, rough edges, scratch, dirty CD, condensation) Non-conventional discs (e.g., 8 cm (3 in) CD, 8 cm (3 in) disc adapter, heart-shaped disc, octagonal disc) Poor connection of audio unit connector or terminal (e.g., damaged, bent, pulled-out pin, corrosion) Improper center panel installation Improper CD cover installation Deformed disc is used (e.g., out of specification (thickness), bent disc). Multiple CDs are inserted into the CD player at the same time NOTE: The CD may be malfunctioning if the CD player/changer does not eject the certain CD only. Inspect the CD player/changer operation using the CD known to be good. |
| NOTE |
|---|
| The CD may be malfunctioning if the CD player/changer does not eject the certain CD only. Inspect the CD player/changer operation using the CD known to be good. |
TROUBLESHOOTING REFERENCE
NO. 3 CD PLAYER/CHANGER DOES NOT PLAY THE CD/NO SOUND
| 3 | CD player/changer does not play the CD/No sound Possible DTC:03:Er07, 03:Er10, 06:Er07, 10:E07, 22:Er07 |
|---|
| Troubleshooting hints CD is inserted upside down Audio units is malfunctioning Defective CD (e.g., cracked, badly bent, rough edges, scratch, dirty CD, condensation) Non-conventional discs (e.g., 8 cm (3 in) CD, 8 cm (3 in) disc adapter, heart-shaped disc, octagonal disc) |
TROUBLESHOOTING REFERENCE
NO. 4 SOUND JUMPS
| 4 | Sound jumps Possible DTC:03:Er02, 06:Er02, 10:Er02, 22:Er02 |
|---|
| Troubleshooting hints Audio unit is malfunctioning Defective CD (e.g., cracked, badly bent, rough edges, scratch, dirty CD, condensation) Improper audio unit installation (e.g., rattle, loose) Inadequate tire pressure NOTE: The CD may be malfunctioning if the sound jumps on the certain CD only. Inspect the CD player/changer operation using the CD known to be good. |
| NOTE |
|---|
| The CD may be malfunctioning if the sound jumps on the certain CD only. Inspect the CD player/changer operation using the CD known to be good. |
TROUBLESHOOTING REFERENCE
NO. 5 CD PLAYER/CHANGER SCRATCHES ON THE CD
| 5 | CD player/changer scratches on the CD Possible DTC:03:Er02, 06:Er02, 10:Er02, 22:Er02 |
|---|
| Troubleshooting hints Audio unit is malfunctioning Deformed disc is used (e.g., out of specification (thickness), bent disc) Multiple CDs are inserted into the CD player at the same time |
TROUBLESHOOTING REFERENCE
NO. 6 DISC CHANGE IS INOPERATIVE
| 6 | Disc change is inoperative Possible DTC:06:Er01, 06:Er10, 22:Er01, 22:Er10 |
|---|
| Troubleshooting hints Audio unit is malfunctioning Improper center panel installation Center panel is malfunctioning |
TROUBLESHOOTING REFERENCE
NO. 7 CD PLAYER DOES NOT PLAY THE MP3-FORMATTED FILE
| 7 | CD player does not play the MP3-formatted file Possible DTC10:Er07, 22:Er07 |
|---|
| Troubleshooting hints CD-R/RW written format is out of specification MP3 and other format data are in the CD-R/RW File extension for MP3-formatted file is incorrect (Correct. ".mp3", incorrect: e.g., RIFF) Defective CD-R/RW (e.g. dirty CD, scratch) MP3 applicable CD player is malfunctioning NOTE: The free-software for the MP3-formatted file in the field may cause the deterioration of sound quality, noise, or defective play, so that the CD player won't play the customer made MP-3-formatted file. The CD player may not play the CD-R/RW properly due to the disc condition. If there are MP-3-formatted file and other file in the same disc, the CD player may not play the disc. If there are MP-3-formatted file and audio data in the same disc, the CD player loads and plays the first session of the data only. |
| NOTE |
|---|
| The free-software for the MP3-formatted file in the field may cause the deterioration of sound quality, noise, or defective play, so that the CD player won't play the customer made MP-3-formatted file. The CD player may not play the CD-R/RW properly due to the disc condition. If there are MP-3-formatted file and other file in the same disc, the CD player may not play the disc. If there are MP-3-formatted file and audio data in the same disc, the CD player loads and plays the first session of the data only. |
TROUBLESHOOTING REFERENCE
NO. 8 MP3-FORMATTED FILE FOLDER SELECTION IS INOPERATIVE/TRACK SEARCH IS INOPERATIVE
| 8 | MP3-formatted file folder selection is inoperative/Track search is inoperative Possible DTC:10:Er02, 22:Er02 |
|---|
| Troubleshooting hints Defective CD-R/RW (e.g. dirty CD, scratch) Conflict of ID tag version for CD-R/RW Improper folder and/or music title in CD-R/RW The number of characters of folder/audio file name in CD-R/RW exceeds the maximum number of characters Improper encode in CD-R/RW MP3 applicable CD player is malfunctioning |
TROUBLESHOOTING REFERENCE
Note. ID3 is a tagging format for MP3-formatted file. ID3 allows metadata (e.g., title, artist, track number, etc.) to be added to the MP3-formatted file. There are two versions in the ID tag. ID3v1: This is the most widespread standard tag formats and most software is compatible with this version. There is a limitation on the maximum number of characters for the text data. ID3v2: There are a variety of version in V2, but there is no interchangeability among the versions.
Limitation on the maximum number of characters for the text data (ID3v1)
| Item | Maximum number of characters | Description |
|---|
| Title | 30 | Music title |
| Artist | 30 | Artist name |
| Album | 30 | Album title |
| Year | 4 | Album produced year/CD wholesale year |
| Genre | | Music category selection |
| Comment | 30 | Free comment |
| Track | 3 | Track number |
NO. 9 CD PLAYER DOES NOT INDICATE THE MP3 TITLE TEXT
| 9 | CD player does not indicate the MP3 title text Possible DTC:10:Er02, 22:Er02 |
|---|
| Troubleshooting hints Defective CD-R/RW (e.g. dirty CD, scratch) Conflict of ID tag version for CD-R/RW The number of characters of folder/audio file name in CD-R/RW exceeds the maximum number of characters Improper encode in CD-R/RW MP3 applicable CD player is malfunctioning No title input in CD-R/RW Input title text by 2-bytes characters |
TROUBLESHOOTING REFERENCE
NO. 10 CD PLAYER DOES NOT PLAY THE AUDIO DATA (CDDA)
| 10 | CD player does not play the audio data (CDDA) Possible DTC:10:Er02, 22:Er02 |
|---|
| Troubleshooting hints CD-R/RW written format is out of specification Defective CD-R/RW (e.g., dirty CD, scratch) MP3 applicable CD player is malfunctioning Data other than the audio data is in CD-R/RW NOTE: The CD player may not play the CD-R/RW properly due to the disc condition. If there are MP-3-formatted file and audio data in the same disc, the CD player loads and plays the first session of the data only. |
| NOTE |
|---|
| The CD player may not play the CD-R/RW properly due to the disc condition. If there are MP-3-formatted file and audio data in the same disc, the CD player loads and plays the first session of the data only. |
TROUBLESHOOTING REFERENCE
NO. 11 TRACK CHANGE IS INOPERATIVE
| 11 | Track change is inoperative Possible DTC:03:Er02, 06:Er02, 10:Er02, 22:Er02 |
|---|
| Troubleshooting hints Audio unit is malfunctioning Defective CD (e.g., cracked, badly bent, rough edges, scratch, dirty CD, condensation) Non-conventional discs (e.g., 8 cm (3 in) CD, 8 cm (3 in) disc adapter, heart-shaped disc, octagonal disc) Center panel is malfunctioning MP3 applicable CD player is malfunctioning |
TROUBLESHOOTING REFERENCE
3. Stereo and Monaural Receptions
- As signals become weak, noise may appear more in stereo reception. Comparing to stereo reception, noise in monaural receptions is relatively less striking.
Measures in Audio System Separation control
- Utilizing the characteristic of monaural reception that noise is relatively less striking than stereo reception, the audio system automatically changes the reception from stereo to monaural and lessens annoying noise when signals become weak or a multipath phenomenon occurs.
High tone control
- When signals become weak or a multipath phenomenon occurs, the audio system restrains volume level in high frequency band and lessens annoying noise.
Scheme 57
Scheme 57: Effect Setting of Separation Control and High Tone Control
- The separation and high tone controls influence sound quality, Therefore they are specifically tuned for individual model. (Comparison of characteristic must be done on the same models)
Scheme 58
- Signals tend to reach longer distances in the night. It is conspicuous in AM signals, several audio functions may stop due to foreign broadcasting station or noise, though the audio system restrains sensitivity of SEEK and SCAN functions in the night, the audio system may select other than desired broadcasting station when signals are considerably strong. This function is liked to the parking light. When the parking light or headlight is turned on, SEEK and SCAN may not function for weak signals.
Scheme 59
Scheme 59: AUDIO CD [REFERENCE]
- The CD player/changer has been designed to play CDs bearing the identification logo, COMPACT DISC DIGITAL AUDIO, as shown. No other discs can be played on the CD player/changer other than MP3 applicable one.
- The CD player/changer may not play the following CD: Defective CD (e.g., cracked, badly bent, rough edges, scratch, dirty CD condensation) 8 cm (3 in) CDs accessories (e.g., 8 cm (3 in) disc adapter, sticker, label) Nonstandard CD (e.g., Diameter/thickness is out of specification) Specification: 119.7-120.3 mm (4.668-4.692 in) of diameter, 12+0.3 or -0.1 mm (0.047+0.012 or 0.004 in) of thickness
- Do not use non-conventional discs. The CD player/changer could be damaged.
Scheme 60
- Although the same physical size as the compact disc, SACD uses a different kind of digital audio signal, Direct Stream Digital.
- The CD player/changer may not play the CD-R/RW properly due to the disc condition (excluding the MP3).
MP3-Formatted File Outline of CD-R and CD-RW
- Definition CD-R: The CD-R is a non-rewritable version. Once a section of a CD-R is written, it cannot be erased or rewritten. CD-RW: The CD-RW is a re-writable version of CD-ROM and can be written the data an unlimited number of times. Since a reflected laser beam amount of the CD-R/RW is less than the reflected laser beam amount of the conventional CD media, the CD player/changer may not play the CD-R/RW or have the sound jumped. Since the recording quality of the CD-R/RW vary widely, some CD-R/RW may not be played.
- There are two methods for recording.
- Classification by recorder Record the audio data in the audio-CD by audio recorder The price of the audio recorder and original audio-CD includes the copyright fee. Recorded the audio data in the conventional data-CD by the personal computer The data-CD is cheaper than the audio-CD. But, there is a CD with the low quality.
- Classification by audio data uncompression/compression Uncompressed audio data The CD-R/RW player can play the uncompressed audio data. Compressed audio data It is possible to record the large quantity of music in a disc. The sound quality varies depends on the audio data compression format. The compressed audio data can be played on the applicable player only.
- Type of compression format: MP3: MPEG Audio Layer 3 - Mazda genie MP3 applicable CD player is available. WMA: Windows Media Audio ATRAG: Adaptive Transform Acoustic Coding
MP3
- The following condition should be met in order to record the MP3-formatted data on the MP3 applicable CD player
| Media | Applicable to the CD-R/RW |
|---|
| Logical format | ISO 9660 level 1&2 / Joliet / Romeo |
| Number of directly | 8 directly |
| Number of files | Maximum 255 as a total number of file and folder Maximum 155 for folder |
| ID3 TAG | Applicable to Ver 1.1, 2.3 and 2.4 |
| File extension | MP3 |
| Packet writing | Not applicable |
| Bit rate | 8kbps-320kbps/VBR |
| Sampling rate | 11.025kHz-48kHz |
