Entertainment System: Overview Mazda 5 I

Entertainment Systems 4 illustrations ~120 words

Scheme 1

Scheme 1: Audio System
Scheme 1: Audio System

Scheme 2

Scheme 2: Car Navigation System
Scheme 2: Car Navigation System

Scheme 3

Scheme 3: CENTER PANEL UNIT REMOVAL/INSTALLATION
Scheme 3: CENTER PANEL UNIT REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ).
  4. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal. CAUTION: When installing the center panel unit, make sure that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the wiring harness or the antenna feeder is caught between the unit and dashboard, it may cause malfunctions.

Scheme 4

Scheme 4: Center Panel Unit Removal Note
Scheme 4: Center Panel Unit Removal Note
  1. Pull the center panel unit outward, detach clip A from the dashboard, and then remove the center panel unit.
