Entertainment System: Overhaul Mazda 5 I

Entertainment Systems 36 illustrations ~1646 words

CENTER PANEL UNIT DISASSEMBLY/ASSEMBLY

CAUTIONBefore disassembling the center panel unit, spread a cloth on the floor to put the disassembled parts on. This protects the surface of the panel from scratches or dirt.

Scheme 9

Scheme 9
Scheme 9
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 10

Scheme 10: AUDIO UNIT DISASSEMBLY/ASSEMBLY
Scheme 10: AUDIO UNIT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 11

Scheme 11: CAR NAVIGATION UNIT REMOVAL/INSTALLATION
Scheme 11: CAR NAVIGATION UNIT REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244361-S16170239572006092100000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-244361-S15926577782006092100000) ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 12

Scheme 12: LCD UNIT REMOVAL/INSTALLATION
Scheme 12: LCD UNIT REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ).
  4. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  5. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ).
  6. Remove in the order indicated in the table.
  7. Install in the reverse order of removal.

Scheme 13

Scheme 13: LCD Unit Removal Note
Scheme 13: LCD Unit Removal Note

Scheme 14

Scheme 14
Scheme 14
  1. Pull the lower LCD unit outward, detach clip A.
  2. Detach B, and then remove the LCD unit.

Scheme 15

Scheme 15: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 15: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-244361-S19523701972006092100000) ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 16

Scheme 16: Front Door Speaker Installation Note
Scheme 16: Front Door Speaker Installation Note
  1. Remove the speaker with the wiring harness passing through the groove of the front door module. CAUTION: If the speaker is installed with the wiring harness out of the groove, an open circuit in the wiring harness could occur.

Scheme 17

Scheme 17: FRONT DOOR SPEAKER INSPECTION
Scheme 17: FRONT DOOR SPEAKER INSPECTION
  1. Verify the resistance between front door speaker terminals. If the resistance is not within the specification, replace the front door speaker. Resistance 4 ohms
  2. Connect a 1.5 V battery to the front door speaker and verify that noise is sound from the front door speaker. If no sound is output, replace the front door speaker.

Scheme 18

Scheme 18: REAR SPEAKER REMOVAL/INSTALLATION
Scheme 18: REAR SPEAKER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Lower anchor of the third-row seat belt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 19

Scheme 19: REAR SPEAKER INSPECTION
Scheme 19: REAR SPEAKER INSPECTION
  1. Verify the resistance between rear speaker terminals. If the resistance is not within the specification, replace the rear speaker. Resistance 4 ohms
  2. Connect a 1.5 V battery to the rear door speaker and verify that noise is sound from the rear speaker. If no sound is output, replace the rear speaker.

Scheme 20

Scheme 20: FRONT TWEETER REMOVAL/INSTALLATION
Scheme 20: FRONT TWEETER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the inner garnish from the front door. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-244361-S41335276262006092100000) ).
  4. Remove the front tweeter.
  5. Install in the reverse order of removal.

Scheme 21

Scheme 21: FRONT TWEETER INSPECTION
Scheme 21: FRONT TWEETER INSPECTION
  1. Verify the resistance between front tweeter terminals. If the resistance is not within the specification, replace the front tweeter. Resistance 3.2 ohms
  2. Connect a 1.5 V battery to the front tweeter and verify that noise is sound from the front tweeter. If no sound is output, replace the front tweeter.

Scheme 22

Scheme 22: CONDENSER REMOVAL/INSTALLATION
Scheme 22: CONDENSER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Lower anchor of the third-row seat belt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 23

Scheme 23: CENTER ROOF ANTENNA REMOVAL/INSTALLATION
Scheme 23: CENTER ROOF ANTENNA REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Lower anchor of the third-row seat belt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ). Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION»(ref-244361-S12459088702006092100000) ). Upper anchor of the second-row seat belt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S12386615082006092100000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244361-S32342025012006092100000) ).
  4. Partially peel back the headliner.
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal.
  7. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 24

Scheme 24: CENTER ROOF ANTENNA INSPECTION
Scheme 24: CENTER ROOF ANTENNA INSPECTION

Scheme 25

Scheme 25
Scheme 25
  1. Verify that there is no continuity between the center roof antenna terminals A and C using an ohmmeter.
  2. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as indicated in the table, replace the center roof antenna.

Scheme 26

Scheme 26: GPS ANTENNA REMOVAL/INSTALLATION
Scheme 26: GPS ANTENNA REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ).
  4. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  5. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ).
  6. Remove the LCD unit. (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ).
  7. Remove in the order indicated in the table.
  8. Install in the reverse order of removal.

Scheme 27

Scheme 27: ANTENNA FEEDER LOCATION
Scheme 27: ANTENNA FEEDER LOCATION

Scheme 28

Scheme 28: FRONT ANTENNA FEEDER INSPECTION
Scheme 28: FRONT ANTENNA FEEDER INSPECTION

Scheme 29

Scheme 29
Scheme 29
  1. Verify that there is no continuity between the front antenna feeder terminal A and B.
  2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the front antenna feeder.

Scheme 30

Scheme 30: REAR ANTENNA FEEDER INSPECTION
Scheme 30: REAR ANTENNA FEEDER INSPECTION
  1. Verify that there is no continuity between the rear antenna feeder terminal A and B.
  2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the rear antenna feeder No.1 or No.2.

Scheme 31

Scheme 31
Scheme 31
  1. Verify that there is no continuity between the GPS antenna feeder terminal A and B.
  2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the GPS antenna feeder.

Scheme 32

Scheme 32: AUDIO CONTROL SWITCH REMOVAL/INSTALLATION
Scheme 32: AUDIO CONTROL SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S16479481112006092100000) ).
  4. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-244338-S20307144292006092100000) ).
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal.

Scheme 33

Scheme 33: Audio Control Switch Installation Note
Scheme 33: Audio Control Switch Installation Note
  1. Install the audio control switch so that the audio control switch wiring harness passes behind the steering wheel as shown in the figure.

Scheme 34

Scheme 34: AUDIO CONTROL SWITCH INSPECTION
Scheme 34: AUDIO CONTROL SWITCH INSPECTION

Scheme 35

Scheme 35
Scheme 35
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S16479481112006092100000) ).
  4. Disconnect the audio control switch connector.
  5. Verify the resistance and continuity between the audio control switch terminals. If the resistance and continuity are not as indicated in the tables, replace the audio control light switch. R: Resistance. See «RESISTANCE SPECIFICATION CHART»(ref-244348-S26631286462006092100000) . RESISTANCE SPECIFICATION CHART Switch position Resistance (ohm) VOL- button ON 51-56 VOL+ button ON 140-154 PRESET+ button ON 286-316 PRESET- button ON 533-590 MODE button ON 984-1,089 MUTE button ON 1,934-2,139 OFF 4,794-5,300

Scheme 36

Scheme 36: CAR NAVIGATION CONTROL SWITCH REMOVAL/INSTALLATION
Scheme 36: CAR NAVIGATION CONTROL SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the shift lever knob. (MTX)
  4. Remove the selector lever knob. (ATX)
  5. Remove the boot panel. (MTX) (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  6. Remove the indicator panel. (ATX) (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  7. Remove the car navigation control switch.
  8. Install in the reverse order of removal.

Scheme 37

Scheme 37: Car Navigation Control Switch Removal Note
Scheme 37: Car Navigation Control Switch Removal Note
  1. Pry the car navigation control switch from the console using a flathead screwdriver wrapped with protective tape.

Scheme 38

Scheme 38: CAR NAVIGATION CONTROL SWITCH INSPECTION
Scheme 38: CAR NAVIGATION CONTROL SWITCH INSPECTION
  1. Operate the car navigation control switch and verify that the car navigation system operates normally. If the system does not operate normally, go to the next step.
  2. Inspect the wiring harness between the LCD unit and the car navigation control switch for an open circuit, power short, or a short to ground. If there is any malfunction in the wiring harnesses, repair or replace the applicable wiring harness. If the wiring harnesses are normal, replace the car navigation control switch.

Scheme 39

Scheme 39: MICROPHONE REMOVAL/INSTALLATION
Scheme 39: MICROPHONE REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ).
  4. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  5. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ).
  6. Remove the LCD unit. (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ).
  7. Remove the microphone.
  8. Install in the reverse order of removal.

Scheme 40

Scheme 40: CIGARETTE LIGHTER REMOVAL/INSTALLATION
Scheme 40: CIGARETTE LIGHTER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the shift lever knob. (MTX)
  4. Remove the selected lever knob. (ATX)
  5. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ).
  6. Remove in the order indicated in the table.
  7. Install in the reverse order of removal.

Scheme 41

Scheme 41: Socket Removal Note
Scheme 41: Socket Removal Note

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Insert a tape-wrapped flathead screwdriver into the socket hole and push on the ring projection to lift the socket outward.
  2. Lift out the socket until the ring projection locks into the lower socket hole as shown in the figure.
  3. From the rear of the front console, insert a tape-wrapped flathead screwdriver between the socket and the ring as shown in the figure.
  4. While lifting the ring projection with the flathead screwdriver, push out and remove the socket.

Scheme 44

Scheme 44: Ring Removal Note
Scheme 44: Ring Removal Note
  1. Pull the ring outward while pressing the tabs.
