Rear Axle: Overview Mazda 5 I

Scheme 19

Scheme 20

Scheme 21

1. Remove the brake caliper component and disc plate.
2. Remove the wheel hub bolt using the SST as shown in the figure.
3. Place a new wheel hub bolt in the wheel hub.
4. Install the wheel hub by placing a proper sized washer on the hub, and tightening the nut as shown in the figure.

Scheme 22

1. install the magnetic base and dial gauge as shown in the figure and measure the wheel bearing axial excessive play. If it exceeds the maximum specification, replace the wheel hub component. Rear wheel bearing maximum play 0.05 mm {0.002 in}
