Welcome Mode ON/OFF Setting

Note. WELCOME mode is controlled by the instrument cluster. Refer to the instrument cluster description.

Refer to «INSTRUMENTATION/DRIVER INFO. PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-579350-S04610743732013100700000) .

Scheme 53

Scheme 53: Welcome Sound ON/OFF Setting

Scheme 54

Switch the ignition to ACC or ON.
Turn the audio unit power to ON.
Press the AUDIO CONT switch. (Scheme 53): Pressing AUDIO CONT Switch
Select "Welcome ON" or "Welcome OFF".
Press the AUDIO CONT switch.
Select "ON" or "OFF". (Scheme 54): Selecting "Welcome ON" And "Welcome OFF"

Scheme 55

Scheme 55: Action Illumination ON/OFF Setting

Scheme 56

Switch the ignition to ACC or ON.
Turn the audio unit power to ON.
Press the AUDIO CONT switch. (Scheme 55): Pressing AUDIO CONT Switch
Select "ILLM EFT ON" or "ILLM EFT OFF".
Press the AUDIO CONT switch.
Select "ON" or "OFF". (Scheme 56): Selecting "ILLM EFT ON" And "ILLM EFT OFF"

Switching Between SIRIUS Satellite Radio Unit Equipped/Not Equipped

Note. Do not operate the command for the Sirius radio because it is used for the factory inspection.

Scheme 57

Scheme 57: Switching Between SIRIUS Satellite Radio Unit Equipped/Not Equipped

Connect the M-MDS (IDS) to the DLC-2. (Scheme 57): Identifying DLC-2
After the vehicle is identified, select the following items from the initial screen of the M-MDS. Select the "Module Programming".
Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "Audio Configure". M-MDS display Function Setting Sirius radio Perform a write on the instrument cluster for whether or not a SIRIUS satellite radio unit is equipped. NOTE: Do not operate the command because it is for factory inspection.

Scheme 58

Scheme 58: USB ADAPTER REMOVAL/INSTALLATION

Scheme 59

Scheme 60

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000) .)
Disconnect the connector.
Remove the bolts.
Remove the USB adapter.
Remove the screw.
Remove the USB adapter from the bracket.
Install in the reverse order of removal.

Scheme 61

Scheme 61: USB ADAPTER INSPECTION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000) .)
Verify that the voltages of each of the terminal voltage table (reference), inspect the parts under inspection item(s) and related wiring harnesses. If the system does not work normally even though the inspection items or related wiring harnesses do not have any malfunction, replace the USB adapter.

With Audio Unit (Without Display)

Note. Car-navigation unit is integrated with the multi information display.

Refer to «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S13703502732013100700000) .

Scheme 62

Scheme 62: With Audio Unit (With Display)

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper Panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .)
Remove clips A and B.
Remove the clip C.
Remove the pad.
While pressing the clip tabs in the direction of the arrow (1) shown in the figure, press the clip in the direction of arrow (2) to detach the tab of clip D from the console.
Remove the clip D.
Move the car-navigation unit assembly in the direction of arrows (1) and (2) shown in the figure and remove the hook.
Remove the car-navigation unit assembly.
Remove the wiring harness from the bracket hook.
Disconnect the connector.
Pull the wiring harness from the console.
Remove the screws.
Remove the car-navigation unit from the bracket.
Install in the reverse order of removal.

Scheme 68

Scheme 68: AUDIO AMPLIFIER REMOVAL/INSTALLATION

Scheme 69

Slide the passenger seat rearward.
Remove the cover. (Scheme 68): Audio Amplifier, Cover, Clips And Bolt With Torque Specification
Remove the bolt.
Detach the clips and set the vehicle wiring harness aside.
Slide the passenger seat forward.
Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the caps. (Scheme 69): Audio Amplifier Connector, Caps And Nuts With Torque Specification
Remove the nuts.
Disconnect the connector.
Remove the audio amplifier.
Install in the reverse order of removal.

Scheme 70

Scheme 70: FRONT DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 71

Scheme 72

Scheme 73

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
Disconnect the connector. (Scheme 70): Front Door Speaker, Connector And Screws (Without Bose) (Scheme 71): Front Door Speaker, Connector And Screws (With Bose)
Remove the screw.
Remove the front door speaker in the direction of the arrow shown in the figure. (Scheme 72): Front Door Speaker (Without Bose) (Scheme 73): Front Door Speaker (With Bose)
Install in the reverse order of removal.

Scheme 74

Scheme 74: FRONT DOOR SPEAKER INSPECTION

Scheme 75

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
Remove the front door speaker. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S02963356692013100700000).)
Verify the resistance between the front door speaker terminals. (Scheme 74): Front Door Speaker Connector Terminals If not within the specification, replace the front door speaker. (Scheme 75): Front Door Speaker Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 1.83-2.47 ohms

Scheme 76

Scheme 76: REAR DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 77

Scheme 78

Scheme 79

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S26826772842013100700000).)
Disconnect the connector. (Scheme 76): Rear Door Speaker, Connector And Screws (Without Bose) (Scheme 77): Rear Door Speaker, Connector And Screws (With Bose)
Remove the screw.
Remove the rear door speaker in the direction of the arrow shown in the figure. Without Bose® (Scheme 78): Rear Door Speaker (Without Bose®) (Scheme 79): Removing Rear Door Speaker (With Bose®)
Install in the reverse order of removal.

Scheme 80

Scheme 80: REAR DOOR SPEAKER INSPECTION

Scheme 81

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S26826772842013100700000).)
Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S00441907682013100700000).)
Verify the resistance between the rear door speaker terminals. (Scheme 80): Rear Door Speaker Connector Terminals If not within the specification, replace the rear door speaker. (Scheme 81): Rear Door Speaker Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 2.89-3.91 ohms

Scheme 82

Scheme 82: FRONT CENTER SPEAKER REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000) .) Center Panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000) .) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000) .) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000) .)
Remove the screw.
Remove the front center speaker.
Install in the reverse order of removal.

Scheme 83

Scheme 83: FRONT CENTER SPEAKER INSPECTION

Scheme 84

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000).) Front center speaker (See «FRONT CENTER SPEAKER REMOVAL/INSTALLATION»(ref-579336-S04149093402013102400000).)
Verify the resistance between the front center speaker terminals. (Scheme 83): Front Center Speaker Connector Terminals If not within the specification, replace the front center speaker. (Scheme 84): Front Center Speaker Terminals Resistance Chart Resistance 3.24-3.96 ohms

Scheme 85

Scheme 85: REAR CENTER SPEAKER REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).)
Remove the screw. (Scheme 85): Rear Center Speaker, Connector And Screws
Disconnect the connector.
Remove the rear center speaker.
Install in the reverse order of removal.

Scheme 86

Scheme 86: REAR CENTER SPEAKER INSPECTION

Scheme 87

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).) Rear center speaker (See «REAR CENTER SPEAKER REMOVAL/INSTALLATION»(ref-579336-S10749932582013100700000).)
Verify the resistance between the rear center speaker terminals. (Scheme 86): Rear Center Speaker Connector Terminals If not within the specification, replace the rear center speaker. (Scheme 87): Rear Center Speaker Terminals Resistance Chart Resistance 0.9-1.1 ohms

Scheme 88

Scheme 88: 4SD

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).)
Remove the screw. (Scheme 88): Rear Speaker, Connector And Screws
Disconnect the connector.
Remove the rear speaker.
Install in the reverse order of removal.

Scheme 89

Scheme 89: 5HB

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).)
Remove the screw. (Scheme 89): Rear Speaker, C-Pillar Trim, Connector And Screw
Disconnect the connector.
Remove the rear speaker.
Install in the reverse order of removal.

Scheme 90

Scheme 90: 4SD

Scheme 91

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S05704132862013100700000).)
Verify the resistance between the rear speaker terminals. (Scheme 90): Rear Speaker Connector Terminals (4SD) If not within the specification, replace the rear speaker. (Scheme 91): Rear Speaker Terminals Resistance Chart (4SD) 3.24-3.96 ohms

Scheme 92

Scheme 92: 5HB

Scheme 93

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S05704132862013100700000).)
Verify the resistance between the rear speaker terminals. (Scheme 92): Rear Speaker Connector Terminals (5HB) If not within the specification, replace the rear speaker. (Scheme 93): Rear Speaker Terminals Resistance Chart (5HB) Resistance 3.24-3.96 ohms

Scheme 94

Scheme 94: TWEETER REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
Remove the tweeter in the direction of the arrow shown in the figure. (Scheme 94): Removing Tweeter
Install in the reverse order of removal.

Scheme 95

Scheme 95: TWEETER INSPECTION

Scheme 96

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
Remove the tweeter. (See «TWEETER REMOVAL/INSTALLATION»(ref-579336-S40916393662013100700000).)
Verify the resistance between tweeter terminals. (Scheme 95): Tweeter Connector Terminals If not within the specification, replace the tweeter. (Scheme 96): Tweeter Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 3.06-3.74 ohms

Scheme 97

Scheme 97: BASS-BOX REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Disconnect the connector. (Scheme 97): Bass-Box, Short-Cord, Connector And Bolt With Torque Specification
Remove the short-cord.
Remove the bolt.
Remove the bass-box.
Install in the reverse order of removal.

Scheme 98

Scheme 98: BASS-BOX INSPECTION

Scheme 99

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Disconnect the connector. (See «BASS-BOX REMOVAL/INSTALLATION»(ref-579336-S00706515092013100700000).)
Verify the resistance between bass-box terminals. (Scheme 98): Identifying Bass-Box Connector Terminals If not within the specification, replace the bass-box. (Scheme 99): Bass-Box Terminals Resistance Chart Resistance 0.9-1.1 ohms

5HB

Note. The center roof antenna has a built-in antenna amplifier.

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3. (5HB) (Scheme 100): Locating Antenna Feeder (Without Display)

With Audio Unit (With Display)

Scheme 100

Scheme 100: ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION

Scheme 101

Scheme 102

Scheme 103

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S33106125982013100700000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-579407-S37725560872013100700000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).)
Partially peel back the hook. (Scheme 102): Peeling Back Hook
Partially peel back the SIRIUS satellite radio antenna feeder. (Scheme 103): Peeling Back SIRIUS Satellite Radio Antenna Feeder
Remove the clip A.
Peel off the tape. (Scheme 104): Removing Clip A
Partially peel back the hook.
Remove the clips B. (Scheme 105): Removing Clips B
Remove the antenna feeder No.1.
Install in the reverse order of removal.

Scheme 104

Scheme 104: ANTENNA FEEDER NO.1 INSPECTION

Scheme 105

Scheme 106

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).)
Disconnect antenna feeder No.2. (Scheme 106): Locating Antenna Feeder No.2
Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table. (Scheme 107): Identifying Antenna Feeder No.1 Connector Terminals If not as indicated in the table, replace antenna feeder No.1. (Scheme 108): Antenna Feeder No.1 Terminals Continuity Chart

Scheme 107

Scheme 107: ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION

Scheme 108

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
Remove the antenna feeder No.2.
Install in the reverse order of removal. Without sunroof (Scheme 109): Antenna Feeder No.2 (Without Sunroof) (Scheme 110): Antenna Feeder No.2 (With Sunroof)

Scheme 109

Scheme 109: ANTENNA FEEDER NO.2 INSPECTION

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Rear seat cushion (4SD) (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB, RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk side trim (5HB, RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).) C-pillar trim (RH) (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).)
Disconnect the antenna feeder No.1. (Scheme 111): Antenna Feeder No.1
Disconnect the antenna amplifier (4SD)/ antenna feeder No.3 (5HB). (Scheme 112): Antenna Amplifier (4SD) (Scheme 113): Antenna Feeder No.3 (5HB)
Verify that the continuity between antenna feeder No.2 terminals is as indicated in the table. (Scheme 116): Antenna Feeder No.2 Connector Terminals 5HB (With Audio Unit (With Display)) If not as indicated in the table, replace antenna feeder No.2. (Scheme 117): Antenna Feeder No.2 Terminals Continuity Chart

Scheme 116

Scheme 116: 4SD (With Audio Unit (With Display))

Scheme 117

Scheme 118

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .)
Disconnect the antenna feeder No.5.
Remove the clips A and B.
Disconnect the antenna amplifier connector.
Remove the clips C, D and E.
Disconnect the center roof antenna connector. (with SIRIUS satellite radio system)
Disconnect the glass antenna connector. (See «Glass Antenna Connector Removal Note»(ref-579336-S21854200972013102500000) .)
Remove the bolt.
Remove the clips F and G.
Install in the reverse order of removal.

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .)
Disconnect the connector.
Remove the clips A and B.
Remove the antenna feeder No.3.
Install in the reverse order of removal.

Scheme 119

Scheme 119: With Audio Unit (With Display)

Scheme 120

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .) Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000) .)
Disconnect the antenna feeder No.7 (See «ANTENNA FEEDER NO.7 REMOVAL/ INSTALLATION»(ref-579336-S01558402842013102900000) .)
Disconnect the antenna feeder No.5.
Remove the clips A, B, C, D and E.
Remove the bolt.
Disconnect the connector.
Remove the clips G, H and I.
Remove the antenna feeder No. 3.
Install in the reverse order of removal.

Scheme 121

Scheme 121: 4SD (With Audio System (With Display))

Scheme 122

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .)
Disconnect the antenna feeder No.5 and connector. (See «ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION»(ref-579336-S20570515942013100700000) .)
Verify that the continuity between antenna feeder No.3 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder No.3.

Scheme 123

Scheme 123: With Audio Unit (Without Display)

Scheme 124

Scheme 125

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
Disconnect the connector. (Scheme 125): Antenna Feeder No.3 And Connector
Verify that the continuity between antenna feeder No.3 terminals is as indicated in the table. (Scheme 126): Identifying Antenna Feeder No.3 Connector Terminals If not as indicated in the table, replace antenna feeder No.3. (Scheme 127): Antenna Feeder No.3 Terminal Continuity Chart

Scheme 126

Scheme 126: With Audio Unit (With Display)

Scheme 127

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
Partially peel back the seaming welts.
Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .) Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000) .)
Disconnect the antenna feeder No.5 and connector. (See «ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION»(ref-579336-S20570515942013100700000) .)
Disconnect the antenna feeder No.7. (See .)
Verify that the continuity between antenna feeder No.3 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder No.3.

SIRIUS Satellite Radio Antenna Feeder No.1

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness.

Refer to «DASHBOARD DISASSEMBLY/ASSEMBLY»(ref-579335-S05494572442013100700000) .

SIRIUS Satellite Radio Antenna Feeder No.2

Note. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2.

Refer to «ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION»(ref-579336-S08235075992013100700000) .

SIRIUS Satellite Radio Antenna Feeder No.3 (5HB)

Note. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3.

Refer to «ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION»(ref-579336-S20570515942013100700000) .

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness.

Scheme 128

Scheme 128: SIRIUS Satellite Radio Antenna Feeder No.1

Scheme 129

Scheme 130

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).)
Disconnect the SIRIUS satellite radio antenna feeder connector. (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-579336-S30319798732013100700000).)
Disconnect the antenna feeder No.2. (Scheme 132): Antenna Feeder No.2
Verify that the continuity between SIRIUS satellite radio antenna feeder No.1 terminals is as indicated in the table. (Scheme 133): Identifying SIRIUS Satellite Radio Antenna Feeder No.1 Connector Terminals If not as indicated in the table, replace dashboard wiring harness. (Scheme 134): SIRIUS Satellite Radio Antenna Feeder No.1 Terminals Continuity Chart

Note. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2.

Refer to «ANTENNA FEEDER NO.2 INSPECTION»(ref-579336-S26074739412013100700000) .

Note. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3.

Refer to «ANTENNA FEEDER NO.3 INSPECTION»(ref-579336-S10066113812013100700000) .

Scheme 131

Scheme 131: With Audio Unit (Without Display)

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).)
Remove in the order indicated in the table. see scheme 136: GPS Antenna, Connector, Clip And Screw (Without Display)
Install in the reverse order of removal.

Scheme 132

Scheme 132: With Audio Unit (With Display)

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000) .)
Remove in the order indicated in the table.
Install in the reverse order of removal.

Note. GPS antenna feeder is removed with the multi information display.

Refer to «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S13703502732013100700000) .

Note. GPS antenna feeder is removed with the antenna feeder No.4.

Refer to «ANTENNA FEEDER NO.4 REMOVAL/INSTALLATION»(ref-579336-S04848118022013102500000) .

Scheme 133

Scheme 133: With Audio Unit (Without Display)

Scheme 134

Verify that the continuity is as indicated in the table. see scheme 138: Identifying GPS Antenna Feeder Connector Terminals If not as indicated in the table, replace the GPS antenna feeder. see scheme 139: GPS Antenna Feeder Terminals Continuity Chart

Note. GPS antenna feeder is integrated with the antenna feeder No.4.

Refer to «ANTENNA FEEDER NO.4 INSPECTION»(ref-579336-S27493559852013102900000) .

Without Bluetooth System

WARNING

Handling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).)
Disconnect the steering switch connector.
Verify the resistance between the steering switch terminals. (Scheme 139): Identifying Steering Switch Connector Terminals If not within the specification, replace the steering switch. (Scheme 140): Steering Switch Terminals Resistance Chart (1 Of 3) (Scheme 141): Steering Switch Terminals Resistance Chart (2 Of 3) (Scheme 142): Steering Switch Terminals Resistance Chart (3 Of 3)
Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground. (Scheme 143): Applying Battery Positive Voltage To Steering Switch Terminal O
Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

With Bluetooth System

WARNING

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).)
Disconnect the steering switch connector.
Verify the resistance between the steering switch terminals. (Scheme 144): Identifying Steering Switch Connector Terminals If not within the specification, replace the steering switch. (Scheme 145): Steering Switch Terminals Resistance Chart (1 Of 4) (Scheme 146): Steering Switch Terminals Resistance Chart (2 Of 4) (Scheme 147): Steering Switch Terminals Resistance Chart (3 Of 4) (Scheme 148): Steering Switch Terminals Resistance Chart (4 Of 4)
Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground. (Scheme 149): Applying Battery Positive Voltage To Steering Switch Terminal O
Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

Scheme 146

Scheme 146: MICROPHONE REMOVAL/INSTALLATION

Scheme 147

Scheme 148

Scheme 149

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).)
Disconnect the connector. (Scheme 150): Microphone Connector (Without Sunroof) (Scheme 151): Microphone Connector (With Sunroof)
Remove the microphone in the direction of the arrow (2) shown in the figure while pressing the microphone tabs in the direction of the arrow (1). (Scheme 152): Pressing Microphone Tabs (Without Sunroof) (Scheme 153): Pressing Microphone Tabs (With Sunroof)
Install in the reverse order of removal.

Scheme 150

Scheme 150: With Audio Unit (Without Display)

Scheme 151

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) AFS control module (With AFS (adaptive front lighting system)) (See «AFS (ADAPTIVE FRONT LIGHTING SYSTEM) CONTROL MODULE REMOVAL/INSTALLATION»(ref-579340-S12823280052013100700000).)
Remove the nuts. (Without AFS (adaptive front lighting system)) (Scheme 154): Bluetooth UNIT Nuts With Torque Specification
Disconnect the connector.
Detach the clip and set the wiring harness aside. (Scheme 155): Detaching Clip Of Bluetooth UNIT
Remove the Bluetooth unit.
Install in the reverse order of removal.

Scheme 152

Scheme 152: With Audio Unit (With Display)

Scheme 153

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000) .) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000) .) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000) .)
Disconnect the connector.
Remove clips A and B.
Remove the bolts.
Remove the Bluetooth unit.
Remove the screws.
Remove the washers.
Remove the Bluetooth unit from the bracket.
Install in reverse order of removal.

Scheme 154

Scheme 154: Front

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
Remove the shift lever knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).)
Remove the selector lever knob. (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).)
Remove the shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).)
Remove in the order indicated in the table. (Scheme 159): Front Accessory Socket And Cap
Install in the reverse order of removal.

Scheme 155

Scheme 155: Rear

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).)
Remove in the order indicated in the table. (Scheme 160): Rear Accessory Socket And Cap
Install in the reverse order of removal.

Scheme 156

Scheme 156: Socket Removal Note

Remove the socket in the direction of the arrow (2) shown in the figure while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover. (Scheme 161): Removing Socket

Scheme 157

Scheme 157: Cap Removal Note

Remove the cap in the direction of the arrow (2) shown in the figure while pressing the cap tabs in the direction of the arrow (1). (Scheme 162): Pressing Cap Tabs

Scheme 158

Scheme 158: Front

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
Remove the shift lever knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).)
Remove the selector lever knob. (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).)
Remove the shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).)
Remove the accessory socket (front) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-579336-S14825488452013100700000).)
Connect a tester as shown in the figure and verify that there is continuity. (Scheme 163): Inspecting Front Accessory Socket If the continuity cannot be verified, replace the accessory socket (front).

Scheme 159

Scheme 159: Rear

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Accessory socket (rear) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-579336-S14825488452013100700000).)
Connect a tester as shown in the figure and verify that there is continuity. (Scheme 164): Inspecting Rear Accessory Socket If the continuity cannot be verified, replace the accessory socket (rear).

Scheme 160

Scheme 160: AUXILIARY JACK REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).)
Remove the auxiliary jack in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack tabs in the direction of the arrow (1). (Scheme 165): Pressing Auxiliary Jack Tabs
Install in the reverse order of removal.

Scheme 161

Scheme 161: AUXILIARY JACK INSPECTION

Scheme 162

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Auxiliary jack (See «AUXILIARY JACK REMOVAL/INSTALLATION»(ref-579336-S33571702612013100700000).)
Connect a commercially-available nonresistant plug to the auxiliary jack. (Scheme 166): Connecting Commercially-Available Nonresistant Plug To Auxiliary Jack
Verify that the continuity between the auxiliary jack terminals is as indicated in the table. (Scheme 167): Auxiliary Jack Terminals Continuity Chart If not as indicated in the table, replace the auxiliary jack.

Scheme 163

Scheme 163: AUXILIARY JACK/USB PORT REMOVAL/INSTALLATION

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .)
Remove the auxiliary jack/USB port in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack/USB port tabs in the direction of the arrow (1).
Install in the reverse order of removal.

Scheme 164

Scheme 164: Auxiliary Jack Inspection

Scheme 165

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .) Auxiliary jack/USB port (See «AUXILIARY JACK/USB PORT REMOVAL/INSTALLATION»(ref-579336-S20815023122013102400000) .)
Connect a commercially-available nonresistant plug to the auxiliary jack.
Verify that the continuity between the auxiliary jack/USB port terminals is as indicated in the table. If not as indicated in the table, replace the auxiliary jack/USB port.

Scheme 166

Scheme 166: USB Port Inspection

Scheme 167

Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .) Auxiliary jack/USB port (See «AUXILIARY JACK/USB PORT REMOVAL/INSTALLATION»(ref-579336-S20815023122013102400000) .)
Insert the pins to positions UA', UB', UC', and UD' shown in the figure from the side of the USB device insertion area for the auxiliary jack/USB port, and verify the continuity at the insertion sida and terminal side of the USB device.
Verify that the continuity at the insertion side and terminal side of the USB device is as indicated in the table. NOTE: When inspecting the USB device insertion side, touch it with a paper clip or similar thin pin without directly inserting a tester into the terminals. If not as indicated in the table, replace the auxiliary jack/USB port.

Entertainment System: Other Mazda 3 BM
