Entertainment System: Removal & Installation Mazda 3 BM

Entertainment Systems 28 illustrations ~1878 words

AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION

Note. AudioPilot ® 2 is a registered trademark of Bose ® Corporation.

Scheme 24

Scheme 24: AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION
Scheme 24: AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Disconnect the connector.
  3. Remove the nut. (Scheme 24): AudioPilot® 2 Microphone, Connector And Nut With Torque Specifications
  4. Remove the AudioPilot ® 2 microphone.
  5. Install in the reverse order of removal.

Scheme 25

Scheme 25: 4SD
Scheme 25: 4SD

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  6. Disconnect the connector. (Scheme 25): Ground Plate And Connector With Torque Specifications
  7. Remove the ground plate.
  8. Remove the center roof antenna in the direction of the arrow (2) shown in the figure while pressing the center roof antenna tabs in the direction of the arrow (1). (Scheme 26): Pressing Center Roof Antenna Tabs
  9. Install in the reverse order of removal.
  10. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 27

Scheme 27: 5HB
Scheme 27: 5HB

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  6. Disconnect the connector. (Scheme 27): Connector And Ground Plate (AM/FM Type) With Torque Specifications (Scheme 28): Connector And Ground Plate (AM/FM/SIRIUS Type) With Torque Specifications
  7. Remove the ground plate.
  8. Remove the antenna rod.
  9. Remove the center roof antenna in the direction of the arrow (2) shown in the figure while pressing the center roof antenna tabs in the direction of the arrow (1). (Scheme 29): Center Roof Antenna (AM/FM Type) (Scheme 30): Center Roof Antenna (AM/FM/SIRIUS Type)
  10. Install in the reverse order of removal.
  11. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 31

Scheme 31: 4SD
Scheme 31: 4SD

Scheme 32

Scheme 32
Scheme 32
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).) Center roof antenna (See «CENTER ROOF ANTENNA REMOVAL/INSTALLATION»(ref-579336-S34096331832013100700000).)
  6. Verify that there is no continuity between the center roof antenna terminals A and B using an ohmmeter. (Scheme 31): Identifying Center Roof Antenna Connector Terminals A And B
  7. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as indicated in the table, replace the center roof antenna. (Scheme 32): Center Roof Antenna Terminals Continuity Chart

Glass Antenna Connector Removal Note

  1. Remove the connector B in the direction of the arrow (2) shown in the figure while pressing the glass antenna terminal in the direction of the arrow (1).

Scheme 33

Scheme 33
Scheme 33

Removal

Note. The antenna feeder No.4 is integrated with the dashboard wiring harness.

  1. Refer to «DASHBOARD DISASSEMBLY/ASSEMBLY»(ref-579335-S05494572442013100700000)

Installation

CAUTIONIf the antenna feeder No.4 is installed with tension on the cable and wiring harness it could result in loosening of the connection areas and poor contact. When installing and connecting the antenna feeder No.4, always make sure there is slack on the cable and wiring harness.

Note. The antenna feeder No.4 is integrated with the dashboard wiring harness. When installing a new antenna feeder No.4, secure it to the vehicle wiring harness along the installation route of the old antenna feeder No.4.

Scheme 34

Scheme 34: ANTENNA FEEDER NO.4 INSPECTION
Scheme 34: ANTENNA FEEDER NO.4 INSPECTION

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000) .) Audio unit (Vehicles with audio unit) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000) .) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000) .) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000) .) Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000) .)
  3. Disconnect the GPS antenna connector.
  4. Disconnect the antenna feeder No.5.
  5. Verify that the continuity between antenna feeder No.4 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder No.4.

Scheme 37

Scheme 37: ANTENNA FEEDER NO.5 REMOVAL/INSTALLATION
Scheme 37: ANTENNA FEEDER NO.5 REMOVAL/INSTALLATION

Scheme 38

Scheme 38
Scheme 38
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000) .) Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (RH) (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .)
  3. Partially peel back the floor covering.
  4. Disconnect the antenna feeder No.4.
  5. Remove the clips A and B.
  6. Disconnect the antenna feeder No.3.
  7. Remove the clips C, D and E.
  8. Remove the antenna feeder No.5
  9. Install in reverse order of removal.

Scheme 39

Scheme 39: ANTENNA FEEDER NO.5 INSPECTION
Scheme 39: ANTENNA FEEDER NO.5 INSPECTION

Scheme 40

Scheme 40
Scheme 40
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .)
  3. Disconnect the antenna feeder No.4.
  4. Disconnect the antenna feeder No.3.
  5. Verify that the continuity between antenna feeder No.5 terminal is as indicated in the table. If not as indicated in the table, replace antenna feeder No.5.

ANTENNA FEEDER NO.6 REMOVAL/INSTALLATION

Note. Antenna feeder No.6 is integrated with the vehicle wiring harness.

  1. Refer to «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-579336-S28117398322013100700000)

Scheme 41

Scheme 41: ANTENNA FEEDER NO.6 INSPECTION
Scheme 41: ANTENNA FEEDER NO.6 INSPECTION

Scheme 42

Scheme 42
Scheme 42
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .) Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-579336-S28117398322013100700000) .)
  3. Verify that the continuity between antenna feeder No.6 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder No.6.

Scheme 43

Scheme 43: ANTENNA FEEDER NO.7 REMOVAL/ INSTALLATION
Scheme 43: ANTENNA FEEDER NO.7 REMOVAL/ INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000) .)
  3. Disconnect the connector A.
  4. Disconnect the connector B. (See «Connector B Removal Note»(ref-579336-S27169628682013102900000) .)
  5. Remove the bolt.
  6. Remove the antenna feeder No.7.
  7. Install in the reverse order of removal.

Scheme 44

Scheme 44: Connector B Removal Note
Scheme 44: Connector B Removal Note
  1. Remove the connector B in the direction of the arrow (2) shown in the figure while pressing the glass antenna terminal in the direction of the arrow (1).

Scheme 45

Scheme 45: ANTENNA FEEDER NO.7 INSPECTION
Scheme 45: ANTENNA FEEDER NO.7 INSPECTION

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000) .)
  3. Disconnect the connector A and B. (See «ANTENNA FEEDER NO.7 REMOVAL/ INSTALLATION»(ref-579336-S01558402842013102900000) .)
  4. Verify that the continuity between antenna feeder No.7 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder No.7.

STEERING SWITCH REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).)
  3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).)
  4. Remove the screw. (Scheme 51): Steering Wheel And Screws
  5. Remove the wiring harness from the cover hook. see scheme 141: Wiring Harness And Cover Hook
  6. Remove the cover tabs and pins from the steering wheel. see scheme 142: Cover Tab, Pins And Steering Wheel
  7. Remove the cover.
  8. Disconnect the connector. see scheme 143: Steering Wheel Connector And Screws
  9. Remove the screw.
  10. Remove the steering switch pins from the steering wheel. see scheme 144: Steering Switch Pins
  11. Remove the steering switch.
  12. Install in the reverse order of removal.
