Engine Control System [Mzr 2.3 Disi Turbo]: Overview Mazda 3 BL рестайлинг

Identifying Engine Control System Components Location [MZR 2.3 DISI Turbo] (1 Of 2). Scheme 90

Identifying Engine Control System Components Location [MZR 2.3 DISI Turbo] (2 Of 2). Scheme 91

Engine Control System Diagram [MZR 2.3 DISI Turbo]. Scheme 92

Engine Control System Wiring Diagram [MZR 2.3 DISI Turbo] (1 Of 2). Scheme 93

Engine Control System Wiring Diagram [MZR 2.3 DISI Turbo] (2 Of 2). Scheme 94

Scheme 95

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».)
3. Remove the following items: (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) Battery PCM cover No.1
4. Disconnect the PCM connector. (See «PCM CONNECTOR CONNECTION NOTE».)
5. Remove the battery tray and PCM component. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».)
6. Remove in the order indicated in the table. (Scheme 95): Locating PCM With Torque Specifications
7. Install in the reverse order of removal.
8. When replacing the PCM on the vehicles, perform the following: PCM configuration (See «PCM CONFIGURATION [MZR 2.3 DISI TURBO]».) Immobilizer system-related parts programming (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [KEYLESS ENTRY SYSTEM]».) (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».)
