Engine Control System [Skyactiv-G 2.0]: Overview Mazda 3 BL рестайлинг

Identifying Engine Control System Components Location [SKYACTIV-G 2.0] (1 Of 2). Scheme 172

Identifying Engine Control System Components Location [SKYACTIV-G 2.0] (2 Of 2). Scheme 173

Engine Control System Diagram. Scheme 174

Engine Control System Wiring Diagram (1 Of 3). Scheme 175

Engine Control System Wiring Diagram (2 Of 3). Scheme 176

Engine Control System Wiring Diagram (3 Of 3). Scheme 177

Scheme 178

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Disconnect the PCM connector. (See «PCM CONNECTOR CONNECTION NOTE».)
4. Remove the battery. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
5. Remove the battery tray and PCM component. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
6. Remove in the order indicated in the table. (Scheme 178): Locating PCM With Torque Specifications
7. Install in the reverse order of removal.
8. When replacing the PCM on the vehicles, perform the following: PCM configuration (See «PCM CONFIGURATION [SKYACTIV-G 2.0]».) Immobilizer system-related parts programming (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [KEYLESS ENTRY SYSTEM]».)

See also:
• DTC TABLE [SKYACTIV-G 2.0]
