FOREWORD [CD PLAYER]

1. If there is any vehicle malfunction complaint lodged by a customer, perform malfunction diagnosis according to the troubleshooting procedure.

Troubleshooting Procedure Chart - Foreword (CD Player). Scheme 163

Scheme 164

Scheme 165

1. If the malfunction does not recur, verify the malfunction cause by performing the following actions: Based on the repair order form, attempt to drive the vehicle or perform tests to replicate the malfunction, record the data at that time, and detect the malfunction cause. Shake the wiring harness or connector of the electrical component which is suspected to be the cause of the malfunction, and inspect for malfunction or occurrence of any DTCs. (Scheme 164): Inspecting Wiring Harness And Connector Of Electrical Component Inspect the female terminals on the connector of the electric component which is suspected to be the cause of the malfunction for poor connection. (Scheme 165): Inspecting Female Terminals On Connector Of Electric Component

NO.1 CD PLAYER DOES NOT LOAD THE CD OR EJECTS THE CD IMMEDIATELY [CD PLAYER]

NO.2 CD PLAYER DOES NOT EJECT THE CD [CD PLAYER]

NO.3 CD PLAYER DOES NOT PLAY THE CD/NO SOUND [CD PLAYER]

NO.4 SOUND JUMPS [CD PLAYER]

NO.5 CD PLAYER SCRATCHES ON THE CD [CD PLAYER]

NO.6 CD PLAYER DOES NOT PLAY THE MP3/WMA-FORMATTED FILE [CD PLAYER]

NO.7 MP3/WMA-FORMATTED FILE FOLDER SELECTION IS INOPERATIVE/TRACK SEARCH IS INOPERATIVE [CD PLAYER]

Note. ID3 is a tagging format for MP3-formatted file. ID3 allows metadata (e.g., title, artist, track number, etc.) to be added to the MP3-formatted file. There are two versions in the ID tag. ID3v1: This is the most widespread standard tag formats and most software is compatible with this version. There is a limitation on the maximum number of characters for the text data. ID3v2: There are a variety of version in V2, but there is no interchangeability among the versions.

Limitation on the maximum number of characters for the text data (ID3v1)

1. In a WMA file, the track name, artist name and album name are recorded with data called "WMA-Tag", and the information can be displayed.
2. WMA files which do not comply with the specific standard may not be played correctly or its file and folder name may not be displayed correctly.
3. The file extension may not be provided depending on the computer operating system, version, software, or setting. In this case, add the file extension ".wma" to the end of the file name, and then write the disc.

NO.8 CD PLAYER DOES NOT INDICATE THE MP3/WMA TITLE TEXT [CD PLAYER]

NO.9 CD PLAYER DOES NOT PLAY THE AUDIO DATA (CDDA) [CD PLAYER]

NO.10 TRACK CHANGE IS INOPERATIVE [CD PLAYER]

MP3/WMA-Formatted File

Outline of CD-R and CD-RW

1. Definition CD-R: The CD-R is a non-rewritable version. Once a section of a CD-R is written, it cannot be erased or rewritten. CD-RW: The CD-RW is a re-writable version of CD-ROM and can be written the data an unlimited number of times. Since a reflected laser beam amount of the CD-R/RW is less than the reflected laser beam amount of the conventional CD media, the CD player may not play the CD-R/RW or have the sound jumped. Since the recording quality of the CD-R/RW vary widely, some CD-R/RW may not be played.

Recording method

1. There are two methods for recording.
2. Classification by recorder Record the audio data in the audio-CD by audio recorder The price of the audio recorder and original audio-CD includes the copyright fee. Recorded the audio data in the conventional data-CD by the personal computer The data-CD is cheaper than the audio-CD. But, there is a CD with the low quality.
3. Classification by audio data uncompression/compression Uncompressed audio data The CD-R/RW player can play the uncompressed audio data. Compressed audio data It is possible to record the large quantity of music in a disc. The sound quality varies depends on the audio data compression format. The compressed audio data can be played on the applicable player only. Type of compression format: MP3: MPEG Audio Layer 3 - Mazda genie MP3 applicable CD player is available. WMA: Windows Media Audio ATRAG: Adaptive TRansform Acoustic Coding MP3
4. The following condition should be met in order to record the MP3-formatted data on the MP3 applicable CD player

WMA (Windows media audio)

1. CD-R and CD-RW including WMA files can be played with this unit. Discs which conform to the following formats can be played. Playable WMA files are as follows
