Entertainment System: Component Locations Mazda 3 BL рестайлинг

Entertainment Systems 18 illustrations ~1278 words

ANTENNA FEEDER LOCATION

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3. (5HB) (Scheme 67): Locating Antenna Feeder

Scheme 67

Scheme 67: ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION
Scheme 67: ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-520454-S30556586742013010300000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-520392-S39809031982013010300000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-520438-S23945830732013010300000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-520428-S03093920172013010300000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).)
  3. Partially peel back the hook. (Scheme 68): Peeling Back Hook
  4. Partially peel back the SIRIUS satellite radio antenna feeder. (Scheme 69): Peeling Back SIRIUS Satellite Radio Antenna Feeder
  5. Remove the clip A.
  6. Peel off the tape. (Scheme 70): Removing Clip A
  7. Partially peel back the hook.
  8. Remove the clips B. (Scheme 71): Removing Clips B
  9. Remove the antenna feeder No.1.
  10. Install in the reverse order of removal.

Scheme 71

Scheme 71: ANTENNA FEEDER NO.1 INSPECTION
Scheme 71: ANTENNA FEEDER NO.1 INSPECTION

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-520454-S30556586742013010300000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-520392-S39809031982013010300000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).)
  3. Disconnect antenna feeder No.2. (Scheme 72): Locating Antenna Feeder No.2
  4. Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table. (Scheme 73): Identifying Antenna Feeder No.1 Connector Terminals If not as indicated in the table, replace antenna feeder No.1. (Scheme 74): Antenna Feeder No.1 Terminals Continuity Chart

Scheme 74

Scheme 74: ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION
Scheme 74: ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION

Scheme 75

Scheme 75
Scheme 75
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Remove the antenna feeder No.2.
  7. Install in the reverse order of removal. Without sunroof (Scheme 75): Antenna Feeder No.2 (Without Sunroof) (Scheme 76): Antenna Feeder No.2 (With Sunroof)

Scheme 76

Scheme 76: ANTENNA FEEDER NO.2 INSPECTION
Scheme 76: ANTENNA FEEDER NO.2 INSPECTION

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Rear seat cushion (4SD) (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (5HB, RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) Trunk side trim (5HB, RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S41103934472013010300000).) C-pillar trim (RH) (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).)
  3. Disconnect the antenna feeder No.1. (Scheme 77): Antenna Feeder No.1
  4. Disconnect the antenna amplifier (4SD)/ antenna feeder No.3 (5HB). (Scheme 78): Antenna Amplifier (4SD) (Scheme 79): Antenna Feeder No.3 (5HB)
  5. Verify that the continuity between antenna feeder No.2 terminals is as indicated in the table. (Scheme 80): Antenna Feeder No.2 Connector Terminals If not as indicated in the table, replace antenna feeder No.2. (Scheme 81): Antenna Feeder No.2 Terminals Continuity Chart

Scheme 81

Scheme 81: ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION
Scheme 81: ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Disconnect the connector. (Scheme 82): Antenna Feeder No.3, Connector And Clips
  7. Remove the clips A and B.
  8. Remove the antenna feeder No.3.
  9. Install in the reverse order of removal.

Scheme 82

Scheme 82: ANTENNA FEEDER NO.3 INSPECTION
Scheme 82: ANTENNA FEEDER NO.3 INSPECTION

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Disconnect the connector. (Scheme 83): Antenna Feeder No.3 And Connector
  7. Verify that the continuity between antenna feeder No.3 terminals is as indicated in the table. (Scheme 84): Identifying Antenna Feeder No.3 Connector Terminals If not as indicated in the table, replace antenna feeder No.3. see scheme 86: Antenna Feeder No.3 Terminals Continuity Chart
