Entertainment System: Other Mazda 3 BL рестайлинг

Welcome Mode ON/OFF Setting

Note. WELCOME mode is controlled by the instrument cluster. Refer to the instrument cluster description.

1. Refer to «INSTRUMENTATION/DRIVER INFO. PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-520387-S41401232622013010300000) .

Scheme 85

Scheme 86

1. Switch the ignition to ACC or ON.
2. Turn the audio unit power to ON.
3. Press the AUDIO CONT switch. (Scheme 85): Pressing AUDIO CONT Switch
4. Select "Welcome ON" or "Welcome OFF".
5. Press the AUDIO CONT switch.
6. Select "ON" or "OFF". (Scheme 86): Selecting "Welcome ON" And "Welcome OFF"

Scheme 87

Scheme 88

1. Switch the ignition to ACC or ON.
2. Turn the audio unit power to ON.
3. Press the AUDIO CONT switch. (Scheme 87): Pressing AUDIO CONT Switch
4. Select "ILLM EFT ON" or "ILLM EFT OFF".
5. Press the AUDIO CONT switch.
6. Select "ON" or "OFF". (Scheme 88): Selecting "ILLM EFT ON" And "ILLM EFT OFF"

Switching between SIRIUS satellite radio unit equipped/not equipped

Note. Do not operate the command for the Sirius radio because it is used for the factory inspection.

Scheme 89

1. Connect the M-MDS (IDS) to the DLC-2. (Scheme 89): Identifying DLC-2
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. Select the "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "Audio Configure". M-MDS display Function Setting Sirius radio Perform a write on the instrument cluster for whether or not a SIRIUS satellite radio unit is equipped. NOTE: Do not operate the command because it is for factory inspection.

5HB

Note. The center roof antenna has a built-in antenna amplifier.

SIRIUS Satellite Radio Antenna Feeder No.1

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness.

1. Refer to «DASHBOARD DISASSEMBLY/ASSEMBLY»(ref-520454-S13367871532013010300000) .

SIRIUS Satellite Radio Antenna Feeder No.2

Note. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2.

1. Refer to «ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION»(ref-520392-S21574632162013010300000) .

SIRIUS Satellite Radio Antenna Feeder No.3 (5HB)

Note. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3.

1. Refer to «ANTENNA FEEDER NO.3 REMOVAL/INSTALLATION»(ref-520392-S16523359742013010300000) .

Note. SIRIUS satellite radio antenna feeder No.1 is integrated with the dashboard wiring harness.

Scheme 90

Scheme 91

Scheme 92

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).)
3. Disconnect the SIRIUS satellite radio antenna feeder connector. (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-520392-S00355049552013010300000).)
4. Disconnect the antenna feeder No.2. (Scheme 91): Antenna Feeder No.2
5. Verify that the continuity between SIRIUS satellite radio antenna feeder No.1 terminals is as indicated in the table. (Scheme 92): Identifying SIRIUS Satellite Radio Antenna Feeder No.1 Connector Terminals If not as indicated in the table, replace dashboard wiring harness. (Scheme 93): SIRIUS Satellite Radio Antenna Feeder No.1 Terminals Continuity Chart

Note. SIRIUS satellite radio antenna feeder No.2 is integrated with the antenna feeder No.2.

1. Refer to «ANTENNA FEEDER NO.2 INSPECTION»(ref-520392-S14051325512013010300000) .

Note. SIRIUS satellite radio antenna feeder No.3 is integrated with the antenna feeder No.3.

1. Refer to «ANTENNA FEEDER NO.3 INSPECTION»(ref-520392-S30110389052013010300000) .

Scheme 93

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-520387-S33083702672013010300000).)
3. Remove in the order indicated in the table. see scheme 90: GPS Antenna, Connector, Clip And Screw
4. Install in the reverse order of removal.

Without Bluetooth System

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

1. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S30398979032013010300000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S38458334842013010300000).)
3. Disconnect the steering switch connector.
4. Verify the resistance between the steering switch terminals. (Scheme 95): Identifying Steering Switch Connector Terminals If not within the specification, replace the steering switch. (Scheme 96): Steering Switch Terminals Resistance Chart (1 Of 3) (Scheme 97): Steering Switch Terminals Resistance Chart (2 Of 3) (Scheme 98): Steering Switch Terminals Resistance Chart (3 Of 3)
5. Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground. (Scheme 99): Applying Battery Positive Voltage To Steering Switch Terminal O
6. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

With Bluetooth System

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

1. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S30398979032013010300000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S38458334842013010300000).)
3. Disconnect the steering switch connector.
4. Verify the resistance between the steering switch terminals. (Scheme 100): Identifying Steering Switch Connector Terminals If not within the specification, replace the steering switch. (Scheme 101): Steering Switch Terminals Resistance Chart (1 Of 4) (Scheme 102): Steering Switch Terminals Resistance Chart (2 Of 4) (Scheme 103): Steering Switch Terminals Resistance Chart (3 Of 4) (Scheme 104): Steering Switch Terminals Resistance Chart (4 Of 4)
5. Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground. (Scheme 105): Applying Battery Positive Voltage To Steering Switch Terminal O
6. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

Scheme 105

Scheme 106

Scheme 107

Scheme 108

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).)
3. Disconnect the connector. (Scheme 106): Microphone Connector (Without Sunroof) (Scheme 107): Microphone Connector (With Sunroof)
4. Remove the microphone in the direction of the arrow (2) shown in the figure while pressing the microphone tabs in the direction of the arrow (1). (Scheme 108): Pressing Microphone Tabs (Without Sunroof) (Scheme 109): Pressing Microphone Tabs (With Sunroof)
5. Install in the reverse order of removal.

Scheme 109

Scheme 110

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) AFS control module (With AFS (adaptive front lighting system)) (See «AFS (ADAPTIVE FRONT LIGHTING SYSTEM) CONTROL MODULE REMOVAL/INSTALLATION»(ref-520371-S20224377082013010300000).)
3. Remove the nuts. (Without AFS (adaptive front lighting system)) (Scheme 110): Bluetooth UNIT Nuts With Torque Specification
4. Disconnect the connector.
5. Detach the clip and set the wiring harness aside. (Scheme 111): Detaching Clip Of Bluetooth UNIT
6. Remove the Bluetooth unit.
7. Install in the reverse order of removal.

Scheme 111

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
3. Remove the shift lever knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).)
4. Remove the selector lever knob. (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)
5. Remove the shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).)
6. Remove in the order indicated in the table. (Scheme 112): Front Accessory Socket And Cap
7. Install in the reverse order of removal.

Scheme 112

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
3. Remove in the order indicated in the table. (Scheme 113): Rear Accessory Socket And Cap
4. Install in the reverse order of removal.

Scheme 113

1. Remove the socket in the direction of the arrow (2) shown in the figure while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover. (Scheme 114): Removing Socket

Scheme 114

1. Remove the cap in the direction of the arrow (2) shown in the figure while pressing the cap tabs in the direction of the arrow (1). (Scheme 115): Pressing Cap Tabs

Scheme 115

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
3. Remove the shift lever knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).)
4. Remove the selector lever knob. (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)
5. Remove the shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).)
6. Remove the accessory socket (front) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-520392-S32522969062013010300000).)
7. Connect a tester as shown in the figure and verify that there is continuity. (Scheme 116): Inspecting Front Accessory Socket If the continuity cannot be verified, replace the accessory socket (front).

Scheme 116

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Accessory socket (rear) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-520392-S32522969062013010300000).)
3. Connect a tester as shown in the figure and verify that there is continuity. (Scheme 117): Inspecting Rear Accessory Socket If the continuity cannot be verified, replace the accessory socket (rear).

Scheme 117

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
3. Remove the auxiliary jack in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack tabs in the direction of the arrow (1). (Scheme 118): Pressing Auxiliary Jack Tabs
4. Install in the reverse order of removal.

Scheme 118

Scheme 119

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Auxiliary jack (See «AUXILIARY JACK REMOVAL/INSTALLATION»(ref-520392-S42766410032013010300000).)
3. Connect a commercially-available nonresistant plug to the auxiliary jack. (Scheme 119): Connecting Commercially-Available Nonresistant Plug To Auxiliary Jack
4. Verify that the continuity between the auxiliary jack terminals is as indicated in the table. see scheme 123: Auxiliary Jack Terminals Continuity Chart If not as indicated in the table, replace the auxiliary jack.
